Summary of Contents for Clarke CRS710V
- Page 1 RECIPROCATING SAW MODEL NO: CRS710V PART NO: 6462552 OPERATION & MAINTENANCE INSTRUCTIONS LS0416...
-
Page 2: Environmental Recycling Policy
INTRODUCTION Thank you for purchasing this CLARKE 710W Variable Speed Reciprocating Saw. Before attempting to use this product, please read this manual thoroughly and follow the instructions carefully. In doing so you will ensure the safety of yourself and that of others around you, and you can look forward to your purchase giving you long and satisfactory service. -
Page 3: General Power Tool Safety Warnings
GENERAL POWER TOOL SAFETY WARNINGS WARNING: READ ALL INSTRUCTIONS. FAILURE TO FOLLOW ALL INSTRUCTIONS LISTED BELOW MAY RESULT IN ELECTRIC SHOCK, FIRE AND/ OR SERIOUS INJURY. THE TERM “POWER TOOL” IN THE WARNINGS REFERS TO YOUR MAINS-OPERATED RECIPROCATING SAW. Save all warnings and instructions for future reference. 1) WORK AREA SAFETY a. - Page 4 c. Prevent unintentional starting. Ensure the switch is in the off-position before connecting to power source and/or battery pack, picking up or carrying the tool. Carrying power tools with your finger on the switch or energising power tools that have the switch on invites accidents. d.
-
Page 5: Additional Warnings For Reciprocating Saws
ADDITIONAL WARNINGS FOR RECIPROCATING SAWS 1. ALWAYS use the appropriate blade for the material being cut. 2. ONLY sharp saw blades in perfect working condition should be used; cracked or bent saw blades should be discarded and replaced at once. 3. -
Page 6: Electrical Connections
ELECTRICAL CONNECTIONS WARNING: READ THESE ELECTRICAL SAFETY INSTRUCTIONS THOROUGHLY BEFORE CONNECTING THE PRODUCT TO THE MAINS SUPPLY. This product is provided with a standard 13 amp, 230 volt (50Hz), BS 1363 plug, for connection to a standard, domestic electrical supply. Should the plug need changing at any time, ensure that a plug of identical specification is used. -
Page 7: Parts Identification
PARTS IDENTIFICATION Number Description Wood Blade (X3) Shoe Blade Holder Carbon Brush Cap Handle Release Button. Trigger Lock On Button Metal Blade (X3) Hex Key (Not shown) Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... -
Page 8: Before Use
BEFORE USE FITTING THE BLADE WARNING: BEFORE REMOVING, OR INSTALLING A BLADE, MAKE SURE THAT THE MAINS PLUG HAS BEEN REMOVED FROM THE MAINS SUPPLY. 1. Twist and hold the blade holder open. 2. Insert the blade as far as possible into the holder with the blade teeth facing downwards. -
Page 9: Operation
WARNING: THE BLADE WILL CONTINUE TO RUN FOR A SHORT PERIOD AFTER THE TRIGGER HAS BEEN RELEASED WAIT UNTIL IT STOPS BEFORE REMOVING IT FROM THE WORKPIECE. REPLACEMENT BLADES Replacement blades are available from your CLARKE dealer. Please quote the following part numbers: Type Part number... -
Page 10: Cutting Tips
CUTTING TIPS WARNING: IF THE CUTTING OPERATION IS DUSTY, WE RECOMMEND THAT YOU WEAR A DUST MASK. GENERAL CUTTING • Allow the tool to reach full speed before touching the work material. • Guide the saw blade into the workpiece keeping the shoe pressed firmly against the workpiece while cutting to prevent tool kickback. -
Page 11: Cutting Metal
• Keep the handle clean and free from oil and grease. • Resin and glue on the blade causes poor cutting results. Clean the blade after use. • Refer to your CLARKE dealer if internal maintenance is required. CHANGING THE CARBON BRUSHES 1. Remove the carbon brush caps using a flat screwdriver. -
Page 12: Specifications
SPECIFICATIONS MODEL CRS710V Voltage 230 V AC @ 50Hz Input power 710 Watts No-load speed 0–2800 Strokes Per Min Stroke Length 20 mm Weight 2.38 kg Dimensions (L x W x H) 453 x 78 x 149 mm Maximum Blade Length... -
Page 13: Parts Diagram
PARTS DIAGRAM Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... -
Page 14: Parts List
PARTS LIST Chuck Washer Washer Ø10.2×ø14.8×1 Connecting Ring 4.2 Outer Ring Bearing 6000-2z 230v Stator Tension Spring Circlip For Shaft Ø 22 Cable Sleeve Bearing 608-2z Spring Compression Spring Gearing Housing Housing Inner Ring Shoe Brand Chuck Pin 3x16 Saw Blade103×1×1 Brush Cover Plastic Ring Baffle... -
Page 15: Declaration Of Conformity
DECLARATION OF CONFORMITY Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
