Module Interfaces - Cabletron Systems 9A426-01 Appendix

9A426-01/9A426-02 Module Specific Information

Module Interfaces

The 9A426-01 ATM Module has seven interfaces. Table 1 lists the identifying
number, name, and description of each interface.
Interface
Number
The 9A426-02 ATM Module has eight interfaces. Table 2 lists the identifying
number, name, and description of each interface.
Interface
Number
Use the numbers in Table 1 or Table 2 to configure your module's default interface
(see the General Configuration Screen).
2
Table 1. 9A426-01 ATM Module Interfaces
Interface
Name
1 SMB-1
2 SMB-10
3 HOST 1
4 HOST 2
5 INB
6 ATM-1
7 FNB
Table 2. 9A426-02 ATM Module Interfaces
Interface
Name
1 SMB-1
2 SMB-10
3 HOST 1
4 HOST 2
5 INB
6 ATM-1
7 ATM-2
8 FNB
Interface
Description
1 Mbps System Management Bus
10 Mbps System Management Bus
i960 Interface to SmartSwitch Core
i960 Interface to SmartSwitch Core
Internal Network Bus
ATM Front Panel Port 1 (APIM)
Flexible Network Bus
Interface
Description
1 Mbps System Management Bus
10 Mbps System Management Bus
i960 Interface to SmartSwitch Core
i960 Interface to SmartSwitch Core
Internal Network Bus
ATM Front Panel Port 1 (APIM)
ATM Front Panel Port 2 (APIM)
Flexible Network Bus
