FNB Resource Configuration Screen Fields
The following information briefly explains each FNB Resource Configuration
Screen field.
Current FDDI Con:
Displays the current connections of the selected module to the
SmartSwitch 9000 FNB.
Config ID
Displays an identification number that is automatically assigned to each
configuration.
FDDI Connections
Displays all possible connections of the selected module to the
SmartSwitch 9000 FNB.
Changing the Current FNB Connection
To change the current FNB connection:
1. Use the arrow keys to highlight the desired FDDI connection.
2. Press the Return key.
3. The connection you selected appears in the Current FDDI Con: field.
4. Use the arrow keys to highlight SAVE, then press the Return key.
The message "SAVED OK" appears. This message indicates that the FNB
connection you selected has been implemented. If you exit without saving, the
message "NOT SAVED -- PRESS SAVE TO KEEP CHANGES" appears, and
the FNB connection you selected will not be implemented.
5. Use the arrow keys to highlight RETURN , then press the Return key.
