9A426-01/9A426-02 Module Specific Information
Connection Table Screen
The 9A426-01/9A426-02 Connection Table Screen (Figure 2), displays the
currently configured connections on the module.
Module Name: 9A426-02
Slot Number: 5
ATM Port Current Connections:
ELAN:
PORT #:
6
SmartSwitch 9000
9A426-02 Connection Table
VPI VCI Encapsulation Type
0 0005 Other
0 0016 Other
1
Figure 2. 9A426-01/9A426-02 Connection Table Screen
Local Management
Firmware Revision: 01.00.01
BOOTPROM Revision: 01.01.01
2 ELAN:
EXIT
AAL Type
5
5
ADD/DELETE
ENTRY RETURN
