CHAPTER 4
TROUBLESHOOTING
The 7H02-06 Module uses LANVIEW, Cabletron Systems built-in
visual diagnostic and status monitoring system.
With LANVIEW LEDs the status of each transmit and receive port
on the 7H02-06 Module can be determined, at a glance. This section
discusses the function and purpose of the LEDs on the 7H02-06
Module.
Figure 4-1 shows the LANVIEW LEDs of the 7H02-06 Module.
7H02-06
SP
Transmit
Receive
Figure 4-1. The LANVIEW LEDs
4-1
