Introduction

Ring to be used with the 7H02-06 Module. These modules provide

the capability to share data without the use of external bridges or

routers.

The 7C03 MMAC SmartSwitch is a unique module that can be

installed in an MMAC Series chassis. The 7C04 Workgroup

SmartSwitch and the 7C04-R Workgroup SmartSwitch are stand-

alone chassis that provide the same functions.

1.3 FEATURES

The 7H02-06 provides Fast Ethernet connectivity via 5 front panel

RJ45 connectors and one FEPIM, and also includes the following

features:

• FEPIMs

• Fixed connectivity ports

1.3.1 LANVIEW LEDs

The 7H02-06 Module incorporates LANVIEW - Cabletron Systems

status monitoring and diagnostic system. Should a problem arise,

such as a power failure, the LANVIEW LEDs help you diagnose the

problem.

The 7H02-06 Module incorporates the following LANVIEW LEDs:

• Transmit (TX) LED

• Receive (RX) LED

For more information about the LANVIEW LEDs and the reset

switch on the 7H02-06 Module, refer to Chapter 4, Troubleshooting.

1-4
