Supplement: Additional Functions
Thank you, and congratulations on your choice of the LVS-400.
In addition to the LVS-400 functions you have come to know, LVS-400 Version 2.0 now also adds an
"A/B mode." A/B mode allows you to utilize the LVS-400 as an even more enhanced video switcher.
This supplement describes the use of "A/B Mode." Please read this material in conjunction with the
main LVS-400 Owner's Manual.
Before using this unit, carefully read the sections entitled: "USING THE UNIT
SAFELY" (LVS-400 Owner's Manual p. 2, p. 3) and "IMPORTANT NOTES"
(LVS-400 Owner's Manual p. 4). These sections provide important information
concerning the proper operation of the unit. Additionally, in order to feel assured
that you have gained a good grasp of every feature provided by your new unit,
LVS-400 Owner's Manual and Supplement: Additional Functions (the document
you are reading) should be read in its entirety. The manual should be saved and
kept on hand as a convenient reference.
Contents
Additional Functions.................................................................................... 2
Differences Between Normal Mode and A/B Mode............................... 2
Preparation for Use of A/B Mode.............................................................. 2
About the New Functions ....................................................... 5
Switching the Input ...................................................................................... 5
Composite Functions.................................................................................... 7
Preview Function ........................................................................................ 13
Other Settings........................................................................ 15
Switching between NTSC and PAL ......................................................... 15
Restoring the Original Factory Settings................................................... 16
