INSTALLING THE CONTROL BOX AND *BATTERY BOX KIT
(*BATTERY BOX KIT (ABBT2), NOT INCLUDED.)
STEP 7. Determine the mounting location for the control box and *optional battery box.
The battery and control box must be located within 4 feet of each other. Then install.
NOTE
Mount the control and optional battery box a minimum of 3 feet above the ground to keep dirt and water from damaging
the control board and within 4 feet of the operator arm in order for the operator cable to reach the control box.
A . Pre-drill (4) holes (7/32˝ drill bit) in backside of control and optional battery box, and through the fencing
where you will be securing the control and battery box to.
B. Now use the (4) supplied phillips screws for both boxes to mount the control and optional battery box to the
fence.
C. Make sure the on/off switch on the bottom of control box is in the off position.
