PULL TO OPEN INSTALLATION

OPERATOR ARM INSTALLATION
PULL TO OPEN: GATE SWINGS TO OPEN INSIDE PROPE PULL TO OPEN: GATE SWINGS TO OPEN INSIDE PROPERTY
The dimensions and step-by-step instructions that follow are for mounting the GHOST CONTROLS The dimensions and step-by-step instructions that follow are for mounting the GHOST CONTROLS
a PULL TO OPEN installation system to a standard gate that swings into the property. PULL TO OPEN installation system to a standard gate that swings into the property.
FOR PUSH TO OPEN APPLICATIONS, PLEASE GO TO PUSH TO OPEN APPLICATION ON "PUSH TO
OPEN INSTALLATION" ON PAGE 39.
STEP 1. Establish and mark the horizontal center lines of the gate and the post for proper
alignment of gate brackets.
P U L L T O O P E N
NOTE
Wheels cannot be used with
any Ghost Controls gate
®
opener system!
For gates weighing over 200
lbs. ball bearing hinges are
recommended.
Operator is not for use on
solid panel privacy gates.
Gate Operator in
®
NOTE
This center point will be used
for mounting the post bracket
in STEP 4.
© G h o s t C o n t r o l s
20
2 0 2 0
®
