Ghost Controls Ghost Pro Series Installation And Owner's Manual page 23

P U L L T O O P E N
23
STEP 4. Verifying minimum of 4˝ Gate Clearance and finishing rear post mount bracket assembly.
If the clearance is less than 4˝, you will need to adjust the pivot brackets so that you have at least 4˝ of clearance, other-
wise, you will not have minimal mechanical advantage needed to move the gate.
Once the clearances are correct, place the secondary bolt into the post mount and pivot bracket, as shown below.
Insert the M10x1.5x75mm bolt and M10 washer through the post bracket hole, then first pivot bracket, pivot spacer, second
pivot bracket, and exit out bottom hole of post bracket as shown below. Fasten a M10 washer and M10 locknut on the end of
the bolt. Finish by tightening both bolts on post bracket.
>4.0
Minimum Distance
Adjust position
as necessary
Adjust position
as necessary
Secondary bolt into
the pivot brackets
