3.2.2.

Connect Handset

Note: If your control box comes with a built-in foil handset, this step is optional.
Connect the handset to the 7-pin DIN socket (HS).
Note: You may connect any LOGICDATA handset to the LogicSP control box!
This will work even if your control box already comes equipped with a built-in foil
handset.
3.2.3.

Connect TV Power Cable

Connect the TV power cable (see Fig. 9, output 3) to your TV-set.
3.2.4.

Connect Optional Components

If a squeeze-line is used to implement pinch-protection for downwards and/or upwards
movement, connect it to the interface SL (see Fig. 9, port 5).
As mentioned above, if a built-in foil handset is used, connecting an alternative handset to the
HS port of the motor control box is also optional.
3.2.5.

Connect Mains Supply

Connect the mains cable to your control box.
Caution: Prior to connecting the mains cable, make sure that:
The mains supply voltage of your country matches the supply voltage
•
requirements printed on the control box. (110V / 60Hz for the US version, 230V
/ 60/50Hz for the European version.)
All components are connected to the appropriate interfaces.
•
When the power cord is connected, the LogicSP control box is operational!
