ACTIVATE STATION: CONTROLS, CONNECTIONS
AND INDICATORS
2
1. POWER/SLEEP: press and hold
to place the Activate Station and
classroom audio system into sleep
mode. The Activate Station will
continue to charge devices when in
sleep mode.
2. POWER INDICATOR: the light will
turn blue when powered on, amber
when placed in sleep mode.
3. LINK INDICATOR: this light is
solid green to indicate Activate is
connected to the audio system and
ready for operation. It will blink green
for several seconds when initially
plugged into power.
4. MICROPHONE VOLUME: adjusts
the volume level of the classroom
speaker for all connected
microphones. The indicator lights
to the right change to show volume
level.
5. AUDIO INPUT VOLUME: adjusts the
level of multimedia devices plugged
into the 3.5mm audio input ports.
8
8
3
1 4 5
9
7
6
6. AUDIO OUTPUT VOLUME: adjusts
the level of ALD or recording devices
plugged into the 3.5mm audio output
ports.
7. VOLUME LEVEL INDICATORS: shows
the volume level of the source that is
being adjusted (Microphone, Input,
Output). The source level will be
updated once a new volume button
is pressed.
8. FLEXMIKE CHARGING SLOTS (2):
place your Flexmike(s) in these slots
for nightly charging.
9. POD CHARGING SLOTS (8): place
your Pods in these slots for nightly
charging.
10. CHARGING COVERS: covers are
included to protect unused Pod
charging slots from dust and debris.
11. AUDIO INPUTS (1-4): connect
a multimedia audio source to
wirelessly send the audio to be
played through the whole classroom
speaker(s).
10
