  • Page 1 SuperServer ® 5029C-TN2 USER’S MANUAL Revision 1.0...
  • Page 2 State of California, USA. The State of California, County of Santa Clara shall be the exclusive venue for the resolution of any such disputes. Supermicro's total liability for all claims will not exceed the price paid for the hardware product.
  • Page 3 About this Manual This manual is written for professional system integrators and PC technicians. It provides information for the installation and use of the SuperServer 5029C-TN2. Installation and maintenance should be performed by experienced technicians only. Please refer to the 5029C-TN2 server specifications page on our website for updates on supported memory, processors and operating systems (http://www.supermicro.com).

  • Page 4: Table Of Contents

    SuperServer 5029C-TN2 User's Manual Contents Chapter 1 Introduction 1.1 Overview ..........................7 1.2 System Features ........................8 1.3 Chassis Features .........................9 Front Features ........................9 Rear Features ........................10 1.4 Motherboard Layout ......................11 Quick Reference Table ......................12 System Block Diagram ......................14 Chapter 2 Maintenance and Component Installation 2.1 Removing Power ........................15...
  • Page 5 Preface Chapter 3 Motherboard Connections 3.1 Power Connections ......................32 3.2 Headers and Connectors ....................33 Control Panel Header ....................37 3.3 Ports ...........................40 3.4 Jumpers ..........................44 Explanation of Jumpers.....................44 3.5 LED Indicators ........................47 Chapter 4 Software 4.1 Microsoft Windows OS Installation ..................48 4.2 Driver Installation ........................50 4.3 SuperDoctor 5 ........................51...
  • Page 6 SuperServer 5029C-TN2 User's Manual Contacting Supermicro Headquarters Address: Super Micro Computer, Inc. 980 Rock Ave. San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) support@supermicro.com (Technical Support) Website: www.supermicro.com Europe Address: Super Micro Computer B.V.

  • Page 7: Chapter 1 Introduction

    Chapter 1 Introduction 1.1 Overview The SuperServer 5029C-TN2 is a compact system comprised of the SC721TQ-250B chassis and the X11SCV-Q single processor motherboard. Refer to our website for information on operating systems that have been certified for use with the system (www.supermicro.com).

  • Page 8: System Features

    Two internal fixed 2.5" hard drive bays (DVD-ROM as an option in the top 2.5" bay) Power One 250W flex ATX power supply Dimensions Width 8.27" (210mm), Height 9.45" (240mm), Depth 11" (279mm) *Refer to the Supermicro website for possible updates to supported memory.

  • Page 9: Chassis Features

    Chapter 1: Introduction 1.3 Chassis Features Front Features The SC721TQ-250B is a compact Mini Tower chassis. The front of the chassis includes a power on/off push-button, a reset button and several LEDs as described below. Figure 1-1. Chassis Front View Front Chassis Features Item Feature...

  • Page 10: Rear Features

    SuperServer 5029C-TN2 User's Manual Information LED Status Description An overheat condition has occurred. Continuously on and red (This may be caused by cable congestion.) Blinking red (1Hz) Fan failure, check for an inoperative fan. Rear Features The rear of the chassis has various input/output ports. Refer to Section 3.3 for more information.

  • Page 11: Motherboard Layout

    Chapter 1: Introduction 1.4 Motherboard Layout Jumper, connector and LED locations are shown below with brief descriptions on the following page. Detailed descriptions are found in Chapter 3. EDP1 LAN2 DVI-D COM1/2 USB6/7 (3.1) USB2/3 LAN1 JPL2 USB0/1 USB4/5 (3.1) JPL1 HD AUDIO HDMI 2.0/DP...

  • Page 12: Quick Reference Table

    SuperServer 5029C-TN2 User's Manual Quick Reference Table Jumper Description Default Setting JBT1 CMOS Clear Open (Normal) C1/JI SMB to PCI-E Slots Enable/Disable Pins 2-3 (Disabled) JPL1, JPL2 LAN1, LAN2 Enable/Disable Pins 1-2 (Enabled) JPME2 ME Manufacturing Mode Pins 1-2 (Normal)
  • Page 13 Chapter 1: Introduction Connector Description SLOT7 CPU PCI-E 3.0 x16 Slot SRW1 - SRW2 M.2 Mounting Screws USB0/1, USB2/3 Front Accessible USB 2.0 Ports USB4/5, USB6/7 Back Panel USB 3.1 Ports USB8/9 Front Accessible USB Header (Two USB 3.1 Type A)

  • Page 14: System Block Diagram

    SuperServer 5029C-TN2 User's Manual System Block Diagram SVID PCIe3.0_x16 IMVP8 PCIe x16 SLOT 8.0GT/s INTEL LGA1151 Digital port 1 HDMI DDI 1 (Socket-H4) DDR4 (CHA) Digital port 2 DIMMA1 Display Port DDI 2 2400MHz SODIMM,Vertical type Digital port 3 DVI-D...

  • Page 15: Chapter 2 Maintenance And Component Installation

    Chapter 2 Maintenance and Component Installation Chapter 2 Maintenance and Component Installation This chapter provides instructions on installing and replacing main system components. To prevent compatibility issues, only use components that match the specifications and/or part numbers given. Installation or replacement of most components requires that power first be removed from the system.

  • Page 16: Rear Chassis Hasp

    SuperServer 5029C-TN2 User's Manual Figure 2-1. Front Bezel Lock Rear Chassis Hasp Unauthorized entry through the rear of the chassis may be discouraged by placing a lock on the rear of the chassis. The chassis is equipped with a rear chassis hasp that can accomodate a variety of commonly available locks (not included).

  • Page 17: Accessing The System

    Chapter 2 Maintenance and Component Installation 2.3 Accessing the System The SC721TQ-250B features a removable top cover to access to the inside of the chassis. Figure 2-4. Removing the Chassis Cover Removing the Top Cover 1. Power down the system as described in section 2.1. 2.

  • Page 18: Motherboard Components

    Pentium processor with up to 65W in an LGA1151 socket. Memory Support The motherboard supports up to 32GB of Non-ECC SO-DIMM with speeds of 2400/2666MHz in two memory slots. Check the Supermicro website for a list of memory modules that have been validated. Installing Memory Caution: Exercise extreme care when installing or removing DIMM modules to prevent damage.

  • Page 19: Dimm Installation

    Chapter 2 Maintenance and Component Installation DIMM Installation 1. Install the desired number of SO-DIMMs into the memory slots, starting with DIMMA1 and then DIMMB1. 2. Align the key on the bottom of the SO-DIMM module against the receptive point on the memory slot.

  • Page 20: Installing Expansion Cards

    SuperServer 5029C-TN2 User's Manual Installing Expansion Cards The 5029C-TN2 includes one M.2 PCI-E 3.0 x1 slot, one M.2 PCI-E 3.0 x4 slot, and one PCI-E 3.0 x16 slot for expansion cards. The cards are installed by removing the chassis tray that holds the motherboard and rear I/O shield.
  • Page 21 Chapter 2 Maintenance and Component Installation 3. Pull the rear tray out from the chassis. 4. Remove the screw that secures the PCI slot shield in the PCI slot at the rear of the tray and set it aside for later use. 5.

  • Page 22: Motherboard Battery

    SuperServer 5029C-TN2 User's Manual Motherboard Battery The motherboard uses non-volatile memory to retain system information when system power is removed. This memory is powered by a lithium battery residing on the motherboard. LITHIUM BATTERY BATTERY HOLDER Figure 2-8. Installing the Onboard Battery Replacing the Battery 1.

  • Page 23: Chassis Components

    Chapter 2 Maintenance and Component Installation 2.5 Chassis Components Front-Mounted Hot-Swap Drives The SC721TQ-250B supports four hot-swappable drives mounted in carriers that are accessible from the front of the chassis. These drives may be removed and installed without powering down the system. Removing 3.5"...
  • Page 24 SuperServer 5029C-TN2 User's Manual Hard Drive Dummy Drive Hard Drive Carrier Figure 2-10. Installing a Hard Drive into a Drive Carrier Installing a Drive Carrier into the Hard Drive Cage 1. Insert the hard drive carrier into the drive bay, using the drive carrier handle to push it all the way into the hard drive cage until it stops.

  • Page 25: Installing The Internal Fixed Hard Drives

    Chapter 2 Maintenance and Component Installation Installing the Internal Fixed Hard Drives The SC721TQ-250B chassis supports two internal 2.5" SATA fixed hard drives: one top- mounted drive and one side-mounted drive. Installing a Top-Mounted Fixed Hard Drive 1. Power down the system as described in Section 2.1 and remove the chassis cover. 2.
  • Page 26 SuperServer 5029C-TN2 User's Manual Installing a Side-Mounted Fixed Hard Drive 1. Power down the system as described in Section 2.1 and remove the chassis cover as described in Section 2.3. 2. Place a 2.5" hard drive into the hard drive bracket and secure the hard drive to the bracket with the four screws provided.

  • Page 27: Installing A Dvd Drive

    Chapter 2 Maintenance and Component Installation Installing a DVD Drive The SC721TQ-250B supports one DVD drive. It can be installed only if the top mounted fixed HDD is not used. It requires a mounting bracket rail (p/n MCP-220-81502-0N). Installing a DVD Drive 1.
  • Page 28 SuperServer 5029C-TN2 User's Manual 7. Install the bracket rail (part number MCP-220-81502-0N) onto the left hand side of the DVD drive, using the two screws provided. Bracket Rail Figure 2-15. Securing the Bracket Rail to a DVD Drive 8. Slide the DVD drive into the chassis until it snaps into place. (Some DVD drives allow you to secure the drive with two screws.)

  • Page 29: Installing A Fan

    Chapter 2 Maintenance and Component Installation Installing a Fan The chassis includes a single 12-cm rear exhaust fan. The chassis also features a set of mounting holes that will support a standard 9-cm exhaust fan (not included). Installing the Exhaust Fan 1.

  • Page 30: Replacing The Power Supply

    SuperServer 5029C-TN2 User's Manual Replacing the Power Supply The SC721TQ-250B includes a fixed (non-hot-swap) 250W power supply. If it is necessary to replace the power supply, follow the instructions below. Note: The power supply power cords must include a grounding plug and must be plugged into grounded electrical outlets.
  • Page 31 Chapter 2 Maintenance and Component Installation Power Supply Figure 2-18. Removing the Power Supply...

  • Page 32: Chapter 3 Motherboard Connections

    SuperServer 5029C-TN2 User's Manual Chapter 3 Motherboard Connections This section describes the connections on the X11SCV-Q motherboard and provides pinout definitions. Note that depending on how the system is configured, not all connections are required. The LEDs on the motherboard are also described here. A motherboard layout indicating component locations may be found in Chapter 1.

  • Page 33: Headers And Connectors

    Chapter 3: Motherboard Connections 3.2 Headers and Connectors Fan Headers There are three 4-pin fan headers on the motherboard; pins 1-3 are backwards compatible with traditional 3-pin fans. The onboard fan speeds are controlled by Thermal Management (via Hardware Monitoring) in the BIOS. When using Thermal Management setting, please use all 3-pin fans or all 4-pin fans.
  • Page 34 SuperServer 5029C-TN2 User's Manual TPM Header The JTPM1 header is used to connect a Trusted Platform Module (TPM)/Port 80, which is available from a third-party vendor. A TPM/Port 80 connector is a security device that supports encryption and authentication in hard drives. It allows the motherboard to deny access if the TPM associated with the hard drive is not installed in the system.
  • Page 35 Chapter 3: Motherboard Connections Front Accessible Audio Header A 10-pin audio header located AUDIO FP allows you to use the onboard sound for audio playback. Connect an audio cable to this header to use this feature. Refer to the table below for pin definitions.
  • Page 36 The X11SCV-Q has five I-SATA 3.0 ports (I-SATA0 - I-SATA4). I-SATA0 can be used with Supermicro SuperDOMs that are yellow SATA DOM connectors with power pins built in, and do not require external power cables. Supermicro SuperDOMs are backward-compatible with regular SATA HDDs or SATA DOMs that need external power cables.

  • Page 37: Control Panel Header

    JF1 contains header pins for various buttons and indicators that are normally located on a control panel at the front of the chassis. These connectors are designed specifically for use with Supermicro chassis. See the figure below for the descriptions of the front control panel buttons and LED indicators.
  • Page 38 SuperServer 5029C-TN2 User's Manual Reset Button The Reset Button connection is located on pins 3 and 4 of JF1. Attach it to a hardware reset switch on the computer case to reset the system. Refer to the table below for pin definitions.
  • Page 39 Chapter 3: Motherboard Connections HDD LED The HDD LED connection is located on pins 13 and 14 of JF1. Attach a cable here to indicate the status of HDD-related activities, including SATA. Refer to the table below for pin definitions. HDD LED Pin Definitions (JF1) Pin#...

  • Page 40: Ports

    SuperServer 5029C-TN2 User's Manual 3.3 Ports Figure 3-2. Rear input/Output Ports Description Description Description DP Port LAN2 COM1 HDMI Port USB7 (3.1 Type A) Line Out LAN1 USB6 (3.1 Type C) Mic In USB5 (3.1 Type A) DVI-D USB4 (3.1 Type C)
  • Page 41 Chapter 3: Motherboard Connections LAN Ports There are two 1GbE LAN ports (LAN1 and LAN2) on the I/O back panel. These ports accept RJ45 type cables. Refer to the table below for the pin definitions. LAN Port Pin Definition Pin# Definition Pin# Definition...
  • Page 42 SuperServer 5029C-TN2 User's Manual Embedded DisplayPort The eDP header is used to connect an embedded display LED or LCD Panel. eDP is a companion standard to the DisplayPort interface designed for embedded display applications, including notebook PCs, tablets, netbooks, and all-in-one desktop PCs. The X11SCV-Q supports 3.3V eDP LED or LCD panel only.
  • Page 43 Chapter 3: Motherboard Connections Universal Serial Bus (USB) Header There are two USB 2.0 headers (USB0/1, USB2/3) and one USB 3.1 header (USB8/9) on the motherboard to provide two USB 3.1 Type A front access connection with a cable (not included).

  • Page 44: Jumpers

    SuperServer 5029C-TN2 User's Manual 3.4 Jumpers Explanation of Jumpers To modify the operation of the motherboard, jumpers are used to choose between optional settings. Jumpers create shorts between two pins to change the function associated with it. Pin 1 is identified with a square solder pad on the printed circuit board. See the motherboard layout page for jumper locations.
  • Page 45 Chapter 3: Motherboard Connections Onboard Audio Enable JPAC1 allows you to enable or disable the onboard audio support. The default position is on pins 1-2 to enable onboard audio connections. Refer to the table below for jumper settings. Audio Enable/Disable Jumper Settings Jumper Setting Definition...
  • Page 46 SuperServer 5029C-TN2 User's Manual LAN Port Enable/Disable Use JPL1 to enable or disable LAN1, and JPL2 to enable or disable LAN2. The default setting is Enabled. LAN Port Enable/Disable Jumper Settings Jumper Setting Definition Pins 1-2 Enabled (Default) Pins 2-3...

  • Page 47: Led Indicators

    Chapter 3: Motherboard Connections 3.5 LED Indicators Onboard Power LED LED1 is an Onboard Power LED. When this LED is lit, it means power is present on the motherboard. In suspend mode, this LED will blink on and off. Be sure to turn off the system and unplug the power cord(s) before removing or installing components.

  • Page 48: Chapter 4 Software

    USB/SATA DVD drive, or a USB flash drive, or the IPMI KVM console. 2. Retrieve the proper RST/RSTe driver. Go to the Supermicro web page for your motherboard and click on "Download the Latest Drivers and Utilities", select the proper driver, and copy it to a USB flash drive.
  • Page 49 Chapter 4: Software 4. During Windows Setup, continue to the dialog where you select the drives on which to install Windows. If the disk you want to use is not listed, click on “Load driver” link at the bottom left corner. Figure 4-2.

  • Page 50: Driver Installation

    The Supermicro website contains drivers and utilities for your system at https://www. supermicro.com/wftp/driver. Some of these must be installed, such as the chipset driver. After accessing the website, go into the CDR_Images (in the parent directory of the above link) and locate the ISO file for your motherboard. Download this file to a USB flash drive or a DVD.

  • Page 51: Superdoctor ® 5

    4.3 SuperDoctor ® The Supermicro SuperDoctor 5 is a program that functions in a command-line or web-based interface for Windows and Linux operating systems. The program monitors such system health information as CPU temperature, system voltages, system power consumption, fan speed, and provides alerts via email or Simple Network Management Protocol (SNMP).

  • Page 52: Ipmi

    SuperServer 5029C-TN2 User's Manual 4.4 IPMI The X11SCV-Q supports the Intelligent Platform Management Interface (IPMI). IPMI is used to provide remote access, monitoring and management. There are several BIOS settings that are related to IPMI. For general documentation and information on IPMI, please visit our website at:...

  • Page 53: Chapter 5 Uefi Bios

    Chapter 5: UEFI BIOS Chapter 5 UEFI BIOS 5.1 Introduction This chapter describes the AMIBIOS™ Setup utility for the X11SCV-Q series motherboard. The BIOS is stored on a chip and can be easily upgraded using a flash program. Note: Due to periodic changes to the BIOS, some settings may have been added or deleted and might not yet be recorded in this manual.

  • Page 54: Main Setup

    SuperServer 5029C-TN2 User's Manual 5.2 Main Setup When you first enter the AMI BIOS setup utility, you will enter the Main setup screen. You can always return to the Main setup screen by selecting the Main tab on the top of the screen.
  • Page 55 Chapter 5: UEFI BIOS Memory Information Total Memory This item displays the total size of memory available in the system.

  • Page 56: Advanced

    SuperServer 5029C-TN2 User's Manual 5.3 Advanced Use the arrow keys to select Advanced setup and press <Enter> to access the submenu items: Warning: Take caution when changing the Advanced settings. An incorrect value, a very high DRAM frequency or an incorrect BIOS timing setting may cause the system to malfunction.
  • Page 57 Chapter 5: UEFI BIOS Option ROM Messages Use this feature to set the display mode for the Option ROM. Select Keep Current to display the current AddOn ROM setting. Select Force BIOS to use the Option ROM display set by the system BIOS.
  • Page 58 SuperServer 5029C-TN2 User's Manual CPU Configuration  The following CPU information will display: • Processor type • CPU Signature • Microcode Patch • Max CPU Speed • Min CPU Speed • CPU Speed • Processor Cores • Hyper Threading Technology •...
  • Page 59 Chapter 5: UEFI BIOS C6DRAM Select Enabled to activate moving the DRAM contents to PRM memory when the CPU is in the C6 state. The options are Disabled and Enabled. Hardware Prefetcher If set to Enable, the hardware prefetcher will prefetch streams of data and instructions from the main memory to the L2 cache to improve CPU performance.
  • Page 60 SuperServer 5029C-TN2 User's Manual Turbo Mode Select Enable for processor cores to run faster than the frequency specified by the manufacturer. The options are Disable and Enable. Package Power Limit MSR Lock Select Enabled to lock the package power limit for the model specific registers. The options are Disabled and Enabled.
  • Page 61 Chapter 5: UEFI BIOS 4-Core Ratio Limit Override This increases (multiplies) 4 clock speeds in the CPU core in relation to the bus speed when four CPU cores are active. Press "+" or "-" on your keyboard to change the value. Enter 32 to use the manufacture default setting.
  • Page 62 SuperServer 5029C-TN2 User's Manual System Agent (SA) Configuration The following information will display: • SA PCIe Code Version • VT-d: Supported Memory Configuration Memory Configuration • Memory RC Version • Memory Frequency • Memory Timing (tCL-tRCD-tRP-tRAS) • DIMMA1 • DIMMB1 Maximum Memory Frequency Use this feature to set the maximum memory frequency for onboard memory modules.
  • Page 63 Chapter 5: UEFI BIOS Graphics Configuration IGFX VBIOS Version 1013 IGFX GOP Version N/A Primary Display Use this feature to select the primary video display. The options are Auto, IGFX, PEG, and PCI. Primary PEG Use this feature to select which graphics device should be the the primary PEG. The default is CPU SLOT7 PCI-E 3.0 X16.
  • Page 64 SuperServer 5029C-TN2 User's Manual PAVP Enable Protected Audio Video Path (PAVP) decodes Intel integrated graphics encrypted video. The options are Disable and Enable. Cdynmax Clamping Enable Enable this feature to activate Cdynmax Clamping. The options are Enable and Disable. Graphics Clock Frequency Use this feature to set the internal graphics clock frequency.
  • Page 65 Chapter 5: UEFI BIOS SLOT7 Slot Power Limit Scale Use this feature to select the scale used for the slot power limit value. The options are 1.0x, 0.1x, 0.01x, and 0.001x. Program PCIe ASPM After OpROM PCIe ASPM, the Active State Power Management for PCI-Express slots, is a power management protocol used to manage power consumption of serial link devices installed on PCI-E slots during a prolonged off-peak time.
  • Page 66 SuperServer 5029C-TN2 User's Manual There are three Owner EPOCH modes (each EPOCH is 64 bit). The options are Select Owner EPOCH input type, Change to New Random Owner EPOCHs, and Manual User Defined Owner EPOCHs. PRMRR Size This feature appears if SW Guard Extensions is set to Enabled. This BIOS must reserve a contiguous region of Processor Reserved Memory (PRM) in the Processor Reserved Memory Range Register (PRMRR).
  • Page 67 Chapter 5: UEFI BIOS Use this feature to set the PCI Express L1 Substates. The options are Disabled, L1.1, and L1.1 & L1.2. Use this feature to enable or disable Precision Time Measurement. The options are Disabled and Enabled. Use this feature to enable or disable Downstream Port Containment. The options are Disabled and Enabled.
  • Page 68 SuperServer 5029C-TN2 User's Manual Use this feature to select the COM1 port type. The options are RS232, RS422, and RS485. Serial Port 2 Configuration Serial Port 2 Select Enabled to enable the selected onboard serial port. The options are Disabled and Enabled.
  • Page 69 Chapter 5: UEFI BIOS Serial Port 4 Configuration Serial Port 4 Select Enabled to enable the selected onboard serial port. The options are Disabled and Enabled. Device Settings This feature displays the status of a serial port specified by the user. Change Settings This feature specifies the base I/O port address and the Interrupt Request address of a serial port specified by the user.
  • Page 70 SuperServer 5029C-TN2 User's Manual Change Settings This feature specifies the base I/O port address and the Interrupt Request address of a serial port specified by the user. Select Auto to allow the BIOS to automatically assign the base I/O and IRQ address. The options are Auto, (IO=220h; IRQ=7;), (IO=3E8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12;), (IO=2E8h;...
  • Page 71 Chapter 5: UEFI BIOS Serial Port Console Redirection  COM1 - COM6 Console Redirection Select Enabled to enable COM ports 1-4 for Console Redirection, which will allow a client machine to be connected to a host machine at a remote site for networking. The options are Disabled and Enabled.
  • Page 72 SuperServer 5029C-TN2 User's Manual Flow Control Use this feature to set the flow control for Console Redirection to prevent data loss caused by buffer overflow. Send a "Stop" signal to stop sending data when the receiving buffer is full. Send a "Start" signal to start sending data when the receiving buffer is empty. The options are None and Hardware RTS/CTS.
  • Page 73 Chapter 5: UEFI BIOS Serial Port for Out-of-Band Management/Windows Emergency Management Services (EMS) Console Redirection Select Enabled to use a COM port selected by the user for EMS Console Redirection. The options are Disabled and Enabled. *If the feature above is set to Enabled, the following features are available for configuration: Console Redirection Settings ...
  • Page 74 SuperServer 5029C-TN2 User's Manual SATA And RST Configuration  SATA Controller(s) This feature enables or disables the onboard SATA controller supported by the Intel PCH chip. The options are Enabled and Disabled. SATA Mode Selection Select AHCI to configure a SATA drive specified by the user as an AHCI drive. Select RAID to configure a SATA drive specified by the user as a RAID drive.
  • Page 75 Chapter 5: UEFI BIOS PCH-FW Configuration ME Firmware Version ME Firmware Mode: Normal Mode ME Firmware SKU: Corporate SKU ME FW Image Re-Flash Use this feature to update the Mangement Engine firmware. The options are Disabled and Enabled. Manageability Features State Enabled this feature to allow system administrators to configure the ME BIOS extension (MEBx) configuration settings.
  • Page 76 SuperServer 5029C-TN2 User's Manual ASF Configuration  PET Progress Use this feature to enable or disable PET Events Progress to receive PET Events alerts. The options are Disabled and Enabled. WatchDog Select Enabled to allow AMT to reset or power down the system if the operating system or BIOS hangs or crashes.
  • Page 77 Chapter 5: UEFI BIOS Use this feature to hide the unconfigure ME confirmation prompt . The options are Disabled and Enabled. MEBx OEM Debug Menu Enable Use this feature to enable or disable the OEM debug menu in MEBx. The options are Disabled and Enabled.
  • Page 78 SuperServer 5029C-TN2 User's Manual The High Performance Event Timer is used to replace the 8254 Programmable Interval Timer. The options are Disabled and Enabled. Native PCIE Enable Enable this feature to grant control of PCI Express Native hot plug, PCI Express Power Management Events, and PCI Express Capability Structure Control.
  • Page 79 Chapter 5: UEFI BIOS PCIe/PCI/PnP Configuration  Option ROM execution Video Use this feature to select the execution of the video OpROM. The options are Do not launch, UEFI, and Legacy. PCI PERR/SERR Support Use this feature to enable or disable the runtime event for PCI errors. The options are Disabled and Enabled.
  • Page 80 SuperServer 5029C-TN2 User's Manual Network Stack Select Enabled to enable PXE (Preboot Execution Environment) or UEFI (Unified Extensible Firmware Interface) for network stack support. The options are Enabled and Disabled. *If the feature above is set to Enabled, the features below will be available for...
  • Page 81 Chapter 5: UEFI BIOS Trusted Computing  *The features in the Trusted Computing section on this page are displayed if a TPM 1.2 module is detected: Configuration Security Device Support If this feature and the TPM jumper on the motherboard are both set to Enabled, onboard security devices will be enabled for TPM support to enhance data integrity and network security.
  • Page 82 SuperServer 5029C-TN2 User's Manual *The features in the Trusted Computing section on this page and the next are displayed if a TPM 2.0 module is detected: TPM20 Device Found Firmware Version Vendor: IFX Security Device Support If this feature and the TPM jumper on the motherboard are both set to Enabled, onboard security devices will be enabled for TPM support to enhance data integrity and network security.
  • Page 83 Chapter 5: UEFI BIOS Endorsement Hierarchy Use this feature to disable or enable endorsement hierarchy for privacy control. The options are Disabled and Enabled. TPM2.0 UEFI Spec Version Use this feature to specify the TPM UEFI spec version. TCG 1.2 has support for Windows® 2012, Windows 8, and Windows 10.

  • Page 84: Event Logs

    SuperServer 5029C-TN2 User's Manual 5.4 Event Logs Use this feature to configure Event Log settings. Change SMBIOS Event Log Settings Enabling/Disabling Options SMBIOS Event Log Change this feature to enable or disable all features of the SMBIOS Event Logging during system boot.
  • Page 85 Chapter 5: UEFI BIOS SMBIOS Event Log Standard Settings Log System Boot Event Select Enabled to log system boot events. The options are Enabled and Disabled. MECI (Multiple Event Count Increment) Enter the increment value for the multiple event counter. Enter a number between 1 to 255. The default setting is 1.

  • Page 86: Security

    SuperServer 5029C-TN2 User's Manual 5.5 Security Use this feature to configure the security settings for the system. Administrator Password Use this feature to set the administrator password which is required to enter the BIOS setup utility. The length of the password should be from three characters to 20 characters long.
  • Page 87 Chapter 5: UEFI BIOS *If Secure Boot Mode is set to Customized, Key Management features are available for configuration: CSM Support This feature is for manufacturing debugging purposes.  Install Factory Default Keys Select Yes to install all factory keys to the default settings. The options are Yes and No. Key Management Vendor Keys Provision Factory Default keys...
  • Page 88 SuperServer 5029C-TN2 User's Manual  Platform Key (PK) Update Select Yes to load a factory default PK or No to load from a file on an external media.  Key Exchange Keys Update Select Yes to load a factory default KEK or No to load from a file on an external media.
  • Page 89 Chapter 5: UEFI BIOS  OsRecovery Signatures Update Select Yes to load a factory default dbr or No to load from a file on an external media. Append Select Yes to add the dbr from the manufacturer's defaults list to the existing dbr. Select No to load the dbr from a file.

  • Page 90: Boot

    SuperServer 5029C-TN2 User's Manual 5.6 Boot Use this feature to configure Boot Settings: Setup Prompt Timeout Use this feature to specify the length of time (the number of seconds) for the BIOS to wait before rebooting the system when the setup activation key is pressed. Enter the value of 65535 (0xFFFF) for the BIOS to wait indefinitely.
  • Page 91 Chapter 5: UEFI BIOS • LEGACY/UEFI/DUAL Boot Order #7 • LEGACY/UEFI/DUAL Boot Order #8 • LEGACY/UEFI/DUAL Boot Order #9 • LEGACY/UEFI/DUAL Boot Order #10 • LEGACY/UEFI/DUAL Boot Order #11 • LEGACY/UEFI/DUAL Boot Order #12 • LEGACY/UEFI/DUAL Boot Order #13 • LEGACY/UEFI/DUAL Boot Order #14 •...

  • Page 92: Save & Exit

    SuperServer 5029C-TN2 User's Manual 5.7 Save & Exit Select the Save & Exit tab from the BIOS setup screen to configure the settings below. Save Options Discard Changes and Exit Select this option to quit the BIOS Setup without making any permanent changes to the system configuration and reboot the computer.
  • Page 93 Chapter 5: UEFI BIOS Default Options Restore Defaults To set this feature, select Restore Optimized Defaults and press <Enter>. These are factory settings designed for maximum system performance but not for maximum stability. Save as User Defaults To set this feature, select Save as User Defaults from the Exit menu and press <Enter>. This enables the user to save any changes to the BIOS setup for future use.

  • Page 94: Appendix A Bios Codes

    SuperServer 5029C-TN2 User's Manual Appendix A BIOS Codes A.1 BIOS Error POST (Beep) Codes During the POST (Power-On Self-Test) routines, which are performed each time the system is powered on, errors may occur. Non-fatal errors are those which, in most cases, allow the system to continue the boot-up process.
  • Page 95 When BIOS performs the Power On Self Test, it writes checkpoint codes to I/O port 0080h. If the computer cannot complete the boot process, a diagnostic card can be attached to the computer to read I/O port 0080h (Supermicro p/n AOM-SPI80-V). For information on AMI updates, please refer to http://www.ami.com/products/.

  • Page 96: Appendix B Standardized Warning Statements For Ac Systems

    Supermicro's Technical Support department for assistance. Only certified technicians should attempt to install or configure components. Read this appendix in its entirety before installing or configuring components in the Supermicro chassis. These warnings may also be found on our website at http://www.supermicro.com/about/...
  • Page 97 Appendix B: Standardized Warning Statements Warnung WICHTIGE SICHERHEITSHINWEISE Dieses Warnsymbol bedeutet Gefahr. Sie befinden sich in einer Situation, die zu Verletzungen führen kann. Machen Sie sich vor der Arbeit mit Geräten mit den Gefahren elektrischer Schaltungen und den üblichen Verfahren zur Vorbeugung vor Unfällen vertraut. Suchen Sie mit der am Ende jeder Warnung angegebenen Anweisungsnummer nach der jeweiligen Übersetzung in den übersetzten Sicherheitshinweisen, die zusammen mit diesem Gerät ausgeliefert wurden.
  • Page 98 SuperServer 5029C-TN2 User's Manual . ٌ ‫ا ك ً ف حالة و ٌ يك أى تتسبب ف اصابة جسذ ة ٌ هذا الزهز ع ٌ خطز !تحذ ز‬ ‫قبل أى تعول عىل أي هعذات،يك عىل علن بالوخاطز ال ا ٌجوة عي الذوائز‬...
  • Page 99 Appendix B: Standardized Warning Statements Warnung Vor dem Anschließen des Systems an die Stromquelle die Installationsanweisungen lesen. ¡Advertencia! Lea las instrucciones de instalación antes de conectar el sistema a la red de alimentación. Attention Avant de brancher le système sur la source d'alimentation, consulter les directives d'installation. .‫יש...
  • Page 100 SuperServer 5029C-TN2 User's Manual Warnung Dieses Produkt ist darauf angewiesen, dass im Gebäude ein Kurzschluss- bzw. Überstromschutz installiert ist. Stellen Sie sicher, dass der Nennwert der Schutzvorrichtung nicht mehr als: 250 V, 20 A beträgt. ¡Advertencia! Este equipo utiliza el sistema de protección contra cortocircuitos (o sobrecorrientes) del edificio.
  • Page 101 Appendix B: Standardized Warning Statements Power Disconnection Warning Warning! The system must be disconnected from all sources of power and the power cord removed from the power supply module(s) before accessing the chassis interior to install or remove system components. 電源切断の警告...
  • Page 102 SuperServer 5029C-TN2 User's Manual ‫يجب فصم اننظاو من جميع مصادر انطاقت وإ ز انت سهك انكهرباء من وحدة امداد‬ ‫انطاقت قبم‬ ‫انىصىل إىن امنناطق انداخهيت نههيكم نتثبيج أو إ ز انت مكىناث الجهاز‬ 경고! 시스템에 부품들을 장착하거나 제거하기 위해서는 섀시 내부에 접근하기 전에 반드시 전원...
  • Page 103 Appendix B: Standardized Warning Statements Attention Il est vivement recommandé de confier l'installation, le remplacement et la maintenance de ces équipements à des personnels qualifiés et expérimentés. !‫אזהרה‬ .‫צוות מוסמך בלבד רשאי להתקין, להחליף את הציוד או לתת שירות עבור הציוד‬ ‫واملدربيه...
  • Page 104 SuperServer 5029C-TN2 User's Manual Warnung Diese Einheit ist zur Installation in Bereichen mit beschränktem Zutritt vorgesehen. Der Zutritt zu derartigen Bereichen ist nur mit einem Spezialwerkzeug, Schloss und Schlüssel oder einer sonstigen Sicherheitsvorkehrung möglich. ¡Advertencia! Esta unidad ha sido diseñada para instalación en áreas de acceso restringido. Sólo puede obtenerse acceso a una de estas áreas mediante la utilización de una herramienta especial,...
  • Page 105 Appendix B: Standardized Warning Statements Battery Handling Warning! There is the danger of explosion if the battery is replaced incorrectly. Replace the battery only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the manufacturer's instructions 電池の取り扱い...
  • Page 106 SuperServer 5029C-TN2 User's Manual ‫هناك خطر من انفجار يف حالة اسحبذال البطارية بطريقة غري صحيحة فعليل‬ ‫اسحبذال البطارية‬ ‫فقط بنفس النىع أو ما يعادلها مام أوصث به الرشمة املصنعة‬ ‫جخلص من البطاريات املسحعملة وفقا لحعليامت الرشمة الصانعة‬ 경고! 배터리가 올바르게 교체되지 않으면 폭발의 위험이 있습니다. 기존 배터리와 동일하거나 제...
  • Page 107 Appendix B: Standardized Warning Statements ¡Advertencia! Puede que esta unidad tenga más de una conexión para fuentes de alimentación. Para cortar por completo el suministro de energía, deben desconectarse todas las conexiones. Attention Cette unité peut avoir plus d'une connexion d'alimentation. Pour supprimer toute tension et tout courant électrique de l'unité, toutes les connexions d'alimentation doivent être débranchées.
  • Page 108 SuperServer 5029C-TN2 User's Manual Backplane Voltage Warning! Hazardous voltage or energy is present on the backplane when the system is operating. Use caution when servicing. バックプレーンの電圧 システムの稼働中は危険な電圧または電力が、 バックプレーン上にかかっています。 修理する際には注意く ださい。 警告 当系统正在进行时，背板上有很危险的电压或能量，进行维修时务必小心。 警告 當系統正在進行時，背板上有危險的電壓或能量，進行維修時務必小心。 Warnung Wenn das System in Betrieb ist, treten auf der Rückwandplatine gefährliche Spannungen oder Energien auf.
  • Page 109 Appendix B: Standardized Warning Statements ‫هناك خطز مه التيار الكهزبايئ أوالطاقة املىجىدة عىل اللىحة‬ ‫عندما يكىن النظام يعمل كه حذ ر ا عند خدمة هذا الجهاس‬ 경고! 시스템이 동작 중일 때 후면판 (Backplane)에는 위험한 전압이나 에너지가 발생 합니다. 서비스 작업 시 주의하십시오. Waarschuwing Een gevaarlijke spanning of energie is aanwezig op de backplane wanneer het systeem in gebruik is.
  • Page 110 SuperServer 5029C-TN2 User's Manual ‫תיאום חוקי החשמל הארצי‬ !‫אזהרה‬ .‫התקנת הציוד חייבת להיות תואמת לחוקי החשמל המקומיים והארציים‬ ‫تركيب املعدات الكهربائية يجب أن ميتثل للقىاويه املحلية والىطىية املتعلقة‬ ‫بالكهرباء‬ 경고! 현 지역 및 국가의 전기 규정에 따라 장비를 설치해야 합니다.
  • Page 111 Appendix B: Standardized Warning Statements Attention La mise au rebut ou le recyclage de ce produit sont généralement soumis à des lois et/ou directives de respect de l'environnement. Renseignez-vous auprès de l'organisme compétent. ‫סילוק המוצר‬ !‫אזהרה‬ .‫סילוק סופי של מוצר זה חייב להיות בהתאם להנחיות וחוקי המדינה‬ ‫التخلص...
  • Page 112 SuperServer 5029C-TN2 User's Manual Warnung Gefährlich Bewegende Teile. Von den bewegenden Lüfterblätter fern halten. Die Lüfter drehen sich u. U. noch, wenn die Lüfterbaugruppe aus dem Chassis genommen wird. Halten Sie Finger, Schraubendreher und andere Gegenstände von den Öffnungen des Lüftergehäuses entfernt.
  • Page 113 Verbindungskabeln, Stromkabeln und/oder Adapater, die Ihre örtlichen Sicherheitsstandards einhalten. Der Gebrauch von anderen Kabeln und Adapter können Fehlfunktionen oder Feuer verursachen. Die Richtlinien untersagen das Nutzen von UL oder CAS zertifizierten Kabeln (mit UL/CSA gekennzeichnet), an Geräten oder Produkten die nicht mit Supermicro gekennzeichnet sind.
  • Page 114 ‫حجم املوصل والقابس السليم. استخدام أي كابالت ومحوالت أخرى قد يتسبب يف عطل أو حريق. يحظر قانون السالمة لألجهزة الكهربائية واملعدات استخدام الكابالت املعتمدة‬ ‫ من قبل‬UL ‫ أو‬CSA ‫( والتي تحمل عالمة‬UL/CSA) ‫ مع أي معدات أخرى غري املنتجات املعنية واملحددة من قبل‬Supermicro.
  • Page 115 사항을 준수하여 제공되거나 지정된 연결 혹은 구매 케이블, 전원 케이블 및 AC 어댑터를 사용하십시오. 다른 케이블이나 어댑터를 사용하면 오작동이나 화재가 발생할 수 있습니다. 전기 용품 안전법은 UL 또는 CSA 인증 케이블 (코드에 UL / CSA가 표시된 케이블)을 Supermicro 가 지정한 제품 이외의 전기 장치에 사용하는 것을 금지합니다. Stroomkabel en AC-Adapter...

  • Page 116: Appendix C System Specifications

    Memory Up to 32GB of DDR4 Non-ECC SO-DIMM with speeds of up to 2666MHz in two slots. Note: See the memory section in Chapter 3 for details and the Supermicro website for updates to supported memory. SATA Controller SATA 3.0 (6Gbps) from Intel SoC Drive Bays Four 3.5"...
  • Page 117 Appendix C: System Specifications Regulatory Compliance Electromagnetic Emissions: FCC Class B, EN 55032 Class B, EN 61000-3-2/3-3, CISPR 32 Class B Electromagnetic Immunity: EN 55024/CISPR 24, (EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, EN 61000-4-11) Safety: CSA/EN/IEC/UL 60950-1 Compliant, UL or CSA Listed (USA and Canada), CE Marking (Europe) Other: VCCI-CISPR 32 and AS/NZS CISPR 32 Environmental: Directive 2011/65/EU and Directive 2012/19/EU...

  • Page 118: Appendix D Uefi Bios Recovery

    Warning: Do not upgrade the BIOS unless your system has a BIOS-related issue. Flashing the wrong BIOS can cause irreparable damage to the system. In no event shall Supermicro be liable for direct, indirect, special, incidental, or consequential damages arising from a BIOS update.
  • Page 119 USB device or a writable CD/DVD. Note 1: If you cannot locate the "Super.ROM" file in your drive disk, visit our website www.supermicro.com to download the BIOS package. Extract the BIOS binary im- age into a USB flash device and rename it "Super.ROM" for the BIOS recovery use.
  • Page 120 SuperServer 5029C-TN2 User's Manual 3. After locating the healthy BIOS binary image, the system will enter the BIOS Recovery menu as shown below. Note: At this point, you may decide if you want to start the BIOS recovery. If you decide to proceed with BIOS recovery, follow the procedures below.
  • Page 121 Appendix D: UEFI BIOS Recovery 5. After the BIOS recovery process is complete, press any key to reboot the system. 6. Using a different system, extract the BIOS package into a USB flash drive. 7. Press <Del> continuously during system boot to enter the BIOS Setup utility. From the top of the tool bar, select Boot to enter the submenu.
  • Page 122 SuperServer 5029C-TN2 User's Manual 8. When the UEFI Shell prompt appears, type fs# to change the device directory path. Go to the directory that contains the BIOS package you extracted earlier from Step 6. Enter flash.nsh BIOSname.### at the prompt to start the BIOS update process.
