  • Page 1 UPER ERVER ® 5028TK-HTR 5028TK-HTTR User's Manual Revision 1.0a...
  • Page 2 This product, including software and documentation, is the property of Supermicro and/or its licensors, and is supplied only under a license. Any use or reproduction of this product is not allowed, except as expressly permitted by the terms of said license.
  • Page 3 Preface Preface About This Manual This manual is written for professional system integrators and PC technicians. It provides information for the installation and use of the SuperServer 5028TK-HTR/HTTR. Installation and maintenance should be performed by experienced technicians only. The SuperServer 5028TK-HTR/HTTR is a high-end server based on the SC827HQ+-R2K04BP2 2U rackmount chassis and the single processor K1SPi/K1SPi-T serverboard.
  • Page 4 SUPERSERVER 5028TK-HTR/HTTR User's Manual Chapter 6: Advanced Chassis Setup Refer to Chapter 6 for detailed information on the SC827HQ+-R2K04BP2 server chassis. You should follow the procedures given in this chapter when installing, removing or reconfiguring hard drives and when replacing system power supply units and cooling fans.
  • Page 5 SUPERSERVER 5028TK-HTR/HTTR User's Manual Notes...

  • Page 6: Table Of Contents

    System Power ....................1-3 Front Control Panel ..................1-3 Cooling System ....................1-3 Air Shrouds ..................... 1-4 Mounting Rails ....................1-4 Contacting Supermicro ..................1-6 2U Twin : System Notes ................. 1-7 Nodes ......................1-7 System Power ....................1-7 Hard Drive Backplane/Drives ................1-7 Chapter 2 Server Installation Overview ......................
  • Page 7 Table of Contents Outer Rack Rails ..................... 2-6 Chapter 3 System Interface Overview ......................3-1 Control Panel Button ..................3-2 Power ......................3-2 Control Panel LEDs ..................3-2 Overheat ......................3-2 NIC1 ........................ 3-2 Drive Carrier LEDs ..................3-3 SATA Drives ....................3-3 SAS Drives ......................
  • Page 8 SUPERSERVER 5028TK-HTR/HTTR User's Manual Connector Definitions ..................5-8 Jumper Settings .................... 5-10 Explanation of Jumpers ................5-10 5-10 Onboard Indicators ..................5-12 5-11 PCI-Express Slots and SATA Ports .............. 5-13 5-12 Onboard Battery .................... 5-14 Chapter 6 Advanced Chassis Setup Static-Sensitive Devices ..................
  • Page 9 Table of Contents Boot Settings ....................7-43 Save & Exit ....................7-45 Appendix A System Specifications Appendix B UEFI BIOS Recovery Instructions...
  • Page 10 SUPERSERVER 5028TK-HTR/HTTR User's Manual Notes...

  • Page 11: Chapter 1 Introduction

    One rackmount rail kit (MCP-290-00053-0N) Note: For your system to work properly, please follow the links below to download all necessary drivers/utilities and the user’s manual for your server. • Supermicro product manuals: http://www.supermicro.com/support/manuals/ • Product drivers and utilities: ftp://ftp.supermicro.com •...

  • Page 12: Serverboard Features

    Memory The K1SPi/K1SPi-T has six DIMM slots supporting up to 384 GB of RDIMM (Registered DIMM) DDR4-2400 ECC memory. See Chapter 5 for details. Note: Check the Supermicro website (www.supermicro.com) for the latest memory support information. SATA The 5028TK-HTR uses a controller integrated into the PCH C612 chipset to support eight SAS3 hard drives per node.

  • Page 13: I/O Ports

    Each of the four K1SPi/K1SPi-T serverboards in the system include two USB 3.0 ports, an IPMI LAN port and a VGA port. Note: For IPMI configuration instructions, please refer to the Embedded BMC Configuration User's Guide available at http://www.supermicro.com/support/ manuals/. Graphics Controller The K1SPi/K1SPi-T features an integrated ASpeed 2400 BMC with an integrated VGA/2D graphics controller.

  • Page 14: Air Shrouds

    SUPERSERVER 5028TK-HTR/HTTR User's Manual Air Shrouds Each node in the SC827HQ+ chassis includes one mylar air shroud per node that directs the airflow where cooling is needed on each serverboard. Always use the air shroud included with each serverboard. Mounting Rails The SC827HQ+ includes a set of quick-release rails, and can be placed in a rack for secure storage and use.
  • Page 15 Chapter 1: Introduction Figure 1-1. Intel PCH C612 Chipset: System Block Diagram Note: This is a general block diagram and may not exactly represent the features on your serverboard. See the previous pages for the actual specifications of your serverboard. This block diagram is intended for your reference only.

  • Page 16: Contacting Supermicro

    Super Micro Computer, Inc. 980 Rock Ave. San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) support@supermicro.com (Technical Support) Website: www.supermicro.com Europe Address: Super Micro Computer B.V. Het Sterrenbeeld 28, 5215 ML...

  • Page 17: Twin 2 : System Notes

    Chapter 1: Introduction 2U Twin : System Notes As a 2U Twin configuration, the SuperServer 5028TK-HTR/HTTR is a unique server system. With four system boards incorporated into a single chassis acting as four separate nodes, there are several points you should keep in mind. Nodes Each of the four serverboards act as a separate node in the system.
  • Page 18 SUPERSERVER 5028TK-HTR/HTTR User's Manual Notes...

  • Page 19: Chapter 2 Server Installation

    Chapter 2: Server Installation Chapter 2 Server Installation Overview This chapter provides a quick setup checklist to get your SuperServer 5028TK-HTR/HTTR up and running. Following these steps in the order given should enable you to have the system operational within a minimum amount of time. This quick setup assumes that your system has come to you with the processors and memory preinstalled.

  • Page 20: Warnings And Precautions

    SUPERSERVER 5028TK-HTR/HTTR User's Manual Warnings and Precautions Choosing a Setup Location • Leave enough clearance in front of the rack to enable you to open the front door completely (~25 inches) and approximately 30 inches of clearance in the back of the rack to allow for sufficient airflow and ease in servicing.

  • Page 21: Rack Mounting Considerations

    Chapter 2: Server Installation Rack Mounting Considerations Ambient Operating Temperature If installed in a closed or multi-unit rack assembly, the ambient operating temperature of the rack environment may be greater than the ambient temperature of the room. Therefore, consideration should be given to installing the equipment in an environment compatible with the manufacturer’s maximum rated ambient temperature (Tmra).

  • Page 22: Installing The System Into A Rack

    SUPERSERVER 5028TK-HTR/HTTR User's Manual Installing the System into a Rack This section provides information on installing the SC827HQ+ chassis into a rack unit with the quick-release rails provided. There are a variety of rack units on the market, which may mean the assembly procedure will differ slightly. You should also refer to the installation instructions that came with the rack unit you are using.

  • Page 23: Installing The Inner Rail Extension

    Chapter 2: Server Installation Installing the Inner Rail Extension The SC827HQ+ chassis includes a set of inner rails in two sections: inner rails and inner rail extensions. The inner rails are pre-attached to the chassis, and do not interfere with normal use of the chassis if you decide not to use a server rack. The inner rail extension is attached to the inner rail to mount the chassis in the rack.

  • Page 24: Outer Rack Rails

    SUPERSERVER 5028TK-HTR/HTTR User's Manual Outer Rack Rails Outer rails attach to the rack and hold the chassis in place. The outer rails for the SC827HQ+ chassis extend between 30 inches and 33 inches. Installing the Outer Rails to the Rack (Figure 2-3) 1.
  • Page 25 Chapter 2: Server Installation Installing the Chassis into a Rack (Figure 2-4) 1. Extend the outer rails as illustrated above. 2. Align the inner rails of the chassis with the outer rails on the rack. 3. Slide the inner rails into the outer rails, keeping the pressure even on both sides.
  • Page 26 SUPERSERVER 5028TK-HTR/HTTR User's Manual Notes...

  • Page 27: Chapter 3 System Interface

    Chapter 3: System Interface Chapter 3 System Interface Overview There are several LEDs on the control panel and on the drive carriers to keep you constantly informed of the overall status of the system. SC827HQ+ models include four front panels on the handles of the chassis which control each of the systems. This chapter explains the meanings of all LED indicators and the appropriate response you may need to take.

  • Page 28: Control Panel Button

    SUPERSERVER 5028TK-HTR/HTTR User's Manual Control Panel Button Power The main power button on each of the four control panels is used to apply or remove power from the power supply to each of the four systems in the chassis. Turning off system power with this button removes the main power, but keeps standby power supplied to the system.

  • Page 29: Drive Carrier Leds

    Chapter 3: System Interface Drive Carrier LEDs The server chassis uses SATA drives. SATA Drives Each SATA drive carrier has two LEDs. • Blue: Each Serial ATA drive carrier has a green LED. When illuminated, this green LED (on the front of the SATA drive carrier) indicates drive activity. A connection to the SATA backplane enables this LED to blink on and off when that particular drive is being accessed.
  • Page 30 SUPERSERVER 5028TK-HTR/HTTR User's Manual Notes...

  • Page 31: About Standardized Warning Statements

    Only certified technicians should attempt to install or configure components. Read this appendix in its entirety before installing or configuring components in the Supermicro chassis. These warnings may also be found on our web site at http://www.supermicro.com/ about/policies/safety_information.cfm. Warning Definition Warning! This warning symbol means danger.
  • Page 32 SUPERSERVER 5028TK-HTR/HTTR User's Manual Warnung WICHTIGE SICHERHEITSHINWEISE Dieses Warnsymbol bedeutet Gefahr. Sie befinden sich in einer Situation, die zu Verletzungen führen kann. Machen Sie sich vor der Arbeit mit Geräten mit den Gefahren elektrischer Schaltungen und den üblichen Verfahren zur Vorbeugung vor Unfällen vertraut.
  • Page 33 Warning Statements for AC Systems ‫جسذٌة‬ ‫اصابة‬ ً‫تتسبب ف‬ ‫حالة ٌوكي أى‬ ً‫اًك ف‬ ‫خطز‬ ًٌ‫ٌع‬ ‫هذا الزهز‬ !‫تحذٌز‬ ‫الذوائز‬ ‫بالوخاطز الٌاجوة عي‬ ‫ي على علن‬ ، ‫ك‬ ‫هعذات‬ ‫تعول على أي‬ ‫قبل أى‬ ‫الكهزبائٍة‬ ‫حىادث‬ ‫أي‬ ‫وقىع‬ ‫وٌع‬ ‫ل‬ ‫الىقائٍة‬...

  • Page 34: Installation Instructions

    SUPERSERVER 5028TK-HTR/HTTR User's Manual Installation Instructions Warning! Read the installation instructions before connecting the system to the power source. 設置手順書 システムを電源に接続する前に、 設置手順書をお読み下さい。 警告 将此系统连接电源前,请先阅读安装说明。 警告 將系統與電源連接前，請先閱讀安裝說明。 Warnung Vor dem Anschließen des Systems an die Stromquelle die Installationsanweisungen lesen. ¡Advertencia! Lea las instrucciones de instalación antes de conectar el sistema a la red de alimentación.

  • Page 35: Circuit Breaker

    Chapter 4: Warning Statements for AC Systems Circuit Breaker Warning! This product relies on the building's installation for short-circuit (overcurrent) protection. Ensure that the protective device is rated not greater than: 250 V, 20 A. サーキッ ト ・ ブレーカー この製品は、 短絡 （過電流） 保護装置がある建物での設置を前提としています。 保護装置の定格が250 V、...

  • Page 36: Power Disconnection Warning

    SUPERSERVER 5028TK-HTR/HTTR User's Manual ‫في‬ ‫التي تم تثبيتها‬ ‫مه الدوائرالقصيرة‬ ‫الحمايت‬ ‫معداث‬ ‫يعتمد على‬ ‫هذا المنتج‬ ‫المبنى‬ ‫أكثر من‬ ‫ليس‬ ‫وقائي‬ ‫ال‬ ‫الجهاز‬ ‫تقييم‬ ‫أن‬ ‫تأكد من‬ 20A, 250V 경고! 이 제품은 전원의 단락(과전류)방지에 대해서 전적으로 건물의 관련 설비에 의존합니다. 보호장치의 정격이 반드시 250V(볼트), 20A(암페어)를 초과하지 않도록...
  • Page 37 Chapter 4: Warning Statements for AC Systems Warnung Das System muss von allen Quellen der Energie und vom Netzanschlusskabel getrennt sein, das von den Spg.Versorgungsteilmodulen entfernt wird, bevor es auf den Chassisinnenraum zurückgreift, um Systemsbestandteile anzubringen oder zu entfernen. ¡Advertencia! El sistema debe ser disconnected de todas las fuentes de energía y del cable eléctrico quitado de los módulos de fuente de alimentación antes de tener acceso el interior del chasis para instalar o para quitar componentes de sistema.

  • Page 38: Equipment Installation

    SUPERSERVER 5028TK-HTR/HTTR User's Manual Equipment Installation Warning! Only trained and qualified personnel should be allowed to install, replace, or service this equipment. 機器の設置 トレーニングを受け認定された人だけがこの装置の設置、 交換、 またはサービスを許可 されています。 警告 只有经过培训且具有资格的人员才能进行此设备的安装、更换和维修。 警告 只有經過受訓且具資格人員才可安裝、更換與維修此設備。 Warnung Das Installieren, Ersetzen oder Bedienen dieser Ausrüstung sollte nur geschultem, qualifiziertem Personal gestattet werden.

  • Page 39: Restricted Area

    Chapter 4: Warning Statements for AC Systems Waarschuwing Deze apparatuur mag alleen worden geïnstalleerd, vervangen of hersteld door geschoold en gekwalificeerd personeel. Restricted Area Warning! This unit is intended for installation in restricted access areas. A restricted access area can be accessed only through the use of a special tool, lock and key, or other means of security.

  • Page 40: Battery Handling

    SUPERSERVER 5028TK-HTR/HTTR User's Manual ‫אזור עם גישה מוגבלת‬ !‫אזהרה‬ ‫יש להתקין את היחידה באזורים שיש בהם הגבלת גישה. הגישה ניתנת בעזרת‬ .)'‫כלי אבטחה בלבד (מפתח, מנעול וכד‬ ‫محظورة‬ ‫مناطق‬ ٍ‫نتركُبها ف‬ ‫هذه انىحذة‬ ‫تخصيص‬ ‫تم‬ ،‫أداة خاصت‬ ‫من خالل استخذاو‬ ‫فقط‬...
  • Page 41 Chapter 4: Warning Statements for AC Systems Warnung Bei Einsetzen einer falschen Batterie besteht Explosionsgefahr. Ersetzen Sie die Batterie nur durch den gleichen oder vom Hersteller empfohlenen Batterietyp. Entsorgen Sie die benutzten Batterien nach den Anweisungen des Herstellers. Attention Danger d'explosion si la pile n'est pas remplacée correctement. Ne la remplacer que par une pile de type semblable ou équivalent, recommandée par le fabricant.

  • Page 42: Redundant Power Supplies

    SUPERSERVER 5028TK-HTR/HTTR User's Manual Redundant Power Supplies Warning! This unit might have more than one power supply connection. All connections must be removed to de-energize the unit. 冗長電源装置 このユニッ トは複数の電源装置が接続されている場合があります。 ユニッ トの電源を切るためには、 すべての接続を取り外さなければなりません。 警告 此部件连接的电源可能不止一个，必须将所有电源断开才能停止给该部件供电。 警告 此裝置連接的電源可能不只一個，必須切斷所有電源才能停止對該裝置的供電。 Warnung Dieses Gerät kann mehr als eine Stromzufuhr haben. Um sicherzustellen, dass der Einheit kein trom zugeführt wird, müssen alle Verbindungen entfernt werden.

  • Page 43: Backplane Voltage

    Chapter 4: Warning Statements for AC Systems ‫امداد الطاقة‬ ‫بوحدات‬ ‫عدة اتصاالت‬ ‫جهاز‬ ‫ال‬ ‫يكون لهذا‬ ‫قد‬ ‫الكهرباء‬ ‫عن‬ ‫وحدة‬ ‫ال‬ ‫لعسل‬ ‫كافة االتصاالت‬ ‫يجب إزالة‬ 경고! 이 장치에는 한 개 이상의 전원 공급 단자가 연결되어 있을 수 있습니다. 이 장치에 전원을...

  • Page 44: Comply With Local And National Electrical Codes

    SUPERSERVER 5028TK-HTR/HTTR User's Manual Attention Lorsque le système est en fonctionnement, des tensions électriques circulent sur le fond de panier. Prendre des précautions lors de la maintenance. ‫מתח בפנל האחורי‬ !‫הרה‬ ‫אז‬ ‫קיימת סכנת מתח בפנל האחורי בזמן תפעול המערכת. יש להיזהר במהלך‬ .‫העבודה‬...

  • Page 45: Product Disposal

    Chapter 4: Warning Statements for AC Systems ¡Advertencia! La instalacion del equipo debe cumplir con las normas de electricidad locales y nacionales.Attention L'équipement doit être installé conformément aux normes électriques nationales et locales. ‫תיאום חוקי החשמל הארצי‬ !‫אזהרה‬ ‫הציוד חייבת להיות תואמת לחוקי החשמל המקומיים והארציים‬ ‫התקנת‬...

  • Page 46: Hot Swap Fan Warning

    SUPERSERVER 5028TK-HTR/HTTR User's Manual Warnung Die Entsorgung dieses Produkts sollte gemäß allen Bestimmungen und Gesetzen des Landes erfolgen. ¡Advertencia! Al deshacerse por completo de este producto debe seguir todas las leyes y reglamentos nacionales. Attention La mise au rebut ou le recyclage de ce produit sont généralement soumis à des lois et/ou directives de respect de l'environnement.
  • Page 47 Chapter 4: Warning Statements for AC Systems 当您从机架移除风扇装置，风扇可能仍在转动。小心不要将手指、螺丝起子和其他 物品太靠近风扇 警告 當您從機架移除風扇裝置，風扇可能仍在轉動。小心不要將手指、螺絲起子和其他 物品太靠近風扇。 Warnung Die Lüfter drehen sich u. U. noch, wenn die Lüfterbaugruppe aus dem Chassis genommen wird. Halten Sie Finger, Schraubendreher und andere Gegenstände von den Öffnungen des Lüftergehäuses entfernt. ¡Advertencia! Los ventiladores podran dar vuelta cuando usted quite ell montaje del ventilador del chasis.

  • Page 48: Power Cable And Ac Adapter

    Electrical Appliance and Material Safety Law prohibits the use of UL or CSA -certified cables (that have UL/CSA shown on the code) for any other electrical devices than products designated by Supermicro only. 電源コードとACアダプター 製品を設置する場合、 提供または指定された接続ケーブル、 電源コードとACアダプター...
  • Page 49 Appareils électroménagers et de loi sur la sécurité Matériel interdit l'utilisation de UL ou CSA câbles certifiés qui ont UL ou CSA indiqué sur le code pour tous les autres appareils électriques que les produits désignés par Supermicro seulement.
  • Page 50 Elektrisch apparaat en veiligheidsinformatiebladen wet verbiedt het gebruik van UL of CSA gecertificeerde kabels die UL of CSA die op de code voor andere elektrische apparaten dan de producten die door Supermicro alleen. 4-20...

  • Page 51: Chapter 5 Advanced Serverboard Setup

    Chapter 5: Advanced Serverboard Setup Chapter 5 Advanced Serverboard Setup This chapter covers the steps required to connect data and power cables and install add-on cards. All serverboard jumpers and connections are also described. A layout and quick reference chart are included in this chapter for your reference. Remember to completely close the chassis when you have finished working with the serverboard to better cool and protect the system.

  • Page 52: Connecting Cables

    SUPERSERVER 5028TK-HTR/HTTR User's Manual Connecting Cables Connecting Data Cables The cables used to transfer data from the peripheral devices have been carefully routed in preconfigured systems to prevent them from blocking the flow of cooling air that moves through the system from front to back. If you need to disconnect any of these cables, you should take care to reroute them as they were originally after reconnecting them (make sure the red wires connect to the pin 1 locations).

  • Page 53: Processor And Heatsink

    If you believe there is a hardware problem with one of these components, please contact Supermicro’s technical support team or your service contact if you have purchased a service package for this system.

  • Page 54: 5-5 Installing Memory

    Memory Support The K1SPi/K1SPi-T has six DIMM slots to support up to 384 GB of RDIMM (Registered DIMM) DDR4-2400 ECC memory. Note: Check the Supermicro website (www.supermicro.com) for the latest memory support information. Figure 5-3. DIMM Installation Release Tab...

  • Page 55: 5-6 Adding Pci Expansion Cards

    Chapter 5: Advanced Serverboard Setup Populating RDIMM/LRDIMM DDR4 Memory Modules Speed (MT/s); Voltage (V); Slots per Channel (SPC) and DIMMs per Channel (DPC) Ranks DIMM Capacity Per DIMM (GB) Type 1 Slot per Channel and Data Width 1 DPC 4 Gb 8 Gb 1.2 V RDIMM...

  • Page 56: Serverboard Details

    SUPERSERVER 5028TK-HTR/HTTR User's Manual Serverboard Details Figure 5-4. K1SPi/K1SPi-T Serverboard Layout (not drawn to scale) USB0/1(3.0) LAN1 UID_LED1 LAN2 UID SW JBR1 JLAN2 JLAN1 JUSB1 IPMI_LAN LAN CTRL BIOS FLASH JBT1 K1SPi(-T) Rev. 1.01 JVRM2 JVRM1 BIOS LICENSE XDP-CD XDP-CPU Notes •...

  • Page 57: K1Spi/K1Spi-T Quick Reference

    Chapter 5: Advanced Serverboard Setup K1SPi/K1SPi-T Quick Reference Jumper Description Default Setting JBT1 Clear CMOS/Reset BIOS Configuration See Section 5-9 JPB1 BMC Enable/Disable Pins 1-2 (Enabled) JPG1 VGA Enable/Disable Pins 1-2 (Enabled) JPL1 (K1SPi) GLAN1/GLAN2 Enable/Disable Pins 1-2 (Enabled) JPL1 (K1SPi-T) 10G LAN1/10G LAN2 Enable/Disable Pins 1-2 (Enabled) JPME2...

  • Page 58: Connector Definitions

    PMBus, LED signals, button signals, fan speed, fan PWM, 5V standby power, and 12V power. This connector is designed specifically for a Supermicro-proprietary add-on card. Refer to the layout below for the location of JF1.
  • Page 59 Chapter 5: Advanced Serverboard Setup Video Port A Video (VGA) port is located on the rear I/O panel. The VGA port is supported by the ASpeed BMC and is used to provide video and CRT display. COM Port Header A COM port header is located on the serverboard for a serial connection. Unit Identifier Switch A Unit Identifier (UID) switch is located next to the VGA port on the I/O backpanel, and a rear UID LED (UID_LED1) is located at next to the UID switch on the...

  • Page 60: Jumper Settings

    SUPERSERVER 5028TK-HTR/HTTR User's Manual Jumper Settings Connector Pins Explanation of Jumpers To modify the operation of the serverboard, Jumper jumpers can be used to choose between optional settings. Jumpers create shorts between two pins to change the function Setting of the connector. Pin 1 is identified with a square solder pad on the printed circuit board.
  • Page 61 Chapter 5: Advanced Serverboard Setup Watch Dog Enable/Disable Watch Dog (JWD1) is a system monitor that can reboot the system when a Watch Dog Jumper Settings software application hangs. Close pins Jumper Setting Definition 1-2 to reset the system if an application Pins 1-2 Reset hangs.

  • Page 62: 5-10 Onboard Indicators

    SUPERSERVER 5028TK-HTR/HTTR User's Manual 5-10 Onboard Indicators LAN 1/LAN 2 IPMI LAN Link LED Activity LED IPMI Dedicated LAN Port LEDs A dedicated IPMI LAN port is located on IPMI LAN the rear I/O panel. The amber LED on (X8ST3-F) IPMI LAN Link LED (Left) &...

  • Page 63: 5-11 Pci-Express Slots And Sata Ports

    S-SATA2 and S-SATA3, supported by Intel PCH S-SATA controller, provide SATA 3.0 connections. These yellow connectors have power pins built in and can be used with Supermicro SuperDOM (Disk-on-Module) devices. Supermicro SuperDOMs are backward-compatible with regular, non-Supermicro SATA HDDs and SATA DOMs that require external power supplies. 5-13...

  • Page 64: 5-12 Onboard Battery

    SUPERSERVER 5028TK-HTR/HTTR User's Manual 5-12 Onboard Battery Please handle used batteries carefully. Do not damage the battery in any way; a damaged battery may release hazardous materials into the environment. Do not discard a used battery in the garbage or a public landfill. Please comply with the regulations set up by your local hazardous waste management agency to dispose of your used battery properly.

  • Page 65: Chapter 6 Advanced Chassis Setup

    Chapter 6: Advanced Chassis Setup Chapter 6 Advanced Chassis Setup This chapter covers the steps required to install components and perform maintenance on the SC827HQ+-R2K04BP2 chassis. For component installation, follow the steps in the order given to eliminate the most common problems encountered.

  • Page 66: Control Panel

    SUPERSERVER 5028TK-HTR/HTTR User's Manual Figure 6-1. Front and Rear Chassis Views Control Panel Control Panel Control Panel Control Panel SATA Drives (12) Node1 Node2 Node3 Node4 Note: also see Figure 6-13. LAN Ports Low-Profile PCI-E Slot IPMI LAN Port Power Supplies USB Ports UID Switch/LED VGA Port...

  • Page 67: Chassis Cover

    Chapter 6: Advanced Chassis Setup Chassis Cover Before operating the SC827HQ+ chassis for the first time, it is important to remove the protective film covering the top of the chassis, in order to allow for proper ventilation and cooling. Removing the Chassis Cover and Protective Film (Figure 6-2) 1.

  • Page 68: Air Shrouds

    SUPERSERVER 5028TK-HTR/HTTR User's Manual Air Shrouds Air shrouds concentrate airflow to maximize fan efficiency. The SC827HQ+ chassis air shroud does not require screws to set up. The 5028TK-HTR/HTTR requires four identical air shrouds, one in each serverboard drawer (p/n MCP-310-21704-0B). See the illustration below.

  • Page 69: Checking The Airflow

    Chapter 6: Advanced Chassis Setup Checking the Airflow Checking Airflow 1. Make sure there are no objects to obstruct airflow in and out of the server. In addition, if you are using a front bezel, make sure the bezel's filter is replaced periodically.
  • Page 70 SUPERSERVER 5028TK-HTR/HTTR User's Manual Changing a System Fan 1. If necessary, open the chassis while the power is running to determine which fan has failed. (Never run the server for an extended period of time with the chassis cover open.) 2.
  • Page 71 Chapter 6: Advanced Chassis Setup Figure 6-5. Replacing a System Fan in the Fan Housing...

  • Page 72: Removing And Installing The Backplane

    SUPERSERVER 5028TK-HTR/HTTR User's Manual Removing and Installing the Backplane The SC827HQ+ chassis backplane is located behind the hard drives and in front of the front system fans. In order to change jumper settings on the backplane, it may be necessary to remove the backplane from the chassis. Removing the Backplane Removing the Backplane from the Chassis 1.
  • Page 73 Chapter 6: Advanced Chassis Setup 7. Remove the side screw from the side of the chassis (Figure 6-7). Figure 6-7. Loosening the Spring Bar Screws in the Floor of the Chassis 8. Gently ease the backplane up and out of the chassis (Figure 6-8). Figure 6-8.

  • Page 74: Installing The Backplane

    SUPERSERVER 5028TK-HTR/HTTR User's Manual Installing the Backplane Installing the Backplane into the Chassis (Figure 6-9) 1. Ensure that all of the hard drive trays have been removed from the bays in the front of the chassis and that the spring bar has been loosened as directed in the previous section.

  • Page 75: Installing The Serverboard

    Chapter 6: Advanced Chassis Setup Installing the Serverboard I/O Shield The I/O shield holds the serverboard ports in place. The I/O shield does not require installation. Permanent and Optional Standoffs Standoffs prevent short circuits by securing space between the serverboard and the chassis surface.
  • Page 76 SUPERSERVER 5028TK-HTR/HTTR User's Manual 8. Connect the cables between the serverboard, backplane, chassis, front panel, and power supply, as needed. Also, fans may be temporarily removed to allow access to the backplane ports. 9. Replace the add-on card bracket and secure the bracket with a screw. Figure 6-10.

  • Page 77: Adapter Card Replacement

    Chapter 6: Advanced Chassis Setup Adapter Card Replacement Each serverboard drawer comes equipped with an adapter card which plugs into the backplane. In the unlikely event that the adapter card needs to be replaced, installation requires only a Phillips head screwdriver. Figure 6-11.

  • Page 78: Installing An Add-On Card

    SUPERSERVER 5028TK-HTR/HTTR User's Manual Installing an Add-on Card The SC827HQ+ chassis includes I/O slots for PCI add-on cards. Each side supports one low profile/half length add-on card for a total of four per chassis, one per drawer. Installing Add-on Cards (Figure 6-12) 1.

  • Page 79: 6-10 Drive Bay Installation/Removal

    SATA drives. Proceed to the next step for instructions. You must use standard 1" high, SATA drives in the system. Note: Refer to Supermicro's web site for setup guidelines: <http://www.supermicro. com/support/manuals/>. The SC827HQ+ chassis contains four individual serverboards in separate node drawers (Figure 6-13).
  • Page 80 SUPERSERVER 5028TK-HTR/HTTR User's Manual Removing Hard Drive Trays from the Chassis (Figure 6-14) 1. Press the release button on the drive tray. This extends the drive bay handle. 2. Use the handle to pull the drive out of the chassis. Figure 6-14.
  • Page 81 Chapter 6: Advanced Chassis Setup The drives are mounted in drive carriers to simplify their installation and removal from the chassis (Figure 6-15). These carriers also help promote proper airflow for the drive bays. Figure 6-15. Chassis Drive Tray Dummy Drive Drive Tray Installing a Drive into the Hard Drive Tray 1.
  • Page 82 Figure 6-17. Installing the Hard Drive SATA Hard Drive Drive Tray Caution: Enterprise level hard disk drives are recommended for use in Supermicro chassis and servers. For information on recommended HDDs, visit the Supermicro website at http://www.supermicro.com/products/nfo/files/storage/SAS-CompList.pdf 6-18...

  • Page 83: 6-11 Power Supply

    Replacement units can be ordered directly from Supermicro (See the contact information in the Preface of this manual). Changing the Power Supply (Figure 6-18) 1.
  • Page 84 SUPERSERVER 5028TK-HTR/HTTR User's Manual Figure 6-18. Changing the Power Supply Release Tab 6-20...

  • Page 85: Chapter 7 Bios

    When an option is selected in the left frame, it is highlighted in white. Often a text message will accompany it. Note: The AMI BIOS has default text messages built in. Supermicro retains the option to include, omit, or change any of these text messages.

  • Page 86: How To Change The Configuration Data

    Warning: Do not upgrade the BIOS unless your system has a BIOS-related issue. Flashing the wrong BIOS can cause irreparable damage to the system. In no event shall Supermicro be liable for direct, indirect, special, incidental, or consequential damages...

  • Page 87: Main Setup

    Day MM/DD/YYYY format. The time is entered in HH:MM:SS format. Note: The time is in the 24-hour format. For example, 5:30 P.M. appears as 17:30:00. Supermicro K1SPi(-T) BIOS Version: This item displays the version of the BIOS ROM used in the system.

  • Page 88: Advanced Setup Configurations

    SUPERSERVER 5028TK-HTR/HTTR User's Manual Advanced Setup Configurations Use the arrow keys to select Advanced setup and press <Enter> to access the submenu items: Warning: Take Caution when changing the Advanced settings. An incorrect value, DRAM frequency or BIOS timing setting may cause the system to malfunction. When this occurs, restore the setting to the manufacture default setting.
  • Page 89 Chapter 7: BIOS Wait For 'F1' If Error Select Enabled to force the system to wait until the 'F1' key is pressed if an error occurs. The options are Disabled and Enabled. INT19 (Interrupt 19) Trap Response Interrupt 19 is the software interrupt that handles the boot disk function. When this item is set to Immediate, the ROM BIOS of the host adaptors will "capture"...
  • Page 90 SUPERSERVER 5028TK-HTR/HTTR User's Manual CPU Configuration  This submenu displays the following CPU information as detected by the BIOS. It also allows the user to configure CPU settings. Per-Socket Configuration  • Processor Socket • Processor ID • Processor Frequency •...
  • Page 91 Chapter 7: BIOS VMX (Available when supported by the CPU and the OS) Select Enable for CPU-related Virtualization support. This feature is used in conjunc- tion with the items: "Clear MCA," "Enable SMX," and "Lock Chipset" for Virtualization media support. The options are Enable and Disable. PPIN Control Select Unlock/Enable to use the Protected-Processor Inventory Number (PPIN) in the system.
  • Page 92 SUPERSERVER 5028TK-HTR/HTTR User's Manual Advanced Power Management Configuration (Available  when supported by your system) Advanced Power Management Configuration CPU PM (Power Management) Tuning If this feature is set to Auto, CPU power management tuning will be performed automatically, and all bits in the MRS 1F0h table will maintain the value of P0. The options are Auto and Manual.
  • Page 93 Chapter 7: BIOS SPD (Serial Presence Detect) Select Enable for SPD support, which will allow the BIOS to access and use memory information that is stored in an EEPROM (electrically erasable programmable read- only memory) chip to properly configure memory modules upon bootup to maximize system memory performance.
  • Page 94 SUPERSERVER 5028TK-HTR/HTTR User's Manual PROCHOT# Response This feature allows the CPU to throttle to a lower power state by asserting a PRO- CHOT# (Number). Select Pn Clamping for maximum efficiency frequency. Select PM Clamping for minimum efficiency frequency. The options are Pm Clamping and Pn Clamping.
  • Page 95 Chapter 7: BIOS Pkg Clmp Lim2 (Package Clamping Limit2) Use this item to set the limit on power performance states for the processor op- erating in turbo mode, with P0 being the state with the highest frequency (clock speed) and power (consumption), and P1, a step lower in performance than P0, with its frequency and voltage scaled back a notch.
  • Page 96 SUPERSERVER 5028TK-HTR/HTTR User's Manual Socket 0 PCIeD00F0 - Port 0/DIM This section allows the user to configure the settings for Socket 0 PCIeD00F0- Port 0/DMI Link Speed This item configures the link speed of a PCI-E port specified by the user. The options are Gen 1 (Generation 1) (2.5 GT/s), Gen 2 (Generation 2) and Auto.
  • Page 97 Chapter 7: BIOS L0s Support When this item is set to Disable, II0 will not put its transmitter in the L0s state. The options are Disable and Enable. IOAT (Intel® IO Acceleration) Configuration Relaxed Ordering Select Enable to enable Relaxed Ordering support which will allow certain transactions to violate the strict-ordering rules of PCI bus for a transaction to be completed prior to other transactions that have already been enqueued.
  • Page 98 SUPERSERVER 5028TK-HTR/HTTR User's Manual SLD WA Revision This item allows the user to determine how SLD WA revision is to be done. The default setting is Auto. Rx Clock WA Select Enable to use Rx Clock WA revision. The options are Disable and Enable. PCI-E ASPM Support Select Enable to support the Active State Power Management (ASPM) level for a PCI-E port specified by the user.
  • Page 99 Chapter 7: BIOS Uncore Configuration Use this feature to configure the settings for the Muliti-Channel DRAMs (MCDRAMs) that reside in the KL series processor. The MCDRAM is a high- bandwidth, high-frequency DRAM and can be configured for multi-functional use. Each KL processor contains up to eight MCDRAMs in the processor package, and each MCDRAM works in conjunction with an OPIO (On-Package IO), which acts as a controller for the MCDRAM.
  • Page 100 SUPERSERVER 5028TK-HTR/HTTR User's Manual from system configuration. This operation will increase system boot time. The options are Enable and Disable. MCDRAM Diagnostics Select Enable to allow the BIOS or the OS to do a diagnosis to determine if a repair is needed for an MCDRAM. During the process of diagnosis, the MCDRAM will not be taken out from system configuration.
  • Page 101 Chapter 7: BIOS Memory Frequency Use this feature to set the maximum memory frequency for onboard memory modules. The options are Auto, 1600, 1867, 2133, and 2400. Attempt Fast Cold Boot Select Enabled to skip a portion of memory reference codes whenever possible in an attempt to increase bootup speed.
  • Page 102 SUPERSERVER 5028TK-HTR/HTTR User's Manual Memory RAS (Reliability_Availability_Serviceability) Configuration Use this submenu to configure the following Memory RAS settings. Patrol Scrub Patrol Scrubbing is a process that allows the CPU to correct correctable memory errors detected on a memory module and send the correction to the requestor (the original source).
  • Page 103 Chapter 7: BIOS XHCI Hand-Off This is a work-around solution for operating systems that do not support XHCI (Ex- tensible Host Controller Interface) hand-off. The XHCI ownership change should be claimed by the XHCI driver. The settings are Enabled and Disabled. EHCI Hand-Off This item is for operating systems that do not support Enhanced Host Controller Interface (EHCI) hand-off.
  • Page 104 SUPERSERVER 5028TK-HTR/HTTR User's Manual SATA Configuration  When this submenu is selected, AMI BIOS automatically detects the SATA devices installed in the system and displays the following items: SATA Controller This item enables or disables the onboard SATA controller. The options are Enabled and Disabled.
  • Page 105 Chapter 7: BIOS (Port 0~ Port 5 ) SATA Device Type Use this item to specify if the SATA port specified by the user should be con- nected to a Solid State drive or a Hard Disk Drive. The options are Hard Disk Drive and Solid State Drive.
  • Page 106 SUPERSERVER 5028TK-HTR/HTTR User's Manual (Port 0~ Port 5 ) Hot Plug Select Enabled to enable hot-plugging support for a port specified by the user, which will allow the user to replace a SATA disk drive installed on this port without shutting down the system.
  • Page 107 Chapter 7: BIOS • Software Preserve Support Port 0~ Port 5 Select Enabled to enable an sSATA port specified by the user. The options are Disabled and Enabled. (Port 0~ Port 5 ) Hot Plug Select Enabled to enable hot-plugging support for a port specified by the user, which will allow the user to replace an sSATA disk drive installed on this port without shutting down the system.
  • Page 108 SUPERSERVER 5028TK-HTR/HTTR User's Manual (Port 0~ Port 5 ) sSATA Device Type (Available when an sSATA port is detected) Use this item to specify if the sSATA port specified by the user should be con- nected to a Solid State drive or a Hard Disk Drive. The options are Hard Disk Drive and Solid State Drive.
  • Page 109 Chapter 7: BIOS Server ME (Management Engine) Configuration This feature displays the following system ME configuration settings. • General ME Configuration • Operational Firmware Version • ME Firmware Type • ME Firmware Version • ME Firmware Features • ME Firmware Status #1 •...
  • Page 110 SUPERSERVER 5028TK-HTR/HTTR User's Manual SR-IOV (Available if the system supports Single-Root Virtualization) Select Enabled for Single-Root IO Virtualization support. The options are Enabled and Disabled. ASPM Support Select Enable to support the Active State Power Management (ASPM) level for a PCI-E port specified by the user.
  • Page 111 Chapter 7: BIOS Ipv4 PXE Support (Available when Network Stack is set to Enabled) Select Enabled to enable Ipv4 PXE (Preboot Execution Environment) for boot sup- port. If this feature is set to Disabled, Ipv4 PXE boot option will not be supported. The options are Enabled and Disabled.
  • Page 112 SUPERSERVER 5028TK-HTR/HTTR User's Manual Serial Port Console Redirection  COM 1 COM 1 Console Redirection Select Enabled to enable COM Port 1 Console Redirection, which will allow a client machine to be connected to a host machine at a remote site for networking. The options are Disabled and Enabled.
  • Page 113 Chapter 7: BIOS Flow Control Use this item to set the flow control for Console Redirection to prevent data loss caused by buffer overflow. Send a "Stop" signal to stop sending data when the receiving buffer is full. Send a "Start" signal to start sending data when the receiving buffer is empty.
  • Page 114 SUPERSERVER 5028TK-HTR/HTTR User's Manual SOL/COM2 Console Redirection Settings Use this feature to specify how the host computer will exchange data with the client computer, which is the remote computer used by the user. Terminal Type Use this feature to select the target terminal emulation type for Console Redirec- tion.
  • Page 115 Chapter 7: BIOS VT-UTF8 Combo Key Support Select Enabled to enable VT-UTF8 Combination Key support for ANSI/VT100 terminals. The options are Enabled and Disabled. Recorder Mode Select Enabled to capture the data displayed on a terminal and send it as text messages to a remote server.
  • Page 116 SUPERSERVER 5028TK-HTR/HTTR User's Manual EMS Console Redirection Settings (Available when EMS Console Redirection is enabled) Use this feature to specify how the host computer will exchange data with the client computer, which is the remote computer used by the user. Out-of-Band Management Port The feature selects a serial port in a client server to be used by the Windows Emergency Management Services (EMS) to communicate with a remote host...
  • Page 117 Chapter 7: BIOS Enabling TPM in the BIOS The steps below describe the proper procedure on how to enable the TPM in the BIOS. This process is necessary to activate support in the system before you can start using the TPM. 1.
  • Page 118 SUPERSERVER 5028TK-HTR/HTTR User's Manual ACPI Settings WHEA Support Select Enabled to support the Windows Hardware Error Architecture (WHEA) plat- form and provide a common infrastructure for the system to handle hardware errors within the Windows OS environment to reduce system crashes and to enhance system recovery and health monitoring.
  • Page 119 Chapter 7: BIOS iSCSI Configuration This item displays iSCSI configuration information: iSCSI Initiator Name Use this item to enter the name of the iSCSI Initiator, which is a unique name used in the world. The name must in the IQN format. The following submenu will be available for configuration: ...

  • Page 120: Event Logs

    SUPERSERVER 5028TK-HTR/HTTR User's Manual Event Logs Use this feature to configure Event Log settings. Change SMBIOS Event Log Settings  This feature allows the user to configure SMBIOS Event settings. Enabling/Disabling Options SMBIOS Event Log Select Enabled to enable SMBIOS (System Management BIOS) Event Logging during system boot.
  • Page 121 Chapter 7: BIOS When Log is Full Select Erase Immediately to immediately erase all errors in the SMBIOS event log when the event log is full. Select Do Nothing for the system to do nothing when the SMBIOS event log is full. The options are Do Nothing and Erase Immediately. SMBIOS Event Log Standard Settings Log System Boot Event Select Enabled to log system boot events.

  • Page 122: Ipmi

    SUPERSERVER 5028TK-HTR/HTTR User's Manual IPMI Use this feature to configure Intelligent Platform Management Interface (IPMI) settings. BMC (BaseBoard Management Controller) Firmware Revision This item indicates the BMC firmware revision used in your system. IPMI Status This item indicates the status of the IPMI firmware installed in your system. System Event Log ...
  • Page 123 Chapter 7: BIOS When SEL is Full This feature allows the user to determine what the AMI BIOS should do when the system event log is full. Select Erase Immediately to erase all events in the log when the system event log is full. The options are Do Nothing and Erase Immediately. Note: After making changes on a setting, be sure to reboot the system for the changes to take effect.

  • Page 124: Security Settings

    SUPERSERVER 5028TK-HTR/HTTR User's Manual VLAN Select Enabled to enable IPMI VLAN function support. The options are Enabled and Disabled. Security Settings This menu allows the user to configure the following security settings for the system. Password Check Select Setup for the system to prompt for a password upon entering the BIOS setup utility.
  • Page 125 Chapter 7: BIOS Secure Boot Menu  The following items will display: • System Mode • Secure Boot • Vendor Keys Secure Boot Control Select Enable for secure boot support to ensure system security at bootup. The options are Enabled and Disabled. Secure Boot Mode This item allows the user to select the desired secure boot mode for the system.
  • Page 126 SUPERSERVER 5028TK-HTR/HTTR User's Manual Authorized Signatures  This feature allows the user to set and save authorized signatures and grant access to those whose names appear on the list. Forbidden Signatures  This feature allows the user to set and save the forbidden signatures and deny the access to those whose names appear on the list.

  • Page 127: Boot Settings

    Chapter 7: BIOS Boot Settings Use this feature to configure Boot Settings: Boot Configuration Boot Mode Select Use this item to select the type of device to be used for system boot. The options are Legacy, UEFI, and Dual. Fixed Boot Order Priorities This option prioritizes the order of a bootable device from which the system will boot.
  • Page 128 SUPERSERVER 5028TK-HTR/HTTR User's Manual  Add New Driver Option Use this item to select a new driver to add to the boot priority list. Add Driver Option Use this feature to select the target driver to add to the boot priority list. Path for Driver Option Use this feature to create a new driver path for boot option.
  • Page 129 Chapter 7: BIOS Save & Exit Select the Save & Exit tab from the BIOS setup screen to configure the settings below. Discard Changes and Exit Select this option to quit the BIOS setup without making any permanent changes to the system configuration, and exit from the BIOS setup utility. Save Changes and Reset After you have made all changes on the BIOS settings, select this option to save the changes you've made and then reboot the computer for the new system con-...
  • Page 130 SUPERSERVER 5028TK-HTR/HTTR User's Manual Save As User Defaults Select this item and press <Enter> to save the current BIOS settings as user's default settings for future use. Restore User Defaults Select this item and press <Enter> to retrieve user-defined settings that were previ- ously saved for future use.
  • Page 131 Each node has six DIMM slots supporting up to 384 GB of RDIMM (Registered DIMM) DDR4-2400 ECC memory Note: refer to Section 5-5 for details on installation and the Supermicro website for the latest memory support information. SATA Drive Bays Twelve hot-swap drive bays to house 3.5"...
  • Page 132 SUPERSERVER 5028TK-HTR/HTTR User's Manual Weight Gross (Bare Bone): 88 lbs. (40 kg.) System Cooling The system has four 8-cm PWM cooling fans System Input Requirements AC Input Voltage: 100-240V AC auto-range Rated Input Current: 16-12A (110-140V), 12.5-9.5A (180-240V) Rated Input Frequency: 50 to 60 Hz Efficiency: 80+ (Platinum Level) Power Supply Rated Output Power: 2000W (Part# PWS-2K04A-1R) (redundant, hot-plug)
  • Page 133 Appendix A: System Specifications Notes...
  • Page 134 SUPERSERVER 5028TK-HTR/HTTR User's Manual (continued from front) The products sold by Supermicro are not intended for and will not be used in life support systems, medical equipment, nuclear facilities or systems, aircraft, aircraft devices, aircraft/emergency communication devices or other critical systems whose failure to perform be reasonably expected to result in significant injury or loss of life or catastrophic property damage.
  • Page 135 Flashing the wrong BIOS can cause irreparable damage to the system. In no event shall Supermicro be liable for direct, indirect, special, incidental, or consequential damages arising from a BIOS update. If you need to update the BIOS, do not shut down or reset the system while the BIOS is updating to avoid possible boot failure.
  • Page 136 SUPERSERVER 5028TK-HTR/HTTR User's Manual Note: If you cannot locate the "Super.ROM" file in your driver disk, visit our website at www.supermicro.com to download the BIOS image to a USB flash device and rename it "Super ROM". 2. Insert the USB device that contains the new BIOS image ("Super.ROM") into your USB drive and power on the system 3.
  • Page 137 Appendix B: UEFI BIOS Recovery 6. After the process has completed, press any key to reboot the system. 7. Using a different system, extract the BIOS package into a bootable USB flash drive. 8. When the DOS prompt appears, enter AMI.BAT BIOSname.###. Note: Do not interrupt this process until BIOS flashing has completed.
  • Page 138 SUPERSERVER 5028TK-HTR/HTTR User's Manual 9. After receiving the message that the BIOS update is complete, unplug the AC power cable from the power supply to clear CMOS, then plug the AC power cable in the power supply again to power on the system. 10.

This manual is also suitable for:

Superserver 5028tk-htr

Table of Contents
