SuperServer
®
5029C-T
USER'S MANUAL
Revision 1.0a

Advertisement

Table of Contents
loading

Related Manuals for Supermicro SuperServer 5029C-T

Summary of Contents for Supermicro SuperServer 5029C-T

  • Page 1 SuperServer ® 5029C-T USER’S MANUAL Revision 1.0a...
  • Page 2 State of California, USA. The State of California, County of Santa Clara shall be the exclusive venue for the resolution of any such disputes. Supermicro's total liability for all claims will not exceed the price paid for the hardware product.
  • Page 3 About this Manual This manual is written for professional system integrators and PC technicians. It provides information for the installation and use of the SuperServer 5029C-T. Installation and maintenance should be performed by experienced technicians only. Please refer to the 5029C-T server specifications page on our website for updates on supported memory, processors and operating systems (http://www.supermicro.com).

  • Page 4: Table Of Contents

    SuperServer 5029C-T User's Manual Contents Chapter 1 Introduction 1.1 Overview ..........................7 1.2 System Features ........................8 1.3 Chassis Features .........................9 Front Features ........................9 Rear Features ........................11 Rear I/O Ports ........................12 1.4 Motherboard Layout ......................13 Quick Reference Table ......................14 System Block Diagram ......................16 Chapter 2 Maintenance and Component Installation 2.1 Removing Power ........................17...
  • Page 5 Preface 2.5 Chassis Components ......................31 Front-Mounted Hot-Swap Drives ..................31 Installing the Internal Fixed Hard Drives .................33 Adding an M.2 Storage Card ....................35 Installing a DVD Drive ......................37 Installing a Fan ........................39 Replacing the Power Supply .....................40 Chapter 3 Motherboard Connections 3.1 Power Connections ......................41 3.2 Headers and Connectors ....................42 3.3 Ports ...........................45...
  • Page 6 SuperServer 5029C-T User's Manual Contacting Supermicro Headquarters Address: Super Micro Computer, Inc. 980 Rock Ave. San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) support@supermicro.com (Technical Support) Website: www.supermicro.com Europe Address: Super Micro Computer B.V.

  • Page 7: Chapter 1 Introduction

    Chapter 1 Introduction 1.1 Overview The SuperServer 5029C-T is a compact, server system comprised of the SC721TQ-250B2 chassis and the X11SCL-IF single processor motherboard. Refer to our website for information on operating systems that have been certified for use with the system (www.supermicro.com).

  • Page 8: System Features

    SuperServer 5029C-T User's Manual 1.2 System Features The following table provides an overview of the main features of the 5029C-T. System Features Motherboard X11SCL-IF Chassis SC721TQ-250B2 Supports single Intel® Xeon E Family/ 8th Intel Core i3/ Pentium/ Celeron Processor, up to 6 cores in Socket H4 (LGA 1511), 80W max.

  • Page 9: Chassis Features

    Chapter 1: Introduction 1.3 Chassis Features Front Features The SC721TQ-250B2 is a compact Mini Tower chassis. The front of the chassis includes a power on/off push-button, a reset button and several LEDs as described below. Figure 1-1. Chassis Front View...
  • Page 10 SuperServer 5029C-T User's Manual Front Chassis Features Item Feature Description The power button applies or removes power to the system. Turning off power removes Power Button the main power but keeps standby power supplied to the system. Reset Button Restarts the system USB3.1 Gen1 ports...

  • Page 11: Rear Features

    Chapter 1: Introduction Rear Features The rear of the chassis has various input/output ports. Figure 1-2. Chassis Rear View Rear Chassis Features Item Feature Description Power Supply Fixed module I/O Backpanel Rear input/output ports PCI-E Slots Supports four full-height, full-length PCI-E expansion cards Kensington Security Slot Supports a Kensington lock to prevent from theft.

  • Page 12: Rear I/O Ports

    SuperServer 5029C-T User's Manual Rear I/O Ports Figure 1-3. Rear input/Output Ports Rear I/O Ports Description Description COM1 USB4 (USB 3.1 Gen 1) Dedicated IPMI LAN LAN2 USB1 LAN1 USB0 VGA Port USB5 (USB 3.1 Gen 1) UID Switch...

  • Page 13: Motherboard Layout

    Chapter 1: Introduction 1.4 Motherboard Layout Jumper, connector and LED locations are shown below with brief descriptions on the following page. Detailed descriptions are found in Chapter 3. USB4/5 (3.0) IPMI_LAN COM1 JUIDB1 LAN1/2 USB0/1 LED4 LED4 COM1 FAN3 Intel i210 USB4/5 JPW2...

  • Page 14: Quick Reference Table

    SuperServer 5029C-T User's Manual Quick Reference Table Jumper Description Default Setting JBT1 CMOS Clear Open (Normal) JPG1 VGA Enable Pins 1-2 (Enabled) JPL1, JPL2 LAN1, LAN2 Enable Pins 1-2 (Enabled) JPME2 ME Manufacturing Mode Pins 1-2 (Normal) JWD1 Watchdog Timer...
  • Page 15 Chapter 1: Introduction Connector Description Onboard Buzzer USB0/1 Back Panel Universal Serial Bus (USB) 2.0 Ports USB2/3 Front Accessible USB 2.0 Header USB4/5 Back Panel USB 3.1 Gen 1 Ports USB6/7 Front Accessible USB 3.1 Gen 1 Header USB8 USB 3.1 Gen 1 Type-A Header VGA Port...

  • Page 16: System Block Diagram

    SuperServer 5029C-T User's Manual System Block Diagram SVID IMVP8 VR DDR4 (CHA) INTEL LGA1151 DIMMA1 CPU_PE3_P0~P15 2133/2400/2666MHz PCIe x16 SLOT #6 (65W / 71 W / 80W / 95W) DDR4 (CHB) DIMMB1 2133/2400/2666MHz x4 DMI3 8GT/s PCIEX4 M.2 M-KEY SATA III*1...

  • Page 17: Chapter 2 Maintenance And Component Installation

    Chapter 2 Maintenance and Component Installation Chapter 2 Maintenance and Component Installation This chapter provides instructions on installing and replacing main system components. To prevent compatibility issues, only use components that match the specifications and/or part numbers given. Installation or replacement of most components requires that power first be removed from the system.

  • Page 18: Rear Chassis Hasp

    SuperServer 5029C-T User's Manual Figure 2-1. Front Bezel Lock Rear Chassis Hasp Unauthorized entry through the rear of the chassis may be discouraged by placing a lock on the rear of the chassis. The chassis is equipped with a rear chassis hasp that can accomodate a variety of commonly available locks (not included).

  • Page 19: Accessing The System

    Chapter 2 Maintenance and Component Installation 2.3 Accessing the System The SC721TQ-250B2 features a removable top cover to access to the inside of the chassis. Figure 2-4. Removing the Chassis Cover Removing the Top Cover 1. Power down the system as described in section 2.1. 2.

  • Page 20: Motherboard Components

    SuperServer 5029C-T User's Manual 2.4 Motherboard Components Processor The 5029C-T supports a single Intel® Xeon E-2100, 8th Generation Core i3, Pentium, or Celeron Processor. Notes: • When handling the processor package, avoid placing direct pressure on the label area of the fan.
  • Page 21 Chapter 2 Maintenance and Component Installation 3. Locate the triangle on the CPU and CPU socket, which indicates the location of Pin 1. Holding the CPU by the edges with your thumb and index finger, align the triangle on the CPU with the triangle on the socket. The CPU keys (the semi-circle cutouts) may also be aligned against the socket keys as a guide.

  • Page 22: Heatsink

    SuperServer 5029C-T User's Manual Heatsink Installing the CPU Heatsink Do not apply thermal grease to the heatsink or the CPU--the required amount has already been applied. Use an Intel-certified multi-directional heatsink. 1. Power down the system as described in Section 2.1 and remove the chassis cover.

  • Page 23: Installing The Air Shroud

    Chapter 2 Maintenance and Component Installation Installing the Air Shroud 1. Position the air shroud onto the heatsink with the wide side facing toward the inside of the chassis. Figure 2-6. Positioning the Air Shroud 2. Clip both hooks on the top of the air shroud onto the top fin of the heatsink properly. 3.
  • Page 24 SuperServer 5029C-T User's Manual 4. Push the rear tray back into the the chassis. Figure 2-8. Pushing the Rear Tray Back Into the Chassis...

  • Page 25: Removing The Heatsink

    Chapter 2 Maintenance and Component Installation Removing the Heatsink Note: We do not recommend that the CPU or the heatsink be removed. However, if you must remove the heatsink, follow the instructions below to avoid damage. 1. Remove power from the system as described in Section 3.1. 2.

  • Page 26: Memory Support

    Memory Support The motherboard supports up to 32GB of unbuffered (UDIMM) DDR4 (288-pin) ECC memory with speeds of up to 2666MHz in two memory slots. Check the Supermicro website for a list of memory modules that have been validated. Installing Memory Caution: Exercise extreme care when installing or removing DIMM modules to prevent damage.

  • Page 27: Dimm Installation

    Chapter 2 Maintenance and Component Installation DIMM Installation 1. Insert the desired number of DIMMs into the memory slots based on the recommended DIMM population table . 2. Push the release tabs outwards on both ends of the DIMM slot to unlock it. 3.

  • Page 28: Installing Expansion Cards

    SuperServer 5029C-T User's Manual Installing Expansion Cards The 5029C-T includes a PCI-E 3.0 x4 slot for an expansion card. The card is installed by removing the chassis tray that holds the motherboard and rear I/O shield. Installing an Expansion Card 1.
  • Page 29 Chapter 2 Maintenance and Component Installation 4. Remove the screw that secures the PCI slot shield in the PCI slot at the rear of the tray and set it aside for later use. 5. Slide the PCI slot shield up and out of the PCI slot. 6.

  • Page 30: Motherboard Battery

    SuperServer 5029C-T User's Manual Motherboard Battery The motherboard uses non-volatile memory to retain system information when system power is removed. This memory is powered by a lithium battery residing on the motherboard. LITHIUM BATTERY BATTERY HOLDER Figure 2-12. Installing the Onboard Battery Replacing the Battery 1.

  • Page 31: Chassis Components

    Chapter 2 Maintenance and Component Installation 2.5 Chassis Components Front-Mounted Hot-Swap Drives The SC721TQ-250B2 supports four hot-swappable drives mounted in carriers that are accessible from the front of the chassis. These drives may be removed and installed without powering down the system. Removing 3.5"...
  • Page 32 SuperServer 5029C-T User's Manual Hard Drive Dummy Drive Hard Drive Carrier Figure 2-14. Installing a Hard Drive into a Drive Carrier Installing a Drive Carrier into the Hard Drive Cage 1. Insert the hard drive carrier into the drive bay, using the drive carrier handle to push it all the way into the hard drive cage until it stops.

  • Page 33: Installing The Internal Fixed Hard Drives

    Chapter 2 Maintenance and Component Installation Installing the Internal Fixed Hard Drives The SC721TQ-250B2 chassis supports two internal 2.5" SATA fixed hard drives: one top- mounted drive and one side-mounted drive. Installing a Top-Mounted Fixed Hard Drive 1. Power down the system as described in Section 2.1 and remove the chassis cover. 2.
  • Page 34 SuperServer 5029C-T User's Manual Installing a Side-Mounted Fixed Hard Drive 1. Power down the system as described in Section 2.1 and remove the chassis cover as described in Section 2.3. 2. Place a 2.5" hard drive into the hard drive bracket and secure the hard drive to the bracket with the four screws provided.

  • Page 35: Adding An M.2 Storage Card

    Chapter 2 Maintenance and Component Installation Adding an M.2 Storage Card One or two M.2 SSD cards may be installed on the motherboard. Supported card form factors are 2280 or 22110. There is a standoff for each length. 1. Remove power from the system as described in section 2.1 and remove the chassis cover.
  • Page 36 SuperServer 5029C-T User's Manual 4. Insert the plastic securing knob into the standoff. Figure 2-19. Securing the M.2 Storage Module Note: You might experience temporary M.2 speed throttling when it reaches its thermal threshold, which depends on the specifications of your device. Please note that this is a normal phenomenon and should not crash or damage your system.

  • Page 37: Installing A Dvd Drive

    Chapter 2 Maintenance and Component Installation Installing a DVD Drive The SC721TQ-250B2 supports one DVD drive. It can be installed only if the top mounted fixed HDD is not used. It requires a mounting bracket rail (p/n MCP-220-81502-0N). Installing a DVD Drive 1.
  • Page 38 SuperServer 5029C-T User's Manual 7. Install the bracket rail (part number MCP-220-81502-0N) onto the left hand side of the DVD drive, using the two screws provided. Bracket Rail Figure 2-21. Securing the Bracket Rail to a DVD Drive 8. Slide the DVD drive into the chassis until it snaps into place. (Some DVD drives allow you to secure the drive with two screws.)

  • Page 39: Installing A Fan

    Chapter 2 Maintenance and Component Installation Installing a Fan The chassis includes a single 12-cm rear exhaust fan. The chassis also features a set of mounting holes that will support a standard 9-cm exhaust fan (not included). Installing the Exhasut Fan 1.

  • Page 40: Replacing The Power Supply

    SuperServer 5029C-T User's Manual Replacing the Power Supply The SC721TQ-250B2 includes a fixed (non-hot-swap) 250W power supply. If it is necessary to replace the power supply, follow the instructions below. Changing the Power Supply 1. Power down the system as described in Section 2.1 and remove the chassis cover as described in Section 2.3.

  • Page 41: Chapter 3 Motherboard Connections

    Chapter 3: Motherboard Connections Chapter 3 Motherboard Connections This section describes the connections on the X11SCL-IF motherboard and provides pinout definitions. Note that depending on how the system is configured, not all connections are required. The LEDs on the motherboard are also described here. A motherboard layout indicating component locations may be found in Chapter 1.

  • Page 42: Headers And Connectors

    SuperServer 5029C-T User's Manual 3.2 Headers and Connectors Fan Headers There are four 4-pin fan headers (FAN1 ~ FAN3, FANA) on the motherboard. All these 4-pin fan headers are backwards compatible with the traditional 3-pin fans. However, fan speed control is available for 4-pin fans only by Thermal Management via the IPMI 2.0 interface.
  • Page 43 Chapter 3: Motherboard Connections Chassis Intrusion A Chassis Intrusion header is located at JL1 on the motherboard. Attach the appropriate cable from the chassis to inform you of a chassis intrusion when the chassis is opened. Refer to the table below for pin definitions. Chassis Intrusion Pin Definitions Pin#...
  • Page 44 SuperServer 5029C-T User's Manual Onboard Power LED Header An Onboard Power LED header is located at JLED1. Refer to the table below for pin definitions. Onboard PWR LED Pin Definitions Pins Definition LED+ Onboard Buzzer The Onboard Buzzer located at SP1 is used to provide audible indicators for various beep codes.

  • Page 45: Ports

    Chapter 3: Motherboard Connections 3.3 Ports COM Port There is one COM port (COM1) on the back I/O panel on the motherboard. The COM port provides serial communication support. COM Port Pin Definitions Pin# Definition Pin# Definition VGA Port The onboard VGA port is located next to LAN2 on the back I/O panel. Use this connection for VGA display.
  • Page 46 SuperServer 5029C-T User's Manual Universal Serial Bus (USB) Ports There are two USB 2.0 ports (USB0/1) and two USB 3.1 Gen 1 ports (USB4/5) located on the back I/O panel. The motherboard also has one front access USB 2.0 header (USB2/3) and one front access USB 3.1 Gen 1 header (USB6/7).
  • Page 47 LED indicator. Note: UID can also be triggered via IPMI on the motherboard. For more information on IPMI, please refer to the IPMI User's Guide posted on our website: https://www. supermicro.com/support/manuals/ UID Switch UID LED Pin Definitions...

  • Page 48: Jumpers

    SuperServer 5029C-T User's Manual 3.4 Jumpers Explanation of Jumpers To modify the operation of the motherboard, jumpers are used to choose between optional settings. Jumpers create shorts between two pins to change the function associated with it. Pin 1 is identified with a square solder pad on the printed circuit board. See the motherboard layout page for jumper locations.
  • Page 49 Chapter 3: Motherboard Connections ME Manufacturing Mode Close pins 2-3 of jumper JPME2 to bypass SPI flash security and force the system to operate in the manufacturing mode, which will allow the user to flash the system firmware from a host server for system setting modifications.

  • Page 50: Led Indicators

    SuperServer 5029C-T User's Manual 3.5 LED Indicators LAN LEDs Two LAN ports (LAN 1/2) are located on the back I/O panel of the motherboard. Each Ethernet LAN port has two LEDs. The green LED indicates activity, while the other Link LED may be green, amber, or off to indicate the speed of the connection.
  • Page 51 Chapter 3: Motherboard Connections Onboard Power LED The Onboard Power LED is located at LED3 on the motherboard. When this LED is on, the system is on. Be sure to turn off the system and unplug the power cord before removing or installing components.

  • Page 52: Chapter 4 Software

    USB/SATA DVD drive, or a USB flash drive, or the IPMI KVM console. 2. Retrieve the proper RST/RSTe driver. Go to the Supermicro web page for your motherboard and click on "Download the Latest Drivers and Utilities", select the proper driver, and copy it to a USB flash drive.
  • Page 53 Chapter 4: Software 1. During Windows Setup, continue to the dialog where you select the drives on which to install Windows. If the disk you want to use is not listed, click on “Load driver” link at the bottom left corner. Figure 4-2.

  • Page 54: Driver Installation

    SuperServer 5029C-T User's Manual 4.2 Driver Installation The Supermicro website contains drivers and utilities for your system at https://www. supermicro.com/wftp/driver/AMD/SP3. Some of these must be installed, such as the chipset driver. After accessing the website, go into the CDR_Images (in the parent directory of the above link) and locate the ISO file for your motherboard.

  • Page 55: Superdoctor ® 5

    4.3 SuperDoctor ® The Supermicro SuperDoctor 5 is a program that functions in a command-line or web-based interface for Windows and Linux operating systems. The program monitors such system health information as CPU temperature, system voltages, system power consumption, fan speed, and provides alerts via email or Simple Network Management Protocol (SNMP).

  • Page 56: Ipmi

    There are several BIOS settings that are related to IPMI. Supermicro ships standard products with a unique password for the BMC ADMIN user. This password can be found on a label on the motherboard.

  • Page 57: Chapter 5 Bios

    Chapter 5: BIOS Chapter 5 BIOS 5.1 Introduction This chapter describes the AMIBIOS™ Setup utility for the X11SCL-IF series motherboard. The BIOS is stored on a chip and can be easily upgraded using a flash program. Note: Due to periodic changes to the BIOS, some settings may have been added or deleted and might not yet be recorded in this manual.

  • Page 58: Main Setup

    SuperServer 5029C-T User's Manual 5.2 Main Setup When you first enter the AMI BIOS setup utility, you will enter the Main setup screen. You can always return to the Main setup screen by selecting the Main tab. The Main BIOS setup screen is shown below.
  • Page 59 Chapter 5: BIOS CPLD Version This item displays the Complex Programmable Logic Device version. Memory Information Total Memory This item displays the total size of memory available in the system.

  • Page 60: Advanced Setup Configurations

    SuperServer 5029C-T User's Manual 5.3 Advanced Setup Configurations Use the arrow keys to select the Advanced menu and press <Enter> to access the submenu features: Warning: Take caution when changing the Advanced settings. An incorrect value, a very high DRAM frequency, or an incorrect DRAM timing setting may make the system unstable. When this occurs, revert to default manufacturer settings.
  • Page 61 Chapter 5: BIOS Option ROM Messages Use this feature to set the display mode for the Option ROM. Select Keep Current to display the current AddOn ROM setting. Select Force BIOS to use the Option ROM display set by the system BIOS. The options are Force BIOS and Keep Current. Wait For "F1"...
  • Page 62 SuperServer 5029C-T User's Manual CPU Configuration  The following CPU information will display: • Type • CPU Signature • Microcode Revision • CPU Speed • L1 Data Cache • L1 Instruction Cache • L2 Cache • L3 Cache • L4 Cache •...
  • Page 63 Chapter 5: BIOS Intel (VMX) Virtualization Technology Use this feature to enable the Vanderpool Technology. This technology allows the system to run several operating systems simultaneously. The options are Disabled and Enabled. Active Processor Cores This feature determines how many CPU cores will be activated for each CPU. When All is selected, all cores in the CPU will be activated.
  • Page 64 SuperServer 5029C-T User's Manual Turbo Mode This feature will enable dynamic control of the processor, allowing it to run above stock fre- quency. The options are Disabled and Enabled. Monitor/Mwait Select Enabled to enable the Monitor/Mwait instructions. The Monitor instructions monitor a region of memory for writes, while MWait instructions instruct the CPU to stop until the moni- tored region begins to write.
  • Page 65 Chapter 5: BIOS Chipset Configuration  Warning: Setting the wrong values in the following features may cause the system to malfunc- tion. System Agent (SA) Configuration The following information is displayed: • SA PCIe Code Version • VT-d Memory Configuration ...
  • Page 66 SuperServer 5029C-T User's Manual Fast Boot Use this feature to enable or disable fast path through the memory reference code (MRC). The options are Disabled and Enabled. REFRESH_2X_MODE Use this feature to select the memory controller 2x refresh rate mode. The options are Disabled, 1- Enabled for WARM or HOT, and 2- Enabled HOT only.
  • Page 67 Chapter 5: BIOS Power Limit Scale Use this feature to select the scale used for the slot power limit value. The options are 1.0x, 0.1x, 0.01x, and 0.001x. Physical Slot Number Use this feature to set the physical slot number attached to this port. Press "+" or "-" on your keyboard to change the setting to a value between 0-8191.
  • Page 68 SuperServer 5029C-T User's Manual PCH-IO Configuration PCI Express Configuration  DMI Link ASPM Control Use this feature to set the Active State Power Management (ASPM) state on the System Agent (SA) side of the DMI Link. The options are Disabled, L0s, L1, L0sL1, and Auto.
  • Page 69 Chapter 5: BIOS Super IO Configuration  The following Super IO information will display: • Super IO Chip AST2500 Serial Port 1 Configuration This submenu allows the user to configure the settings of Serial Port 1. Serial Port Select Enabled to enable the selected onboard serial port. The options are Disabled and Enabled.
  • Page 70 SuperServer 5029C-T User's Manual Serial Port Console Redirection  COM1 Console Redirection Select Enabled to enable console redirection support for a serial port specified by the user. The options are Disabled and Enabled. *If the feature above is set to Enabled, the following settings will become available for configuration: COM1 Console Redirection Settings...
  • Page 71 Chapter 5: BIOS Flow Control Use this feature to set the flow control for Console Redirection to prevent data loss caused by buffer overflow. Send a "Stop" signal to stop sending data when the receiving buffer is full. Send a "Start" signal to start sending data when the receiving buffer is empty. The options are None and Hardware RTS/CTS.
  • Page 72 SuperServer 5029C-T User's Manual Terminal Type This feature allows the user to select the target terminal emulation type for Console Redirection. Select VT100 to use the ASCII Character set. Select VT100+ to add color and function key support. Select ANSI to use the Extended ASCII Character Set. Select VT-UTF8 to use UTF8 encoding to map Unicode characters into one or more bytes.
  • Page 73 Chapter 5: BIOS Resolution 100x31 Select Enabled for extended-terminal resolution support. The options are Disabled and Enabled. Legacy OS Redirection Resolution Use this feature to select the number of rows and columns used in Console Redirection for legacy OS support. The options are 80x24 and 80x25. Putty KeyPad This feature selects the settings for Function Keys and KeyPad used for Putty, which is a terminal emulator designed for the Windows OS.
  • Page 74 SuperServer 5029C-T User's Manual *If the feature above is set to Enabled, the following settings will become available for configuration: EMS Console Redirection Settings This feature allows the user to specify how the host computer will exchange data with the client computer, which is the remote computer used by the user.
  • Page 75 Chapter 5: BIOS SATA Mode Selection Use this feature to select the mode for the installed SATA drives. The options are AHCI and RAID. SATA Frozen Use this feature to enable the HDD Security Frozen Mode. The options are Enabled and Disabled.
  • Page 76 SuperServer 5029C-T User's Manual PCH-FW Configuration  The following firmware information will display: • Operational Firmware Version • Backup Firmware Version • Recovery Firmware Version • ME Firmware Features • ME Firmware Status #1 • ME Firmware Status #2 •...
  • Page 77 Chapter 5: BIOS USB Configuration  The following USB items will be displayed: • USB Module Version • USB Controllers • USB Devices Legacy USB Support (Available when USB Functions are not Disabled) Select Enabled to support legacy USB devices. Select Auto to disable legacy support if USB devices are not present.
  • Page 78 SuperServer 5029C-T User's Manual Onboard Video Option ROM Use this feature to select the onboard video firmware type to be loaded. The options are Legacy and EFI. NVMe Firmware Source Use this feature to select the NVMe firmware to support booting. The options are Vendor Defined Firmware and AMI Native Support.
  • Page 79 Chapter 5: BIOS Ipv4 HTTP Support Select Enabled to enable IPv4 HTTP boot support. The options are Disabled and Enabled. Ipv6 PXE Support Select Enabled to enable IPv6 PXE boot support. The options are Disabled and Enabled. Ipv6 HTTP Support Select Enabled to enable IPv6 HTTP boot support.
  • Page 80 SuperServer 5029C-T User's Manual SHA-1 PCR Bank Use this feature to disable or enable the SHA-1 Platform Configuration Register (PCR) bank for the installed TPM device. The options are Disabled and Enabled. SHA256 PCR Bank Use this feature to disable or enable the SHA256 Platform Configuration Register (PCR) bank for the installed TPM device.
  • Page 81 Chapter 5: BIOS SMCI BIOS-Based TPM Provision Support Use feature to enable the Supermicro TPM Provision support. The options are Disabled and Enabled. TXT Support Intel Trusted Execution Technology (TXT) helps protect against software-based attacks and ensures protection, confidentiality, and integrity of data stored or created on the system. Use this feature to enable or disable TXT Suppport.
  • Page 82 SuperServer 5029C-T User's Manual TLS Authentication Configuration  This submenu allows the user to configure Transport Layer Security (TLS) settings. Server CA Configuration Enroll Certification Enroll Certification Using File Use this feature to enroll certification from a file. Certification GUID Use this feature to input the certification GUID.

  • Page 83: Event Logs

    Chapter 5: BIOS 5.4 Event Logs Use this feature to configure Event Log settings. Change SMBIOS Event Log Settings Enabling/Disabling Options SMBIOS Event Log Change this feature to enable or disable all features of the SMBIOS Event Logging during system boot. The options are Disabled and Enabled. Erasing Settings Erase Event Log If No is selected, data stored in the event log will not be erased.
  • Page 84 SuperServer 5029C-T User's Manual SMBIOS Event Log Standard Settings Log System Boot Event This feature toggles the System Boot Event logging to enabled or disabled. The options are Enabled and Disabled. MECI The Multiple Event Count Increment (MECI) counter counts the number of occurences that a duplicate event must happen before the MECI counter is incremented.

  • Page 85: Ipmi

    Chapter 5: BIOS 5.5 IPMI Use this feature to configure Intelligent Platform Management Interface (IPMI) settings. BMC Firmware Revision This item indicates the IPMI firmware revision used in your system. IPMI Status (Baseboard Management Controller) This item indicates the status of the IPMI firmware installed in your system. System Event Log Enabling/Disabling Options SEL Components...
  • Page 86 SuperServer 5029C-T User's Manual When SEL is Full This feature allows the user to decide what the BIOS should do when the system event log is full. Select Erase Immediately to erase all events in the log when the system event log is full.
  • Page 87 Chapter 5: BIOS Station MAC Address This feature displays the Station MAC address for this computer. Mac addresses are 6 two- digit hexadecimal numbers. Gateway IP Address This feature displays the Gateway IP address for this computer. This should be in decimal and in dotted quad form (i.e., 172.31.0.1).

  • Page 88: Security

    SuperServer 5029C-T User's Manual 5.6 Security This menu allows the user to configure the following security settings for the system. Password Check Select Setup for the system to check for a password at Setup. Select Always for the system to check for a password at bootup or upon entering the BIOS Setup utility. The options are Setup and Always.
  • Page 89 Chapter 5: BIOS CSM Support Select Enabled to support the EFI Compatibility Support Module (CSM), which provides compatibility support for traditional legacy BIOS for system boot. The options are Disabled and Enabled.  Key Management This submenu allows the user to configure the following Key Management settings. ...
  • Page 90 SuperServer 5029C-T User's Manual  Key Exchange Keys Update Select Yes to load the KEK from the manufacturer's defaults. Select No to load the KEK from a file. The options are Yes and No. Append Select Yes to add the KEK from the manufacturer's defaults list to the existing KEK.
  • Page 91 Chapter 5: BIOS  OsRecovery Signature This feature uploads and installs an OSRecovery Signature. You may insert a factory default key or load from a file. The file formats accepted are: 1) Public Key Certificate a. EFI Signature List b. EFI CERT X509 (DER Encoded) c.

  • Page 92: Boot

    SuperServer 5029C-T User's Manual 5.7 Boot Use this feature to configure Boot settings. Setup Prompt Timeout Use this feature to indicate the length of time (the number of seconds) for the BIOS to wait before rebooting the system when the setup activation key is pressed. Enter the value of 65535 (0xFFFF) for the BIOS to wait indefinitely.
  • Page 93 Chapter 5: BIOS • Legacy/UEFI/Dual Boot Option #5 • Legacy/UEFI/Dual Boot Option #6 • Legacy/UEFI/Dual Boot Option #7 • Legacy/UEFI/Dual Boot Option #8 • UEFI/Dual Boot Option #9 • Dual Boot Option #10 • Dual Boot Option #11 • Dual Boot Option #12 •...
  • Page 94 SuperServer 5029C-T User's Manual Path for Boot Option Use this feature to enter the path for the new boot option in the format fsx:\path\filename.efi. Boot Option File Path Use this feature to specify the file path for the new boot option.
  • Page 95 Chapter 5: BIOS UEFI Hard Disk Drive BBS Priorities  This feature sets the system boot order of detected devices. • Boot Option #1 Hard Disk Drive BBS Priorities  This feature sets the system boot order of detected devices. •...

  • Page 96: Save & Exit

    SuperServer 5029C-T User's Manual 5.8 Save & Exit Select the Save & Exit tab from the BIOS setup screen to configure the settings below: Save Options Discard Changes and Exit Select this feature to quit the BIOS Setup without making any permanent changes to the system configuration and reboot the computer.
  • Page 97 Chapter 5: BIOS Default Options Restore Defaults To set this feature, select Restore Defaults from the Save & Exit menu and press <Enter>. These are factory settings designed for maximum system stability, but not for maximum performance. Save As User Defaults To set this feature, select Save as User Defaults from the Save &...

  • Page 98: Appendix A Bios Post Codes

    When BIOS performs the Power On Self Test, it writes checkpoint codes to I/O port 0080h. If the computer cannot complete the boot process, a diagnostic card can be attached to the computer to read I/O port 0080h (Supermicro p/n AOC-LPC80-20). For information on AMI updates, please refer to http://www.ami.com/products/.

  • Page 99: Appendix B Standardized Warning Statements For Ac Systems

    Supermicro's Technical Support department for assistance. Only certified technicians should attempt to install or configure components. Read this appendix in its entirety before installing or configuring components in the Supermicro chassis. These warnings may also be found on our website at http://www.supermicro.com/about/...
  • Page 100 Appendix B: Standardized Warning Statements Warnung WICHTIGE SICHERHEITSHINWEISE Dieses Warnsymbol bedeutet Gefahr. Sie befinden sich in einer Situation, die zu Verletzungen führen kann. Machen Sie sich vor der Arbeit mit Geräten mit den Gefahren elektrischer Schaltungen und den üblichen Verfahren zur Vorbeugung vor Unfällen vertraut. Suchen Sie mit der am Ende jeder Warnung angegebenen Anweisungsnummer nach der jeweiligen Übersetzung in den übersetzten Sicherheitshinweisen, die zusammen mit diesem Gerät ausgeliefert wurden.
  • Page 101 SuperServer 5029C-T User's Manual . ٌ ‫ا ك ً ف حالة و ٌ يك أى تتسبب ف اصابة جسذ ة ٌ هذا الزهز ع ٌ خطز !تحذ ز‬ ‫قبل أى تعول عىل أي هعذات،يك عىل علن بالوخاطز ال ا ٌجوة عي الذوائز‬...
  • Page 102 Appendix B: Standardized Warning Statements Warnung Vor dem Anschließen des Systems an die Stromquelle die Installationsanweisungen lesen. ¡Advertencia! Lea las instrucciones de instalación antes de conectar el sistema a la red de alimentación. Attention Avant de brancher le système sur la source d'alimentation, consulter les directives d'installation. .‫יש...
  • Page 103 SuperServer 5029C-T User's Manual Warnung Dieses Produkt ist darauf angewiesen, dass im Gebäude ein Kurzschluss- bzw. Überstromschutz installiert ist. Stellen Sie sicher, dass der Nennwert der Schutzvorrichtung nicht mehr als: 250 V, 20 A beträgt. ¡Advertencia! Este equipo utiliza el sistema de protección contra cortocircuitos (o sobrecorrientes) del edificio.
  • Page 104 Appendix B: Standardized Warning Statements Power Disconnection Warning Warning! The system must be disconnected from all sources of power and the power cord removed from the power supply module(s) before accessing the chassis interior to install or remove system components. 電源切断の警告...
  • Page 105 SuperServer 5029C-T User's Manual ‫يجب فصم اننظاو من جميع مصادر انطاقت وإ ز انت سهك انكهرباء من وحدة امداد‬ ‫انطاقت قبم‬ ‫انىصىل إىن امنناطق انداخهيت نههيكم نتثبيج أو إ ز انت مكىناث الجهاز‬ 경고! 시스템에 부품들을 장착하거나 제거하기 위해서는 섀시 내부에 접근하기 전에 반드시 전원...
  • Page 106 Appendix B: Standardized Warning Statements Attention Il est vivement recommandé de confier l'installation, le remplacement et la maintenance de ces équipements à des personnels qualifiés et expérimentés. !‫אזהרה‬ .‫צוות מוסמך בלבד רשאי להתקין, להחליף את הציוד או לתת שירות עבור הציוד‬ ‫واملدربيه...
  • Page 107 SuperServer 5029C-T User's Manual Warnung Diese Einheit ist zur Installation in Bereichen mit beschränktem Zutritt vorgesehen. Der Zutritt zu derartigen Bereichen ist nur mit einem Spezialwerkzeug, Schloss und Schlüssel oder einer sonstigen Sicherheitsvorkehrung möglich. ¡Advertencia! Esta unidad ha sido diseñada para instalación en áreas de acceso restringido. Sólo puede obtenerse acceso a una de estas áreas mediante la utilización de una herramienta especial,...
  • Page 108 Appendix B: Standardized Warning Statements Battery Handling Warning! There is the danger of explosion if the battery is replaced incorrectly. Replace the battery only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the manufacturer's instructions 電池の取り扱い...
  • Page 109 SuperServer 5029C-T User's Manual ‫هناك خطر من انفجار يف حالة اسحبذال البطارية بطريقة غري صحيحة فعليل‬ ‫اسحبذال البطارية‬ ‫فقط بنفس النىع أو ما يعادلها مام أوصث به الرشمة املصنعة‬ ‫جخلص من البطاريات املسحعملة وفقا لحعليامت الرشمة الصانعة‬ 경고! 배터리가 올바르게 교체되지 않으면 폭발의 위험이 있습니다. 기존 배터리와 동일하거나 제...
  • Page 110 Appendix B: Standardized Warning Statements ¡Advertencia! Puede que esta unidad tenga más de una conexión para fuentes de alimentación. Para cortar por completo el suministro de energía, deben desconectarse todas las conexiones. Attention Cette unité peut avoir plus d'une connexion d'alimentation. Pour supprimer toute tension et tout courant électrique de l'unité, toutes les connexions d'alimentation doivent être débranchées.
  • Page 111 SuperServer 5029C-T User's Manual Backplane Voltage Warning! Hazardous voltage or energy is present on the backplane when the system is operating. Use caution when servicing. バックプレーンの電圧 システムの稼働中は危険な電圧または電力が、 バックプレーン上にかかっています。 修理する際には注意く ださい。 警告 当系统正在进行时，背板上有很危险的电压或能量，进行维修时务必小心。 警告 當系統正在進行時，背板上有危險的電壓或能量，進行維修時務必小心。 Warnung Wenn das System in Betrieb ist, treten auf der Rückwandplatine gefährliche Spannungen oder Energien auf.
  • Page 112 Appendix B: Standardized Warning Statements ‫هناك خطز مه التيار الكهزبايئ أوالطاقة املىجىدة عىل اللىحة‬ ‫عندما يكىن النظام يعمل كه حذ ر ا عند خدمة هذا الجهاس‬ 경고! 시스템이 동작 중일 때 후면판 (Backplane)에는 위험한 전압이나 에너지가 발생 합니다. 서비스 작업 시 주의하십시오. Waarschuwing Een gevaarlijke spanning of energie is aanwezig op de backplane wanneer het systeem in gebruik is.
  • Page 113 SuperServer 5029C-T User's Manual ‫תיאום חוקי החשמל הארצי‬ !‫אזהרה‬ .‫התקנת הציוד חייבת להיות תואמת לחוקי החשמל המקומיים והארציים‬ ‫تركيب املعدات الكهربائية يجب أن ميتثل للقىاويه املحلية والىطىية املتعلقة‬ ‫بالكهرباء‬ 경고! 현 지역 및 국가의 전기 규정에 따라 장비를 설치해야 합니다.
  • Page 114 Appendix B: Standardized Warning Statements Attention La mise au rebut ou le recyclage de ce produit sont généralement soumis à des lois et/ou directives de respect de l'environnement. Renseignez-vous auprès de l'organisme compétent. ‫סילוק המוצר‬ !‫אזהרה‬ .‫סילוק סופי של מוצר זה חייב להיות בהתאם להנחיות וחוקי המדינה‬ ‫التخلص...
  • Page 115 SuperServer 5029C-T User's Manual Warnung Gefährlich Bewegende Teile. Von den bewegenden Lüfterblätter fern halten. Die Lüfter drehen sich u. U. noch, wenn die Lüfterbaugruppe aus dem Chassis genommen wird. Halten Sie Finger, Schraubendreher und andere Gegenstände von den Öffnungen des Lüftergehäuses entfernt.
  • Page 116 Verbindungskabeln, Stromkabeln und/oder Adapater, die Ihre örtlichen Sicherheitsstandards einhalten. Der Gebrauch von anderen Kabeln und Adapter können Fehlfunktionen oder Feuer verursachen. Die Richtlinien untersagen das Nutzen von UL oder CAS zertifizierten Kabeln (mit UL/CSA gekennzeichnet), an Geräten oder Produkten die nicht mit Supermicro gekennzeichnet sind.
  • Page 117 ‫حجم املوصل والقابس السليم. استخدام أي كابالت ومحوالت أخرى قد يتسبب يف عطل أو حريق. يحظر قانون السالمة لألجهزة الكهربائية واملعدات استخدام الكابالت املعتمدة‬ ‫ من قبل‬UL ‫ أو‬CSA ‫( والتي تحمل عالمة‬UL/CSA) ‫ مع أي معدات أخرى غري املنتجات املعنية واملحددة من قبل‬Supermicro.
  • Page 118 사항을 준수하여 제공되거나 지정된 연결 혹은 구매 케이블, 전원 케이블 및 AC 어댑터를 사용하십시오. 다른 케이블이나 어댑터를 사용하면 오작동이나 화재가 발생할 수 있습니다. 전기 용품 안전법은 UL 또는 CSA 인증 케이블 (코드에 UL / CSA가 표시된 케이블)을 Supermicro 가 지정한 제품 이외의 전기 장치에 사용하는 것을 금지합니다. Stroomkabel en AC-Adapter...

  • Page 119: Appendix C System Specifications

    Memory Two DDR4-2666MHz ECC UDIMM slots, max capacity 64GB Note: See the memory section in Chapter 3 for details and the Supermicro website for updates to supported memory. SATA Drives Four (4) hot-swap 3.5" SAS2/ SATA3 drive bays with Backplane (SES-II) Two (2) internal fixed 2.5"...
  • Page 120 SuperServer 5029C-T User's Manual Regulatory Compliance Electromagnetic Emissions: FCC Class B, EN 55032 Class B, EN 61000-3-2/3-3, CISPR 32 Class B Electromagnetic Immunity: EN 55024/CISPR 24, (EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, EN 61000-4-11)

  • Page 121: Appendix D Bsmi Rohs

    SuperServer 5029C-T User's Manual Appendix D BSMI RoHS 限 限 用 用 物 物 質 質 含 含 有 有 情 情 況 況 標 標 示 示 聲 聲 明 明 書 書 Declaration of the Presence Condition of the Restricted Substances Marking...
  • Page 122 Appendix D: BSMI RoHS *輸入額定: 100-240V ~, 60-50Hz, 4-2A *使用者不能任意拆除或替換內部配備 *設備名稱：伺服器 *報驗義務人之姓名或名稱：美超微電腦股份有限公司 *報驗義務人之地址：新北市中和區建一路 150 號 3 樓...
