ELECTRIC RANGES
700 Series
TYPE: 72/02TCEPT, 72/02TCEPQ, 74/02TCEPT, 74/02TCEPQ, 76/02TCEPT, 76/02TCEPQ,
72/02CEPT, 72/02CEPQ, 74/02CEPT, 74/02CEEPT, 74/02CEPQ, 74/02CEEPQ, 76/02CEPT,
76/02CEEANPT, 76/02CEEEACPT, 76/02CEPQ, 76/02CEEANPQ, 76/02CEEEACPQ
Installation and Operation Manual
S/N:
Rev.: 1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 700 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Metos 700 Series

Summary of Contents for Metos 700 Series

  • Page 1 ELECTRIC RANGES 700 Series TYPE: 72/02TCEPT, 72/02TCEPQ, 74/02TCEPT, 74/02TCEPQ, 76/02TCEPT, 76/02TCEPQ, 72/02CEPT, 72/02CEPQ, 74/02CEPT, 74/02CEEPT, 74/02CEPQ, 74/02CEEPQ, 76/02CEPT, 76/02CEEANPT, 76/02CEEEACPT, 76/02CEPQ, 76/02CEEANPQ, 76/02CEEEACPQ Installation and Operation Manual S/N: Rev.: 1.0...
  • Page 3 Dear Customer, Congratulations on deciding to choose a Metos appliance for your kitchen activities. You made an excellent choice. We will do our best to make you a satisfied Metos customer like thousands of customers we have around the world.
  • Page 4 16.2.2004 Rev. 1.0...

  • Page 5: Table Of Contents

    16.2.2004 Rev. 1. General ......................1 1.1 Symbols used in the manual ..................1 1.2 Symbols affixed to the appliance .................. 1 1.3 Checking correspondence between the handbook and the appliance ......2 2. Safety ......................3 2.1 Using the appliance safely ..................... 3 2.2 Safety instructions in case of malfunction ..............
  • Page 6 16.2.2004 Rev. 5. Installation ....................13 5.1 General information ..................... 13 5.2 Storage ......................... 13 5.3 Unpacking the appliance ..................... 13 5.4 Disposing of packaging materials ................13 5.5 Installation ........................14 5.6 Electrical connection ....................15 5.6.1 Connecting the connection cable to the terminal block (countertop and freestanding ranges)[72PT,72PQ,74PT,74PQ,76TPT,76TPQ,72TPT,72TPQ,74TPT,74TPQ,76PT,76 TPQ] ..........................

  • Page 7: General

    16.2.2004 Rev. 1.0 General 1. General Read the instructions in this handbook carefully: they contain important information re- garding proper, efficient and safe installation, operation and maintenance of the appli- ance. Keep this handbook in a safe place where it is readily available for consultation by other users of the appliance.

  • Page 8: Checking Correspondence Between The Handbook And The Appliance

    16.2.2004 Rev. 1.0 General 1.3 Checking correspondence between the handbook and the appliance The appliance serial number is shown on the rating plate. If the handbooks are misplaced, new copies may be ordered from the manufacturer or the local dealer. When ordering new handbooks always quote the serial number shown on the rating plate.

  • Page 9: Safety

    16.2.2004 Rev. 1.0 Safety 2. Safety 2.1 Using the appliance safely Being designed for professional use, this appliance should be used by qualified personnel only. Never leave the appliance unattended while in use! Do not move the appliance while hot! IF OIL SHOULD CATCH FIRE, NEVER USE WATER TO EXTINGUISH IT.
  • Page 10 16.2.2004 Rev. 1.0 Safety...

  • Page 11: Functional Description

    16.2.2004 Rev. 1.0 Functional description 3. Functional description 3.1 Intended use This electric range is intended to cook food in pots and pans placed on the cooking plates. 3.1.1 Prohibited use This electric range is not designed to cook food directly on the cooking plates. 3.2 Construction Stainless steel bearing structure resting on four height-adjustable feet.

  • Page 12: Operating Switches And Pilot Lights

    16.2.2004 Rev. 1.0 Functional description 3.3.1 Operating switches and pilot lights 7-position selector switch “Power on” pilot light By turning the selector switch to the desired setting, the pilot light will go on and the cook- ing plate will start heating. Heating is effected by means of conductive heat provided by electric cast-iron cooking plates.

  • Page 13: Operating Instructions

    16.2.2004 Rev. 1.0 Operating instructions 4. Operating instructions 4.1 Before using the appliance 4.1.1 Preparing the use Remove all packaging materials and adhesive films from the range very carefully. Re- move the protective plastic film from the panels, being careful not to leave any traces of glue on the steel surface;...

  • Page 14: Using The Appliance

    16.2.2004 Rev. 1.0 Operating instructions 4.2 Using the appliance 4.2.1 Turning on the appliance Turn on the appliance using the safety switch located outside the appliance. By turning the knob to the desired effect setting, the pilot light will go on and the cooking plate will start heating.

  • Page 15: Turning On The Electric Oven

    16.2.2004 Rev. 1.0 Operating instructions 4.2.4 Turning on the electric oven Select the required heating direction using the knob shown as item 23 in ”Fig. 5” . The power indicator light (item 25) will come on. Set the cooking chamber temperature by turning the operating thermostat knob clockwise (item 24).

  • Page 16: Preheating

    16.2.2004 Rev. 1.0 Operating instructions 4.2.6 Preheating Preheating the chambers will ensure excellent cooking results. To do so, make sure that the door is closed and set cooking chamber temperature to a value that is about 25-50°C higher than the required cooking temperature. Considering the decrease in temperature that occurs in the chamber when you open the oven door, you should wait until the set temperature has stabilised (the "heating on"...

  • Page 17: Periodic Maintenance

    16.2.2004 Rev. 1.0 Operating instructions Scratches and dark stains Scratches and dark stains may be smoothed or removed by using stainless steel wool pads or synthetic abrasive sponges, rubbing always in the same direction as the satin finish. Rust If you need to remove rust stains, contact manufacturers of industrial detergents to find a suitable product.
  • Page 18 16.2.2004 Rev. 1.0 Operating instructions...

  • Page 19: Installation

    16.2.2004 Rev. 1.0 Installation 5. Installation 5.1 General information The manufacturer cannot be held liable for any damage to property or injury to persons due to installation errors or inappropriate use of the appliance. Check that the appliance is preset to use the voltage rating available at the location where it is installed.

  • Page 20: Installation

    16.2.2004 Rev. 1.0 Installation 5.5 Installation If the range is installed near other electrical appliances, ensure that they do not interfere with each other. Each applience should have an independently used power supply. Before turning on any heating element, make sure that all packaging materials and protective films have been removed.

  • Page 21: Electrical Connection

    16.2.2004 Rev. 1.0 Installation 5.6 Electrical connection Connecting a Y-type power cord. Follow the installation instructions and the information on the rating plate when connect- ing the unit. Comply with all local regulations and standards! Each appliance requires an independent fused power supply line. On-site installation: provide accessible all-pole disconnection device with a minimum of a 3 mm contact gap.

  • Page 22: Air Conditioning

    16.2.2004 Rev. 1.0 Installation 5.7 Air conditioning The appliance should be installed in a well-ventilated area, if possible under a hood, in compliance with applicable regulations in force. 5.8 Staff training Instruct the personnel in the use of this appliance by referring to the user’s manual and hand out the manual to them.

  • Page 23: Troubleshooting

    16.2.2004 Rev. 1.0 Troubleshooting 6. Troubleshooting If the appliance fails to work, check the fuse box for blown fuses (overload protection). Have the overload protection device checked by a qualified technician. Users are not allowed to perform any maintenance operations on any parts of this appli- ance.
  • Page 24 16.2.2004 Rev. 1.0 Troubleshooting HOT CUPBOARD Hot cupboard won’t No power; Check that the appliance is heat: getting power; A temperature is set but Faulty thermostat; Call the service Replace the thermostat the cabinet won’t turn Broken heating element; Call the service Replace the heating element (see chapter "Replacing the heating element")
  • Page 25 16.2.2004 Rev. 1.0 Technical specifications 8. Technical specifications Connection diagrams ......30 Installation and connection drawings. 46 Technical specifications table....64 CE conformity declaration ....67...
  • Page 26 SC00412: Wiring diagram 72/02TCEPQ, 72/02CEPQ, 3/N/PE 400V ~ 50/60 Hz...
  • Page 27 16.2.2004 Rev. 1.0 Technical specifications Code Coordinata Initials Description Electric characteristics A036720 E51 - 52 Cooking plate 2600W - 230V 220x220 mm A038506 Line pilot light 400V - 150 °C A045500 S1 - 2 Selector switch 7 positions...
  • Page 28 SC00429: Wiring diagram 72/02TCEPT, 72/02CEPT, 3/N/PE 400V ~ 50/60 Hz...
  • Page 29 16.2.2004 Rev. 1.0 Technical specifications Code Coordinata Initials Description Electric characteristics A038506 Line pilot light 400V - 150 °C A045500 S1 - 2 Selector switch 7 positions A045601 Cooking plate 2600W - 230V D. 220 mm A048901 Cooking plate 2000W - 230V D. 180 mm...
  • Page 30 SC00411: Wiring diagram 74/02TCEPQ, 74/02CEPQ, 3/N/PE 400V ~ 50/60 Hz...
  • Page 31 16.2.2004 Rev. 1.0 Technical specifications Code Coordinata Initials Description Electric characteristics A036720 E51 - 52 - 53 - 54 Cooking plate 2600W - 230V 220x220 mm A038506 Line pilot light 400V - 150 °C A045500 S1 - 2 - 3 - 4 Selector switch 7 positions...
  • Page 32 PROGETTO NON E' PERMESSO CONSEGNARE A TERZI O RIPRODURRE QUESTO DOCUMENTO BANCA DIS. NE UTILIZZARE IL CONTENUTO O RENDERLO COMUNQUE NOTO A TERZI SENZA LA NOSTRA TIPICO SUBITI. E' FATTA RISERVA DI TUTTI I DIRITTI DA BREVETTI O MODELLI. SC00428: Wiring diagram 74/02TCEPT, 74/02CEPT, 3/N/PE 400V ~ 50/60 Hz...
  • Page 33 16.2.2004 Rev. 1.0 Technical specifications Code Coordinata Initials Description Electric characteristics A038506 Line pilot light 400V - 150 °C A045500 S1 - 2 - 3 - 4 Selector switch 7 positions A045601 E52 - 54 Cooking plate 2600W - 230V D. 220 mm A048901 E51 - 53 Cooking plate...
  • Page 34 SC00410: Wiring diagram 74/02CEEPQ, 3/N/PE 400V ~ 50/60 Hz...

  • Page 35: Technical Specifications

    16.2.2004 Rev. 1.0 Technical specifications Code Coordinata Initials Description Electric characteristics A036720 E51 - 52 - 53 - 54 Cooking plate 2600W - 230V 220x220 mm A037550 E58 - 59 Heating element 2750W - 230V A038506 Line pilot light 400V - 150 °C A044601 Control thermostat 50 - 300 °C - 3F...
  • Page 36 SC00427: Wiring diagram 74/02CEEPT, 3/N/PE 400V ~ 50/60 Hz...
  • Page 37 16.2.2004 Rev. 1.0 Technical specifications Code Coordinata Initials Description Electric characteristics A037550 E58 - 59 Heating element 2750W - 230V A038506 Line pilot light 400V - 150 °C A038506 Operation pilot light 400V - 150 °C A044601 Control thermostat 50 - 300 °C - 3F A045500 S1 - 2 - 3 - 4 Selector switch...
  • Page 38 SC00409: Wiring diagram 76/02TCEPQ, 76/02CEPQ, 3/N/PE 400V ~ 50/60 Hz...
  • Page 39 16.2.2004 Rev. 1.0 Technical specifications Code Coordinata Initials Description Electric characteristics A036720 E51 - 52 - 53 - 54 - 55 Cooking plate 2600W - 230V 220x220 mm - 56 A038506 Line pilot light 400V - 150 °C A045500 S1 - 2 - 3 - 4 - 5 - 6 Selector switch 7 positions...
  • Page 40 SC00426: Wiring diagram 76/02TCEPT, 76/02CEPT, 3/N/PE 400V ~ 50/60 Hz...
  • Page 41 16.2.2004 Rev. 1.0 Technical specifications Code Coordinata Initials Description Electric characteristics A038506 Line pilot light 400V - 150 °C A045500 S1 - 2 - 3 - 4 - 5 - 6 Selector switch 7 positions A045601 E52 - 54 - 56 Cooking plate 2600W - 230V D.
  • Page 42 16.2.2004 Rev. 1.0 Technical specifications Installation drawing 72/02TCEPT Connection cable entry Distance between feet Rating plate Power connection terminals...
  • Page 43 16.2.2004 Rev. 1.0 Technical specifications Installation drawing 72/02TCEPQ Connection cable entry Distance between feet Plate dimensions Rating plate Power connection terminals...
  • Page 44 16.2.2004 Rev. 1.0 Technical specifications Installation drawing 74/02TCEPT Connection cable entry Distance between feet Rating plate Power connection terminals...
  • Page 45 16.2.2004 Rev. 1.0 Technical specifications Installation drawing 74/02TCEPQ Connection cable entry Distance between feet Plate dimensions Rating plate Power connection terminals...
  • Page 46 16.2.2004 Rev. 1.0 Technical specifications Installation drawing 76/02TCEPT Connection cable entry Distance between feet Rating plate Power connection terminals...
  • Page 47 16.2.2004 Rev. 1.0 Technical specifications Installation drawing 76/02TCEPQ Connection cable entry Distance between feet Plate dimensions Rating plate Power connection terminals...
  • Page 48 16.2.2004 Rev. 1.0 Technical specifications Installation drawing 72/02CEPT Connection cable entry Distance between feet Rating plate Power connection terminals...
  • Page 49 16.2.2004 Rev. 1.0 Technical specifications Installation drawing 72/02CEPQ Connection cable entry Distance between feet Plate dimensions Rating plate Power connection terminals...
  • Page 50 16.2.2004 Rev. 1.0 Technical specifications Installation drawing 74/02CEPT Connection cable entry Distance between feet Rating plate Power connection terminals...
  • Page 51 16.2.2004 Rev. 1.0 Technical specifications Installation drawing 74/02CEEPT Connection cable entry Distance between feet Rating plate Power connection terminals...
  • Page 52 16.2.2004 Rev. 1.0 Technical specifications Installation drawing 74/02CEPQ Connection cable entry Distance between feet Plate dimensions Rating plate Power connection terminals...
  • Page 53 16.2.2004 Rev. 1.0 Technical specifications Installation drawing 74/02CEEPQ Connection cable entry Distance between feet Plate dimensions Rating plate Power connection terminals...
  • Page 54 16.2.2004 Rev. 1.0 Technical specifications Installation drawing 76/02CEPT Connection cable entry Distance between feet Rating plate Power connection terminals...
  • Page 55 16.2.2004 Rev. 1.0 Technical specifications Installation drawing 76/02CEEANPT Connection cable entry Distance between feet Rating plate Power connection terminals...
  • Page 56 16.2.2004 Rev. 1.0 Technical specifications Installation drawing 76/02CEEEACPT Connection cable entry Distance between feet Rating plate Power connection terminals...
  • Page 57 16.2.2004 Rev. 1.0 Technical specifications Installation drawing 76/02CEPQ Connection cable entry Distance between feet Plate dimensions Rating plate Power connection terminals...
  • Page 58 16.2.2004 Rev. 1.0 Technical specifications Installation drawing 76/02CEEANPQ Connection cable entry Distance between feet Plate dimensions Rating plate Power connection terminals...
  • Page 59 16.2.2004 Rev. 1.0 Technical specifications Installation drawing 76/02CEEEACPQ Connection cable entry Distance between feet Plate dimensions Rating plate Power connection terminals...
  • Page 60 16.2.2004 Rev. 1.0 Technical specifications Item Type Voltage Specification Oven internal dimensions WxDxH 74EPT,76EANPT,76EEPT,74EPQ, 660 x 543 x 300 mm 76EANPQ,76EEACPQ Cupboard internal dimensions WxDxH 76EANPT,76EEPT,76EANPQ, 331 x 550 x 300 mm 76EEACPQ Volume with package 72PT,72PQ 0.4 m3 Volume with package 74PT,74PQ 0.75 m3 Volume with package...
  • Page 61 5 x 1.5 Supply wire type 74TPQ,74PQ 5 x 4 Supply wire type 76TPQ,76PQ 5 x 4 Supply wire type 74EPQ 5 x 6 700 Series=700 Series 72TPT=72/02TCEPT, 72TPQ=72/02TCEPQ, 74TPT=74/02TCEPT, 74TPQ=74/02TCEPQ, 76TPT=76/02TCEPT, 76TPQ=76/02TCEPQ, 72PT=72/02CEPT, 72PQ=72/02CEPQ, 74PT=74/02CEPT, 74EPT=74/02CEEPT, 74PQ=74/ 02CEPQ, 74EPQ=74/02CEEPQ, 76PT=76/02CEPT,...
  • Page 62 16.2.2004 Rev. 1.0 Technical specifications...
