- Page 1 DIGITAL Fast Ethernet Interface Module DELHE-UA User’s Guide...
- Page 3 DIGITAL Fast Ethernet Interface Module DELHE-UA User’s Guide Part Number: 9032765 September 1998 This book describes the DELHE-UA features and how to install and troubleshoot the equipment. Revision/Update Information: This is a new document.
-
Page 4: United States Government Restricted Rights
Cabletron Systems reserves the right to make changes in specifications and other information contained in this document without prior notice. The reader should in all cases consult Cabletron Systems to determine whether any such changes have been made. The hardware, firmware, or software described in this manual is subject to change without notice. - Page 5 FCC Notice — Class A Computing Device: This equipment generates, uses, and may emit radio frequency energy. The equipment has been type tested and found to comply with the limits for a Class A digital device pursuant to Part 15 of FCC rules, which are designed to provide reasonable protection against such radio frequency interference.
- Page 6 IMPORTANT: Before utilizing this product, carefully read this License Agreement. This document is an agreement between you, the end user, and Cabletron Systems, Inc. (“Cabletron”) that sets forth your rights and obligations with respect to the Cabletron software program (the “Program”) contained in this package.
-
Page 7: Safety Information
CLASS 1 LASER TRANSCEIVERS THE DELHE-UA GIGABIT ETHERNET MODULES USE CLASS 1 LASER TRANSCEIVERS. READ THE FOLLOWING SAFETY INFORMATION BEFORE INSTALLING OR OPERATING The Class 1 laser transceivers use an optical feedback loop to maintain Class 1 operation limits. This control loop eliminates the need for maintenance checks or adjustments. -
Page 8: Declaration Of Conformity
___________________________________ Title Rochester, NH, USA ___________________________________ Location 89/336/EEC 73/23/EEC Manufacturer’s Name: Cabletron Systems, Inc. 35 Industrial Way PO Box 5005 Rochester, NH 03867 Mr. J. Solari Cabletron Systems Limited Nexus House, Newbury Business Park London Road, Newbury Berkshire RG13 2PZ, England... -
Page 9: Table Of Contents
PREFACE Using This Guide ...xi Structure of This Guide ...xi Document Conventions ... xii Related Documentation ... xii Correspondence ... xiii Documentation Comments ... xiii World Wide Web... xiii Getting Help ... xiii SAFETY Overview ...xv Safety Requirements ... xvi CHAPTER 1 INTRODUCTION Overview... - Page 10 Contents Physical Properties ... A-1 Environmental Requirements... A-1 FEPIM Options... A-1 Regulatory Compliance... A-2 APPENDIX B FEPIM SPECIFICATIONS DELTX-UI... B-1 DELFX-UI... B-2 DELF3-UI ... B-3 viii DELHE-UA User’s Guide...
- Page 11 Figure DELHE-UA ... 1-1 Removing the FEPIM Coverplate... 2-3 Installing the FEPIM ... 2-4 Removing the HSIM Coverplate... 2-6 Installing the DELHE-UA ... 2-7 DELTX-UI Crossover Switch ... 2-11 Twisted Pair Cabling ... 2-12 DELHE-UA LANVIEW LEDs ... 3-1 DELTX-UI LED ... 3-2 DELTX-UI Pinouts ...B-1 DELFX-UI ...B-2 DELF3-UI ...B-3...
- Page 12 Tables Table FEPIM Options ...1-2 DELHE-UA LEDs ...3-2 10/100 LED Indications When RX LED Is On...3-3 10/100 LED Indications When RX LED Is Off...3-3 TABLES DELHE-UA User’s Guide Page...
-
Page 13: Preface
Welcome to the DIGITAL Fast Ethernet Interface Module DELHE-UA User’s Guide. This manual describes the DELHE-UA and provides information concerning features, installation, troubleshooting, information on Local Management, and specifications for the DELHE-UA. The DELVM-UA is a Fast Ethernet interface module. This manual refers to the DELHE-UA as an HSIM (High Speed Interface Module). -
Page 14: Document Conventions
Preface DOCUMENT CONVENTIONS Throughout this guide, the following symbols are used to call attention to important information. Note symbol. Calls the reader’s attention to any item of information that may be of special importance. Caution symbol. Contains information essential to avoid damage to the equipment. -
Page 15: Correspondence
CORRESPONDENCE Documentation Comments If you have comments or suggestions about this manual, send them to DIGITAL Network Products: Attn.: E-MAIL: World Wide Web To locate product-specific information, refer to the DIGITAL Network products Home Page on the World Wide Web at the following locations: North America: Europe: Asia Pacific:... -
Page 17: Safety
OVERVIEW Any warning or caution that appears in this manual is defined as follows: WARNING VORSICHT DANGER AVISO CAUTION ACHTUNG ATTENTION PRECAUCIÓN DELHE-UA User’s Guide SAFETY Warns against an action that could result in equipment damage, personal injury, or death. Warnt den Benutzer vor Aktionen, die das Gerät beschädigen, Personen verletzen oder sogar zum Tot führen könnten. -
Page 18: Safety Requirements
Safety SAFETY REQUIREMENTS The warnings or cautions that must be observed for the hardware described in this manual are listed below in English, German, French, and Spanish. WARNING VORSICHT DANGER AVISO WARNING VORSICHT DANGER AVISO WARNING VORSICHT Only qualified personnel should install or service this unit. - Page 19 DANGER AVISO WARNING VORSICHT DANGER AVISO DELHE-UA User’s Guide Safety Requirements Certains FEPIM utilisent des lasers de classe 1. Ne pas utiliser d’instruments optiques pour visualiser la sortie laser, car ces instruments augmentent les risques oculaires. Pour visual- iser le port optique, débrancher l'adaptateur secteur.
- Page 20 Safety CAUTION ACHTUNG ATTENTION PRECAUCIÓN CAUTION ACHTUNG ATTENTION PRECAUCIÓN xviii The DELVM-UA, FEPIM, and the host module or hub are sensitive to static discharges. Use an antistatic wrist strap and observe all static precautions during this procedure. Failure to do so could result in damage to this equipment Der DELVM-UA, FEPIMs und das Host-Modul bzw.
- Page 21 CAUTION ACHTUNG ATTENTION PRECAUCIÓN CAUTION DELHE-UA User’s Guide Safety Requirements Ensure that the FEPIM or DELVM-UA connector aligns with the DELVM-UA, module, or device connector pins to prevent bending the pins. Failure to do so can damage the DELVM-UA, FEPIM, module or device. Vergewissern Sie sich, daß...
- Page 22 Safety ACHTUNG ATTENTION PRECAUCIÓN Das Ende an beiden Seiten des Glasfaserkabels darf nicht berührt werden oder mit Staub, Schmutz und anderen Stoffen in Berührung kommen, die zur Verunreinigung führen und Datenübertragungsprobleme verursachen könnten. In einem solchen Fall müssen die Enden mit einem eigens dazu bestimmten Staubreiniger (z.B.
-
Page 23: Delhe-Ua
CHAPTER 1 INTRODUCTION The DELHE-UA has two Fast Ethernet ports in which Fast Ethernet (Port) Interface Modules (FEPIMs) can be installed. Figure 1-1 shows the DELHE-UA. DELHE-UA FEPIM 1 FEPIM 2 fepim_ports Ports 1 and 2 Figure 1-1 DELHE-UA OVERVIEW The DELHE-UA extends the functionality of certain DIGITAL interface modules by providing high-speed uplink capability through Fast Ethernet technology with different types of media. -
Page 24: Delhe-Ua Leds
Full Duplex Switched Ethernet mode. 1.1.4 LANVIEW Diagnostic LEDs Cabletron Systems provides a visual diagnostic and monitoring system called LANVIEW. The DELHE-UA LANVIEW LEDs help you quickly identify transmit and receive status. Chapter 3 provides information on the DELHE-UA LEDs and the DELTX-UI LED. -
Page 25: Chapter 2 Installation
To install the DELHE-UA the following items are required: • Antistatic wrist strap • Phillips screwdriver • Fast Ethernet (Port) Interface Modules (FEPIMs) in the appropriate media Before attempting to use the DELHE-UA you should be familiar with the IEEE 802.3, 802.3 10BASE-T, and 802.3u 100BASE-T Specifications. -
Page 26: Installing Fast Ethernet (Port) Interface Modules
Chapter 2: Installation 4. After removing the module from its antistatic bag, visually inspect the device. If you notice any sign of damage, contact a DIGITAL representative immediately. Save the antistatic bag in the event the module must be reshipped. INSTALLING FAST ETHERNET (PORT) INTERFACE MODULES Only qualified personnel should perform installation... -
Page 27: Removing The Fepim Coverplate
FEPIM Coverplate P I M Figure 2-1 Removing the FEPIM Coverplate Before installing a DELFX-UI or DELF3-UI module into the host module, remove the protective cover on the SC connector. 2. Refer to Figure 2-2. Gently pull the faceplate of the DELHE-UA forward to allow room for the FEPIM to be aligned over the connector. -
Page 28: Installing The Fepim
Chapter 2: Installation Figure 2-2 Installing the FEPIM 4. Press down firmly on the FEPIM until the pins slide all the way into the DELHE-UA connector. Ensure that the FEPIM seats flush on the standoffs. 5. Secure the FEPIM using the screws enclosed in the FEPIM packaging. The screw used to attach the rear of the FEPIM to the standoff is optional and not necessary for proper installation. -
Page 29: Installing The Delhe-Ua
INSTALLING THE DELHE-UA Only qualified personnel should install or service this unit. A DELHE-UA can be installed in any DIGITAL device that supports HSIMs (High Speed Interface Module) technology (e.g., DLE52-MA, DLE28-MA). Refer to the Release Notes for the version of firmware running on the DIGITAL host platform to ensure that the DELHE-UA is supported. -
Page 30: Removing The Hsim Coverplate
Chapter 2: Installation 5. Remove and save the two faceplate mounting screws securing the HSIM coverplate and remove the coverplate. See Figure 2-3. DELHE-UA Coverplate Faceplate Mounting Screws Figure 2-3 Removing the HSIM Coverplate 6. Refer to Figure 2-4 and place the DELHE-UA behind the module faceplate. -
Page 31: Installing The Delhe-Ua
Connector Cutaway view of connector DELHE-UA Faceplate Mounting Screws Figure 2-4 Installing the DELHE-UA 7. Align the connector on the DELHE-UA with the connector on the module. Ensure that the DELHE-UA connector aligns with the module connector pins to prevent bending the pins. This can damage both the DELHE-UA and the module. -
Page 32: Connecting To The Network
Chapter 2: Installation 9. Secure the DELHE-UA to the module faceplate using the mounting screws saved in Step 5. 10. Secure the DELHE-UA to the module standoffs using the standoff screws included in the DELHE-UA shipping materials. 11. Reinstall the interface module in the chassis. 12. -
Page 33: Connecting A Fiber Optic Segment To The Fepim
2.4.1 Connecting a Fiber Optic Segment to the FEPIM DIGITAL offers fiber optic cables that use SC style connectors which are keyed to ensure proper crossover of the transmit and receive fibers. An odd number of crossovers (preferably one) must be maintained between like devices so that the transmit port of one device is connected to the receive port of the other device and vice versa. -
Page 34: Connecting A Twisted Pair Segment
Chapter 2: Installation Do not touch the ends of the fiber optic strands, and do not let the ends come in contact with dust, dirt, or other contaminants. Contamination of the ends causes problems in data transmissions. If the ends become contaminated, blow the surfaces clean with a canned duster. -
Page 35: Deltx-Ui Crossover Switch
Position X (crossed over) 1. RX+ 5. NC 2. RX- 6. TX- 3. TX+ 7. NC 4. NC 8. NC Figure 2-5 DELTX-UI Crossover Switch A schematic of a straight-through and a crossover cable is shown in Figure 2-6. If the wires do not cross over, use the switch on the DELTX-UI to internally cross over the RJ45 port. -
Page 36: Twisted Pair Cabling
Chapter 2: Installation NOTE: RX+/RX– and TX+/TX– must share a common color pair. Figure 2-6 Twisted Pair Cabling Connect a DELTX-UI to a twisted pair segment as follows: 1. Ensure that the device connected to the other end of the segment is powered ON. - Page 37 b. Verify that the RJ45 connector on the twisted pair segment has the proper pinouts. c. Check the cable for continuity. d. Make sure that the twisted pair connection meets cable specifications outlined in Appendix B. e. Confirm that the crossover switch is in the correct position. If a link is not established, refer to Chapter 3, LANVIEW LEDs, for information before contacting a DIGITAL representative.
-
Page 39: Lanview Leds
This chapter describes how to use the LANVIEW LEDs to monitor the DELHE-UA status and diagnose DELHE-UA problems. DELHE-UA LEDs Refer to Figure 3-1 for the location of the DELHE-UA LEDs and Table 3-1 for a description of the LED indications. Transmit (TX) Receive (RX) LEDs for FEPIM 1... -
Page 40: Delhe-Ua Leds
Chapter 3: Color Green Green (Blinking) Amber (Flashing) Receive Red (Solid) Green (Flashing) Amber (Blinking) Transmit Red (Flashing) Red (Solid) DELTX-UI LED The optional DELTX-UI has one LED labeled 10/100. The 10/100 LED together with the RX LED allows the user to determine the link status and the operating speed of the Fast Ethernet (Port) Interface Module. -
Page 41: Delhe-Ua Local Management
A link exists if the associated port RX LED is on. Table 3-2 10/100 LED Indications When RX LED Is On Color 10/100 Green No link exists if the associated port RX LED is off. Table 3-3 10/100 LED Indications When RX LED Is Off Color 10/100 Green... -
Page 43: A.2 Environmental Requirements
DELHE-UA SPECIFICATIONS This chapter lists the specifications and regulatory requirements for the DELHE-UA. Cabletron Systems reserves the right to change these specifications at any time without notice. PHYSICAL PROPERTIES Dimensions Weight MTBF (Predicted) ENVIRONMENTAL REQUIREMENTS Operating Temperature Storage Temperature Operating Relative Humidity... -
Page 44: A.4 Regulatory Compliance
Appendix A: DELHE-UA Specifications REGULATORY COMPLIANCE This equipment meets the following safety and electromagnetic compatibility (EMC) requirements: Safety Electromagnetic Compatibility (EMC) UL 1950, CSA C22.2 No.950, EN 60950, IEC 950, and 73/23/EEC FCC Part 15, EN 55022, CSA C108.8, EN 50082-1, VCCI V-3, 89/336/EEC, and AS/NZS 3548 DELHE-UA User’s Guide... -
Page 45: B-1 Deltx-Ui Pinouts
FEPIM SPECIFICATIONS This appendix provides specifications for the Fast Ethernet (Port) Interface Modules. Cabletron Systems reserves the right to change these specifications at any time without notice. The DELHE-UA supports the following Fast Ethernet (Port) Interface Modules: the DELTX-UI, the DELFX-UI, and the DELF3-UI. -
Page 46: B-2 Delfx-Ui
Appendix B: FEPIM Specifications DELFX-UI The DELFX-UI shown in Figure B-2 uses an SC style connector that supports multimode fiber optic cabling. Specifications for the DELFX-UI are listed in Table B-1, below. Cable Type 50/125 µm fiber optic 62.5/125 µm fiber optic 100/140 µm fiber optic The transmitter power levels and receive sensitivity levels listed are peak power levels after optical overshoot. -
Page 47: B-3 Delf3-Ui
DELF3-UI The DELF3-UI shown in Figure B-3 uses an SC style connector that supports single mode fiber optic cabling. Specifications for the DELF3-UI are listed in Table B-2, below. Cable Type 8/125 µm fiber optic 12.5/125 µm fiber optic The transmitter power levels and receive sensitivity levels listed are peak power levels after optical overshoot. - Page 50 9032765 Printed in U.S.A.
