Chapter 2: Installation
5. Remove and save the two faceplate mounting screws securing the
HSIM coverplate and remove the coverplate. See Figure 2-3.
DELHE-UA
Coverplate
Faceplate Mounting Screws
6. Refer to Figure 2-4 and place the DELHE-UA behind the module
faceplate.
2-6
Figure 2-3 Removing the HSIM Coverplate
2555_03
DELHE-UA User's Guide
