- Page 1 EPIM-3PS Installation Guide Cabletron Systems, P.O. Box 5005, Rochester, NH 03866-5005 P/N 9031283-01...
-
Page 3: Fcc Notice
Rochester, NH 03866-5005 All Rights Reserved Printed in the United States of America Part Number: 9031283-01 November 1994 BRIM, EPIM-3PS, EMM-E6, ESXMIM, MicroMMAC, and NBR-420/620 are trademarks of Cabletron Systems, Inc. CompuServe is a registered trademark of CompuServe, Inc. FCC NOTICE This device complies with Part 15 of the FCC rules. -
Page 4: Doc Notice
Notice NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. - Page 5 BY UTILIZING THE ENCLOSED PRODUCT, YOU ARE AGREEING TO BECOME BOUND BY THE TERMS OF THIS AGREEMENT, WHICH INCLUDES THE LICENSE AND THE LIMITATION OF WARRANTY AND DISCLAIMER OF LIABILITY. IF YOU DO NOT AGREE TO THE TERMS OF THIS AGREEMENT, PROMPTLY RETURN THE UN- USED PRODUCT TO THE PLACE OF PURCHASE FOR A FULL REFUND.
-
Page 6: United States Government Restricted Rights
Notice 2. NO LIABILITY FOR CONSEQUENTIAL DAMAGES. IN NO EVENT SHALL CABLETRON OR ITS SUPPLIERS BE LIABLE FOR ANY DAMAGES WHATSOEV- ER (INCLUDING, WITHOUT LIMITATION, DAMAGES FOR LOSS OF BUSINESS, PROFITS, BUSINESS INTERRUPTION, LOSS OF BUSINESS INFORMATION, SPECIAL, INCIDENTAL, CONSEQUENTIAL, OR RELIANCE DAMAGES, OR OTH- ER LOSS) ARISING OUT OF THE USE OR INABILITY TO USE THIS CABLETRON PRODUCT, EVEN IF CABLETRON HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. - Page 7 • EPIM-3PS LEDs BRIM Installation Considerations You can install your EPIM-3PS in any device that supports both BRIM and EPIM technology (e.g., EMM-E6, MicroMMAC, ESXMIM or the NBR-420/620), but, the BRIM and the EPIM-3PS must go into equivalent slots in order to be correctly recognized by local management.
- Page 8 Refer to your BRIM documentation for specific BRIM and EPIM installation procedures. Note: On some devices, the EPIM slot is located under the BRIM slot. In these cases, install the EPIM-3PS and connect the internal Ethernet cable to the EPIM before installing the BRIM.
- Page 9 2.) Remove the coverplate or the EPIM (whichever applies). 3.) Slide your EPIM-3PS into place, making sure that the connectors on the rear of the EPIM are fully engaged with the connectors on the MIM.
-
Page 10: Installing The Epim-3Ps
Installing the EPIM-3PS Figure 1. EPIM-3PS Installation Page 4 EMM-E6 RESET STBY ETHERNET... - Page 11 BRIM is now ready for operation. Note: To disconnect the Ethernet cable from the EPIM-3PS, carefully insert a small flat screwdriver between the clip on the connector and the circuit board. Connecting the EPIM-3PS to a BRIM...
- Page 12 Connecting the EPIM-3PS to a BRIM EPIM-3PS Ethernet Cable BRIM Figure 2. Connecting a BRIM to the EPIM-3PS Page 6...
- Page 13 EPIM LED EPIM LED The EPIM-3PS has one amber LED that indicates a connection exists between the BRIM and EPIM-3PS. Connection LED Figure 3. EPIM-3PS LED Page 7...
-
Page 14: Getting Help
Getting Help If you have questions, or need additional help, contact Cabletron Systems Technical Support: By phone ® By CompuServe By Internet mail Page 8 Getting Help (603) 332-9400 Monday-Friday; 8am-8pm EST GO CTRON from any ! prompt support@ctron.com...
