Lanview Leds; Delhe-Ua Leds - Cabletron Systems Expansion module DELHE-UA User Manual

This chapter describes how to use the LANVIEW LEDs to monitor the
DELHE-UA status and diagnose DELHE-UA problems.
3.1

DELHE-UA LEDs

Refer to Figure 3-1 for the location of the DELHE-UA LEDs and
Table 3-1 for a description of the LED indications.
Transmit (TX)
Receive (RX)
LEDs for FEPIM 1
The terms flashing, blinking, and solid used in Table 3-1
indicate the following:
Flashing indicates an irregular LED pulse.
Blinking indicates a steady LED pulse (approximately 50% on
and 50% off).
Solid indicates a steady LED light. No pulsing.
DELHE-UA User's Guide
CHAPTER 3

LANVIEW LEDs

FEPIM 1
Receive (RX)
LEDs for FEPIM 2
Figure 3-1 DELHE-UA LANVIEW LEDs
FEPIM 2
Transmit (TX)
DELHE-UA
SP
3-1
