- Page 1 Lincoln Aperion 24 Impinger® Conveyor Oven Installation, Operation and Maintenance Manual FOR 60 HZ Original Instructions Part Number 4605890 Rev 0 July 2021...
-
Page 2: Safety Notices
Safety Notices Warning This appliance is not intended for use by persons DEFINITIONS (including children) with reduced physical, sensory or DANGER mental capabilities, or lack of experience and knowledge, unless they have been given supervision concerning use Indicates a hazardous situation that, if not avoided, will of the appliance by a person responsible for their safety. -
Page 3: Table Of Contents
Table of Contents Safety Notices ........................2 Definitions ........................2 Section 1 General Information Purchaser’s Responsibility ....................5 Additional Requirements ....................5 Section 2 Installation Exterior Dimensions ......................6 Utility Specifications ......................7 Canopy Ventilation Recommendations ................8 Installation Requirements ....................9 Gas Code Requirements .................... - Page 4 Table of Contents (continued) Section 4 Maintenance Operator Maintenance ....................24 Cleaning Instructions ..................... 24 Daily Cleaning ......................... 24 Weekly Cleaning ......................25 Conveyor Removal ......................25 Finger Removal ....................... 25 Preventive Maintenance ....................26 Section 5 Troubleshooting General Issues ......................... 27 UI Alarm Messages ......................
-
Page 5: General Information
The requirements of AS 5601 are to be used in conjunction with, but do not take precedence over, any check-out made by a Factory Authorized Servicer or a Lincoln statutory regulations that may apply in any area. -
Page 6: Installation
Section 2 Installation Exterior Dimensions 26.1875" (665 mm) ELECTRIC POWER CONNECTION LOCATION CONVEYOR ASSEMBLY 38.75" 24.8125" (984 mm) (630 mm) 63.5" (1613 mm) 48.4375" (1230 mm) DOOR SWING 26.4375" (672 mm) 48.5625" 37.9375" 10.6875" (1233 mm) 11.6875" (964 mm) (271 mm) (297 mm) 13.1875"... -
Page 7: Utility Specifications
Section 2 Installation Utility Specifications Electric Ovens Recommended Electrical Model Energy Power Voltage Current Phase Specification 2424E Electric 13 kW 208-240 VAC 4 Wires, 3 Line +G All ovens require separate service and dedicated neutral. Notice Do not install the (these) oven(s) in any area with an ambient temperature in excess of 95°F / 35°C. -
Page 8: Canopy Ventilation Recommendations
AFF = Above Finished Floor NOTE: The drawing shown is a typical installation and NOTE: Lincoln can provide oven spec sheets that show is intended to be a guideline. Hood dimensions and the the dimensions of the oven, kW or BTU ratings and other... -
Page 9: Installation Requirements
Section 2 Installation Installation Requirements ELECTRICAL CODE REQUIREMENTS Warning DANGER This appliance must be properly grounded at time All utility connections and fixtures must be maintained in of installation. Failure to ensure that this equipment accordance with local and national codes. is properly grounded can result in electrocution, dismemberment or fatal injury. -
Page 10: Spacing Requirements
When permitted by local code(s) and used with appropriate (1219 mm) clearance on the right hand side to allow for food products, Lincoln “ventless” ovens are not required conveyor removal, cleaning, and servicing. to be installed under a ventilation hood. For gas ovens, a... -
Page 11: Restraint Requirement - Oven(S) On Casters
Section 2 Installation RESTRAINT REQUIREMENT – OVEN(S) ON CASTERS • The installation shall be made with a gas connector that complies with the local codes for Connectors for Movable Gas Appliances, ANSI Z21.69 • CSA 6.16 latest version, and a quick disconnect device that complies with the local codes for Quick Disconnect Devices for Use with Gas Fuel, ANSI Z21.41 •... -
Page 12: Installation
The instructions that follow are intended as a guide 1. Using multiple people, a crane, or forklift remove the for preparing for the installation of the Lincoln Aperion oven from the crate carefully. (Caution) Do not lift from Impinger® oven. First and foremost, each crate should be the Left and Right Control Boxes. - Page 13 Section 2 Installation 4. To add a Top Unit to the Stack Assembly. Ensure that the Threaded Pins are installed at the corners of the bottom Stack Cover Taller of the Top Unit. With Holes Threaded Pin (4x) Leg Kit 4-Places 3.
-
Page 14: For Floor Installation
Installation Section 2 For Floor Installation 3. With the Bottom Unit on blocks, connect the Long Leg Kit to the bottom of the Bottom Unit in 4 places. 1. When placing the Oven on the floor, use the Long Leg Kit with Casters on the Bottom Unit. -
Page 15: Start-Up Checkout
Section 2 Installation 10. Install Loading and Offloading Trays (Loading Tray Marked with I, Offloading Tray Marked II). Loading Tray Conveyor Belt Offloading Tray 5. To add a Top Unit to the Stack Assembly. The Threaded Long Legs With Casters Pins are pre-installed at the corners of the bottom of the Top Unit. -
Page 16: Start-Up Procedures
LLC in order to insure the oven(s) is properly installed and in working order. The warranty becomes effective upon NOTE: Use Lincoln Smoke Candle #369361 (in Australia, an verification of proper installation. alternate method of coloring the air may be used). -
Page 17: Checklist
Section 2 Installation CHECKLIST Are the correct clearances maintained? Does the ventilation system meet the requirements? Are the legs and caster securely fastened? Is the unit level? Has the restraint been installed to prevent uncontrolled movement? ... -
Page 18: Operation And Programming
1. Ensure that your oven is connected to an electrical supply. Move the On/Off switch to the ON position • The display screen will energize and show the Lincoln oven model number and current software version. (Figure 1) This screen will transition after a few seconds to the Home Screen. -
Page 19: Eco Mode
Section 3 Operation and Programming Figure 4 Figure 6 2. The oven is now in pre-heat mode and the oven heaters ECO MODE will start-up. The temperature settings appear on the screen. You will see the temperature of the oven and Eco mode allows the operator to save energy by stopping the the temperature increasing up to the set-point. -
Page 20: Manual Mode
Operation and Programming Section 3 MANUAL MODE Manual mode allows the operator to change the temperature, upper and lower fan speeds, and cook time to revise or create a new recipe. CHANGING TEMPERATURE AND COOK TIME (BELT SPEED) 1. Press the Chef’s Hat or Manual mode button on the Home screen. - Page 21 Section 3 Operation and Programming 6. Save Recipe: Press the Save icon in the Manual Mode screen (Figure 16). The screen will transition to a numbered screen (Figure 17). Select the Recipe number and press the check mark. The icon and border color can be changed by selecting the Change Icon and/or Change Color buttons (Figure 18).
-
Page 22: Settings Mode
Operation and Programming Section 3 3. Temperature Unit of Measure - Touch the white circle in SETTINGS MODE the oval button on the Settings display that shows the Settings mode allows the operator to change the oven temperature measure. The Fahrenheit or Celsius symbol settings such as Temperature unit of measure or Belt will change to correspond to the desired temperature direction. -
Page 23: Oven Shut Down
Section 3 Operation and Programming Figure 25 OVEN SHUT DOWN 1. To shut down your oven, press the Back Button to return to the Home screen. The conveyor should stop moving; however, the cooling fan will continue to run if the oven is hot. -
Page 24: Maintenance
1. Clean exterior surfaces of the oven by wiping down However, to achieve the maximum efficiency of the oven, it with Lincoln Oven Cleaner or a mild detergent and clean is necessary to keep it clean. For cleaning instructions, see water, or a commercial stainless cleaner. -
Page 25: Weekly Cleaning
Clean all exterior surfaces of door and pass through window (available option on future models) with Lincoln Oven Cleaner and rinse with clean The Lincoln Aperion Impinger® oven comes with 4 identical finger assemblies comprising a housing and cover and water. -
Page 26: Preventive Maintenance
Maintenance Section 4 3. Remove top 2 housings first, then bottom 2 housings. 5. Re-assemble and re-install in reverse order. Ensure return air baffles are installed between top and bottom finger assemblies. Bottom Finger Assembly 4. Disassemble fingers by sliding cover off the housing. Preventive Maintenance NOTE: Components are tight fitting. -
Page 27: Troubleshooting
Section 5 Troubleshooting General Issues Problem Cause Correction UI blank Oven not plugged in, panel breaker tripped Check panel breaker and plug Fuses failed Replace fuses on back panel Component failure Call for service UI screen locked up, frozen, Software issue Turn OFF the unit using the power switch, nonresponsive to touch turn the unit back ON after 20 seconds. -
Page 28: Ui Alarm Messages
The name and phone number of the Factory Authorized Servicer should be located on the oven or contact The Lincoln Aperion Impinger® oven includes 3 safety KitchenCare Technical Service Department at (844) 724-2273 thermal cut-out switches for your protection. The oven High for the name of the nearest agency. - Page 29 The foregoing NOT WARRANT ANY PRODUCTS OR SERVICES OF OTHERS. shall be the sole obligation of Lincoln under this Limited Warranty with respect to the equipment, products and services. With respect to equipment, materials, parts and REMEDIES accessories manufactured by others, Lincoln’s sole obligation shall be to use reasonable...
- Page 30 LINCOLN 11200 AIRPORT NORTH OFFICE PARK STE. A&B, FORT WAYNE, IN 46825 844-724-2273 WWW.LINCOLNFP.COM ©2021 Welbilt, Inc. except where explicitly stated otherwise. All rights reserved. Part Number 4605890 Rev 0 July 2021...
