Product Features; Operation Instruction - Fenix HM50R V2.0 User Manual

Note: According to
Submersible
the ANSI/PLATO
FL1 standard, the
above specifications are from the results produced by Fenix through its laboratory testing using one Fenix ARB‐L16‐
700P rechargeable Li‐ion battery under the temperature of 21±3°C and humidity of 50% ‐ 80%. The true
performance of this product may vary according to different working environments and the actual battery used.
* The Turbo output is measured in a total of runtime including output at reduced levels due to temperature or
protection mechanism in the design.
Product Features

700 lumens maximum output; 115 meters maximum beam distance.

Cree XP‐G3 S4 white light LED with a lifespan of 50,000 hours.

Included a 16340 rechargeable LI‐ion battery.

Detachable structure ‐ can be used as a flashlight.

White and red lights

USB Type‐C charging port for easy and fast charging.

Lockout function avoids accidental activation.

Made of durable A6061‐T6 aluminum.

Premium type HAIII hard‐anodized anti‐abrasive finish.

Size: 2.52'' x 1.42'' x 1.26'' / 64 x 36 x 32 mm.

Weight: 2.75 oz / 78 g (including battery and headband).
Operation Instruction
