2.2 Parent Unit (primarily in receiver mode)
2.2.1 Power:
Powered by rechargeable NiMh 2x1.2V, 750 mAh
type AAA batteries (13) (included) or by switch-
ing mains adaptor 100-240V ~ 50/60Hz / 6V,
500mA.
WARNING: Rechargeable batteries must only be
recharged using the mains adaptor (1) supplied
in the pack.
WARNING:
- The mains adaptor (1) cable and carry strap (14)
must be kept out of children's reach at all times.
They can constitute strangulation risks.
- Inspect the mains adaptors (1) periodically; if
the power cable or the plastic parts of the mains
adaptor are damaged, do not use them and con-
tact an Artsana SpA's qualified expert.
- Never leave the adaptors (1) connected to the
mains when the devices are not in use and/or not
connected to the adaptors themselves.
2.2.2 User Instructions – Switching on and Ad-
justments
- ON/OFF button on the parent unit (primarily in
receiver mode) (2).
Press the ON/OFF button (2) for around 2 sec-
onds to turn the parent unit (primarily in receiver
mode) ON. Do not press the button for longer
otherwise the parent unit may not switch on.
Press it again for around 2 seconds to turn the
parent unit (primarily in receiver mode) OFF.
• Volume adjustment button
Press the button toward "+" to increase the vol-
ume by one level.
Press the button (3) toward "-" to decrease the
volume by one level.
The unit will beep each time you increase or
decrease the volume level. When the volume
reaches its maximum or minimum levels, it will
beep twice.
The device stores the selected and previously used
volume level in its memory bank.
Note: The device has 8 volume levels. The factory
default sound level is 5.
• Voice activated mode or continual transmission
mode switch (8)
If the switch is set to "OFF", the two units will op-
erate in continuous transmission mode
If the switch is set to "ON", the child unit will
operate in voice activated mode; the speaker (6)
+ -
(3).
on the parent unit (primarily in receiver mode)
will only switch on when it picks up sounds from
the child unit (primarily in transmitter mode) mi-
crophone (5), and will then switch off after a few
seconds if no sound is received.
• Talk-back button to activate the parent-baby
"TALK" option (9)
Press this button (9), to switch the parent unit
from receiver mode to transmitter mode and
communicate with the baby through the inte-
grated microphone (7).
This will simultaneously switch the child unit
(primarily in transmitter mode) from transmission
to receiver mode. The loudspeaker (6) on the child
unit will automatically reproduce the voice trans-
mitted from the parent unit.
On releasing the button (9), the parent unit
switches back to receiver mode (its primary func-
tion) and the child unit automatically switches
back to its primary transmission function mode.
• Portable option for the parent unit
The parent unit is fitted with a carry strap (14)
which makes it practical to carry around.
2.2.3 Luminous and acoustic operating status
indicator
The 2-coloured LED (5) provides 3 different types
of information:
• power ON indicator and correct connection to
the child unit indicator; The 2-coloured LED (5)
is green.
NOTE. If the parent unit is not able to establish a
connection with the child unit or the connection is
lost, the 2-coloured LED (5) is green and will blink
twice every second until it re-establishes a con-
nection. Moreover, after 10 seconds it will beep
twice a second.
• Rechargeable battery (13) low battery indica-
tor: the 2-coloured LED (5) is red and blinks twice
every second and it will beep once a second. If
you wish to continue using the device, it is recom-
mended to charge the rechargeable batteries (13),
otherwise the device will stop working.
Charge the batteries using the mains adaptor
supplied in the pack (1), the warning signal will
be disabled.
Rechargeable battery charge status indicator (13):
the 2-coloured LED (5) is RED.
When recharging is complete, the 2-coloured LED
(5) will switch OFF if the parent unit is OFF whilst
recharging; it will go GREEN if the parent unit is
ON whilst recharging.
