The beeping switches off when the rechargeable
batteries are being charged.
7. Integrated Microphone
8. Voice activated mode or continual transmission
mode switch
9. Talk-back button to activate the parent-baby
communication mode ("TALK" function)
10. Battery compartment cover
11. Carry strap slots
12. Power and/or rechargeable battery charger
socket ((6V
13. NiMh 2x1.2V, 750 mAh type AAA rechargea-
ble batteries (included) via switching mains adap-
tor 100-240V ~ 50/60Hz / 6V, 500mA.
14. Carry strap
2. Description of the characteristics
2.1 Child Unit (primarily in transmitter mode)
2.1.1 Power:
Powered by mains adaptors 100-240V ~ 50/60Hz
/ 6V , 500mA or 2 AAA alkaline batter-
ies (not included).
If powered by a mains adaptor (1):
• insert the mains adaptor plug (1) into the socket
(9) on the side of the unit,
• check that the voltage used by the electrical sys-
tem corresponds to that indicated on the adaptor
plates (1) indicated above.
- plug the mains adaptor (1) into an easy to reach
mains socket.
WARNING
- The mains adaptor (1) cable can strangle
children and must be kept out of their
reach at all times.
- Inspect the mains adaptors (1) periodically; if the
power cable or the plastic parts are damaged, do
not use them and contact a qualified expert.
- Never leave the adaptors (1) connected to the
mains when the devices are not in use and/or not
connected to the adaptors themselves.
2.1.2 Instructions for use – Switching on and
Sound Adjustments
The child unit (primarily in transmitter mode)
should be placed about 1 – 1.5 metres from the
child, on a flat and stable surface, with the micro-
phone (5) facing the child.
Warning: the child unit, mains adaptor (1) and the
power cable must be kept out of children's reach.
TALK
500mA)
- ON/OFF button on the child unit
Press the ON/OFF button (2) for around 2 sec-
onds to turn the child unit (primarily in transmit-
ter mode) ON. Do not press the button for longer
otherwise the child unit may not switch on. Press
it again for around 2 seconds to turn the child unit
(primarily in transmitter mode) OFF.
• Nightlight ON/OFF button
Press the ON/OFF button (3) for around 2 sec-
onds to turn the nightlight ON.
Do not press the button for longer otherwise the
nightlight may not switch on. When the child unit
(primarily in transmitter mode) is alkaline bat-
tery powered only, the nightlight (3) switches off
automatically after 5 minutes. If the child unit
(primarily in transmitter mode) is powered by the
mains adaptor (1), the night light (3) will remain
ON until the button (3) is pressed again.
• Volume adjustment button
This regulates the reception volume of sound
from the parent unit if the talk-back function
is enabled;
Press the button toward "+" to increase the
volume by one level.
Press the button toward "-" to decrease the
volume by one level.
When the volume reaches its maximum or mini-
mum levels, it will beep twice.
The device stores the selected and previously
used volume level in its memory bank.
Note: The device has 8 volume levels. The factory
default sound level is 5.
2.1.3 Luminous operating status indicator
The 2-coloured LED (4) provides two different
types of information.
• power ON indicator and correct connection to
the parent unit indicator;
The 2-coloured LED (4) is green.
NOTE. If the child unit is not able to establish a
connection with the parent unit or the connection
is lost, the 2-coloured LED (4) is green and will
blink twice every second until it re-establishes a
connection.
• 1.5V AAA alkaline batteries (not supplied in the
pack) are low: the 2-coloured LED (4) is green and
blinks twice every second.
