Summary of Contents for Altimium FO1DV-4K
- Page 1 User Manual FO1DV-4K Mini 4K DVI Fiber Extender All Rights Reserved Version: FO1DV-4K...
-
Page 2: Fcc Statement
4K DVI Optical Fiber Extender Preface Read this user manual carefully before using this product. Pictures shown in this manual is for reference only, different model and specifications are subject to real product. This manual is only for operation instruction only, not for any maintenance usage. The functions described in this version are updated till August 2016. -
Page 3: Safety Precautions
4K DVI Optical Fiber Extender SAFETY PRECAUTIONS To insure the best from the product, please read all instructions carefully before using the device. Save this manual for further reference. ⚫ Unpack the equipment carefully and save the original box and packing material for possible future shipment ⚫... -
Page 4: Package List
4K DVI Optical Fiber Extender Introduction This product is a mini DVI optical fiber extender for 4K resolution. It contains a transmitter module and a receiver module. Compatible with HDMI1.4, it transmits high-definition DVI/ HDMI (max 3840x2160@30Hz) up to 300m/ 1km over qualified OM3 multi-mode/ single mode cable. - Page 5 4K DVI Optical Fiber Extender Receiver: ② Link led: Illuminate blue when connected with source; blink blue when capturing EDID data There are a Power led on its rear panel, it will illuminate red when powered on. ③ Power: Insert a DC 5V 1A power adapter here ④...
-
Page 6: Specification
4K DVI Optical Fiber Extender Important to know: 1) To ensure normal and reliable transmission, plug the DVI display to the DVI In port of the transmitter, and stick the EDID Reader to manually capture the EDID data of the display. -
Page 7: Troubleshooting And Maintenance
4K DVI Optical Fiber Extender Troubleshooting & Maintenance Problems Causes Solutions Color losing or vague/ Poor quality of the optical Change for qualified OM3 double image in HDMI fiber cable cable. display Not been powered Power up the unit Power led is off, operations Make sure power adapter don’t work Poor contact of power port... -
Page 8: After Sales Service
4K DVI Optical Fiber Extender After-sales Service If there appear some problems when running the device, please check and deal with the problems referring to this user manual. Any transport costs are borne by the users during the warranty. 1) Product Limited Warranty: We warrant that our products will be free from defects in materials and workmanship for two years, which starts from the first day you buy this product (The purchase invoice shall prevail).
