Figure 2.6 Removing the mobile SATA HDD trays/ 移除可移动 SATA HDD 托架 / 移除
可移動 SATA HDD 托架
Attaching the Ears and Handles / 安装耳柄
2.4
There are two ears and two handles in the accessory box. If you need to install them,
please refer to Figure 2.11 and simply fasten them to the front-right and front-left cor-
ners with the screws provided.
附件盒里有一对耳柄。请参考图 2.11 将耳柄安装在机箱前面板的左右两端，并用提供
的螺丝进行固定。
附件盒裡有一對耳柄。請參考圖 2.11 將耳柄安裝在主機殼前面板的左右兩端，並用提
供的螺絲進行固定。
Figure 2.7 Attaching the Ears and Handles/ 安装耳柄
HPC-7120S User Manual/ 用户手册
13
