- Page 1 User Manual HPC-5000M Small Tower Server Chassis for ATX/Mini ITX Motherboard ATX/Mini ITX 主板专用的小型直立 式服务器机箱 ATX/Mini ITX 主板專用的小型直立 式伺服器機箱...
- Page 2 No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd. Information provided in this manual is intended to be accurate and reliable. How- ever, Advantech Co., Ltd.
- Page 3 On-line Technical Support/ 在线技术支持 / 線上技術支 援 For technical support and service, please visit our support website at: http://support.advantech.com 如需技术支持和服务，请访问研华公司的网站： http://support.advantech.com.cn 若需技術支援及其它服務，請連結研華公司的支援網站： http://support.advantech.com Instructions/ 安全指示 Read these safety instructions carefully. Keep this User Manual for later reference. Disconnect this equipment from any AC outlet before cleaning. Use a damp cloth.
- Page 4 CAUTION: The computer is provided with a battery-powered real-time clock cir- cuit. There is a danger of explosion if battery is incorrectly replaced. Replace only with same or equivalent type recommended by the manufacture. Discard used batteries according to the manufacturer’s instructions. THE COMPUTER IS PROVIDED WITH CD DRIVES COMPLY WITH APPRO- PRIATE SAFETY STANDARDS INCLUDING IEC 60825.
- Page 5 设备内部有液体流入； 设备曾暴露在过于潮湿的环境中使用； 设备无法正常工作，或您无法通过用户手册来使其正常工作； 设备跌落或者损坏； 设备有明显的外观破损。 注意：计算机配置了由电池供电的实时时钟电路，如果更换错误的电池，将有爆 炸的危险。因此，只可以使用制造商推荐的同一种或者同等型号的电池进行替 换。请按照制造商的指示处理旧电池。 计算机提供的 CD 光盘驱动，已符合各种安全标准，包括 IEC 60825。 CLASS I LASER PRODUCT KLASS I LASER PRODUKT 本设备符合 FCC 规则第 15 款的规定。操作受如下两个条件限制： (1) 本设备不得产生有害的干扰，而且 (2) 本设备必须能经受干扰，包括可能引起意外操作的干扰。 注意：无论何时进行操作，请务必完全断开机箱电源。不可在电源接通时进行设 备连接，以避免瞬间电涌损坏敏感电子元件。只有专业技术人员才可以打开机 箱。 注意：接触产品的母板、无源底板或附加卡前，请先确保您接地来移除身上附带 的静电。由于现在的电子设备对静电十分敏感，为了安全起见，请使用接地腕 环。请将所有电子元件放在无静电的表面或静电屏蔽袋中。 注意：未经专业认可的元件会损坏设备。请使用附件盒中提供的元件 （如螺丝） 以确保正确的安装。 請仔細閱讀此安全操作說明。 請妥善保存此用戶手冊供日後參考。...
- Page 6 Advantech has come to be known. Your satisfaction is our primary concern. Here is a guide to Advantech’s cus- tomer services.
- Page 7 Because of Advantech’s high quality-control standards and rigorous testing, most of our customers never need to use our repair service. If an Advantech product is defec- tive, it will be repaired or replaced at no charge during the warranty period. For out- of-warranty repairs, you will be billed according to the cost of replacement materials, service time and freight.
- Page 8 Call your dealer and describe the problem. Please have your manual, product, and any helpful information readily available. If your product is diagnosed as defective, obtain an RMA (return merchandise authorization) number from your dealer. This allows us to process your return more quickly.
- Page 9 Initial Inspection/ 初始检查 / 初始檢查 When you open the carton, please make sure that the following materials have been shipped: Chassis User Manual Warranty Card Accessory box with a package of screws (for fastening the motherboard, Stan- dard type optical disk drive, other disk drives), a 2.5"...
- Page 10 HPC-5000M User Manual / 用户手册...
-
Page 11: Table Of Contents
Contents/ 目录 / 目錄 Chapter General Information 概述 產品資訊 ......1 Introduction/ 产品简介 / 產品簡介 ........2 Specifications/ 产品规格 / 產品規格 ........2 Power Supply Options/ 电源选项 / 電源選項 ......3 Table 1.1: Power supply options/ 电源选项 / 電源選項 ..3 Environmental Specifications/ 环境规格 / 環境規格 ....4 Table 1.2: Environment specifications/ 环境规格... - Page 12 Figure A.1 Exploded Diagrams& Parts List/ 分解图 & 部件列表 / 分 解圖 & 零件表 ......... 16 Table A.1: Parts list/ 部件列表 / 零件表 ....17 HPC-5000M User Manual / 用户手册...
-
Page 13: Chapter 1 General Information 概述 產品資訊
Chapter General Information 概述 產品資訊... -
Page 14: Introduction/ 产品简介 / 產品簡介
Introduction/ 产品简介 / 產品簡介 The HPC-5000M series is a small tower server chassis designed for video, AOI, workstation or medical applications which have high performance and low noise requirements. With the latest industrial design, HPC-5000M represents a break- through from the traditional, rigid concept of industrial PCs, and provides users with both a quiet and a stable operating platform. -
Page 15: Power Supply Options/ 电源选项 / 電源選項
100,000 hours 100,000 hours MTBF (80% load; 25°C) (100% load; 25°C) Safety 安规认证 UL/TUV/CB/CCC/BSMI/KCC UL/TUV/CB/CCC/BSMI/KCC 安規認證 Caution! Power supply options and specifications are subject to the product data- sheet on Advantech website. 请以研华公司官方网站公告的该机箱产品型录上的电源选项料号与电源 规格为准。 請以研華公司官方網站公告的該機箱產品型錄上的電源選項料號與電源 規格為準。 HPC-5000M User Manual / 用户手册... -
Page 16: Environmental Specifications/环境规格/環境規格
Environmental Specifications/环境规格/環境規格 Table 1.2: Environment specifications/ 环境规格 / 環境規格 Environment Operating Non-operating 环境 工作 非工作 環境 Temperature 温度 0 ~ 40° C (32 ~ 104° F) -40 ~ 70° C (-40 ~ 158° F) 溫度 Humidity 湿度 10 ~ 95% @ 40° C, non-condensing 10 ~ 95% @ 60° C, non-condensing 濕度... -
Page 17: Dimension Diagram/ 产品尺寸 / 產品尺寸
Dimension Diagram/ 产品尺寸 / 產品尺寸 Figure 1.1 Dimension diagram/ 产品尺寸 / 產品尺寸 HPC-5000M User Manual / 用户手册... - Page 18 HPC-5000M User Manual / 用户手册...
-
Page 19: Chapter 2 System Setup 系统安装 系統安裝
Chapter System Setup 系统安装 系統安裝... -
Page 20: Removing The Side Cover/ 移除侧盖 / 移除側蓋
Note! Use caution when installing or operating the components with the chas- sis open. Be sure to turn off the power, unplug the power cord and ground yourself by touching the metal chassis before you handle any components inside the machine. 机箱打开时，请小心安装或操作机箱内部组件。请务必关闭机箱电源并... -
Page 21: Installing Motherboard/ 安装母板 / 安裝主機板
Installing Motherboard/ 安装母板 / 安裝主機板 Figure 2.2 Installing Motherboard/ 安装母板 / 安裝主機板 Installing Disk Drives/ 安装磁盘驱动器 / 安裝磁碟機 Installing 3.5" HDD / 安装 3.5" 硬盘 / 安裝 3.5" 硬碟 2.3.1 Figure 2.3 Installing 3.5" HDD / 安装 3.5" 硬盘 / 安裝 3.5" 硬碟 HPC-5000M User Manual / 用户手册... -
Page 22: Installing 2.5" Hdd / 安装 2.5" 硬盘 / 安裝 2.5" 硬碟
Installing 2.5" HDD / 安装 2.5" 硬盘 / 安裝 2.5" 硬碟 2.3.2 Figure 2.4 Installing 2.5" HDD / 安装 2.5" 硬盘 / 安裝 2.5" 硬碟 When the length of expansion card is longer than 8.5" (21.6cm), we suggest to use a 2.5"... -
Page 23: Chapter 3 Operation 操作
Chapter Operation 操作... -
Page 24: The Front And Rear Panel / 前后面板 / 前後面板
The Front and Rear Panel / 前后面板 / 前後面板 Front side view / Rear side view / 前面板 后面板 / 後面板 Slim ODD Tray / 薄型ODD托架 300/500W Single PSU / 300/500W单PSU / 300/500W單PSU Rear IO space / 后部IO / 後部 12cm system fan / Power button / 12cm系统风扇... -
Page 25: The Inner View/ 內视图 / 內視圖
Figure 3.2: Power cord plugs should have same orientation in the socket/ 插座上电源线方向相同 / 插座上的電源線方向應相同 The Inner View/ 內视图 / 內視圖 Slim ODD device (optional) / Keylock bracket / Keylock 3.5” HDD space / 3.5” HDD 3.5” HDD 300/500W Single PSU / 300/500W PSU / 300/500W PSU 12cm system f an /... - Page 26 HPC-5000M User Manual / 用户手册...
-
Page 27: Exploded Diagram& Parts List
Appendix Exploded Diagram& Parts List 分解图 & 部件列表 分解圖 & 零件表... -
Page 28: Exploded Diagram& Parts List/分解图&部件列表/ 分解圖 & 零件表
Exploded Diagram& Parts List/分解图&部件列表/ 分解圖 & 零件表 Figure A.1 Exploded Diagrams& Parts List/ 分解图 & 部件列表 / 分解圖 & 零件表 HPC-5000M User Manual / 用户手册... - Page 29 Table A.1: Parts list/ 部件列表 / 零件表 Main chassis Air filter bracket 机箱本体 防尘棉架 機殼本體 防塵棉架 Power supply unit HDD bracket 电源模块 硬盘支架 電源模組 硬碟支架 Side cover Slim ODD bracket 侧盖 薄型光驱支架 側蓋 薄型光碟機支架 Chassis feet Front USB port cable 机箱脚垫...
- Page 30 No part of this publication may be reproduced in any form or by any means, electronic, photocopying, recording or otherwise, without prior written permis- sion of the publisher. All brand and product names are trademarks or registered trademarks of their respective companies. © Advantech Co., Ltd. 2017 www.advantech.com.cn 使用前请检查核实产品的规格。本手册仅作为参考。 产品规格如有变更，恕不另行通知。 未经研华公司书面许可，本手册中的所有内容不得通过任何途径以任何形式复制、翻...
