H-7983
BANDAGE DISPENSER

TOOLS NEEDED

Drill
Drill Bit
Dispenser x 1

SCREW MOUNTING

1.
Using the key, push release latch to open front cover
of dispenser. The latch is located on the top edge in
the center. (See Figure 1)
Figure 1
PAGE 1 OF 6
1-800-295-5510
uline.com
Phillips Screwdriver
Rubber Mallet

PARTS

Key x 1
Wall Anchor x 2

MOUNTING INSTRUCTIONS

Screw x 2
2. Pop out hole plugs. (See Figure 2)
Figure 2
3. Hold dispenser to ideal mounting place on wall.
4. Mark two locations on wall where screws will be
inserted.
Para Español, vea páginas 3-4.
Pour le français, consulter les pages 5-6.
Adhesive Strip x 2
0621 IH-7983
