π
H-7682
RUBBERMAID
®
FRESHENER DISPENSER
TOOLS NEEDED
Phillips Screwdriver Bit
Electric Drill
Dispenser x 1
1.
Locate cover release button on right side of dispenser.
While holding in cover release button with one hand,
flip cover down with opposite hand. (See Figure 1)
Figure 1
2. Insert two "C" batteries (not included) with the "+"
side up into the battery compartment of dispenser.
(See Figure 2)
Figure 2
PAGE 1 OF 4
1-800-295-5510
uline.com
AIR
Screw x 2
2
1
PARTS
Wall Anchor x 2
SETUP
3. If nothing appears on the screen, push
on/off button. (See Figure 3)
Figure 3
4. Adjust settings using buttons inside dispenser.
(See Figure 4)
Figure 4
Alcohol Swab x 1
0219 IH-7682
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for U-Line Rubbermaid H-7682
Summary of Contents for U-Line Rubbermaid H-7682
- Page 1 π H-7682 1-800-295-5510 uline.com RUBBERMAID ® FRESHENER DISPENSER TOOLS NEEDED Phillips Screwdriver Bit Electric Drill PARTS Dispenser x 1 Screw x 2 Wall Anchor x 2 Alcohol Swab x 1 SETUP Locate cover release button on right side of dispenser. 3.
- Page 2 SETUP CONTINUED 5. If desired, turn beeping tone on or off by using the CHANGE CURRENT TIME TONE button. (See Figure 5) 1. To set current time, press MODE until the time screen is shown. Use ADJUST to set current time. When finished, press ENTER until home screen is displayed.
- Page 3 SETUP CONTINUED SET CURRENT DAY OF THE WEEK SET TO WORK 5, 6 OR 7 DAYS PER WEEK 1. To select days on/off for dispenser, push MODE until 1. To select 5, 6 or 7 days per week operation, push second day screen appears.
- Page 4 SETUP CONTINUED MOUNTING 4. Press on/off button to turn dispenser off. 5. Insert refill can with spray nozzle facing out of the Use the alcohol swab to clean the area of the wall dispenser and away from wall. (See Figure 13) where dispenser will be placed.
