Digital Watchdog MEGApix IVA DWC-MB48WiAT User Manual page 84

Specification -
Spec.
CAMERA
Image sensor 1/2.8" 4K CMOS
Total pixels 3952 (H) x 2320 (V)
Focal length 2.7 ~ 13.5mm, F1.4 / MFZ, P-Iris
D: 38.2° ~ 105°
Horizontal angle H: 33.1° ~ 90.3°
V: 18.9° ~ 49°
Auto, manual (1/15 ~ 1/32000),
Shutter speed anti-flicker, slow shutter (off, 2X,
3X, 5X, 6X, 7.5X, 10X)
MIN. illumination 0.09 lux, 0 lux with IR (F1.4)
IR H6IR, 140ft
Day and night TDN (True Day and Night)
WDR WDR (DOL)
Optical zoom X5 Optical
DNR 3D-DNR
Privacy zone 16 programmable zones
AGC Auto
Other image Configurable exposure, white
processing balance, sharpness
ENCODER (VIDEO AND AUDIO)
Video compression H.264, H.265, MJPEG
H.264 profile BP / MP / HP
H.265 profile MP
H.265: QFHD/1080p/720p/VGA/
D1/CIF
Multiple profile
H.264 QFHD/1080p/720p/VGA/
streaming
D1/CIF
performance
MJPEG: 1080p/720p/800x600/
VGA/768x432/D1/CIF
100kbps ~ 10Mbps, multi-rate for
Video bitrate
Preview and Recording
Multistreaming CBR/VBR at H.264,
Bitrate control H.265 (controllable frame rate and
bandwidth)
Edge storage Micro SD
I/O AND EVENT
Audio in/out
Alarm in/out
Video output
(2nd video out)
Event notification
SECURITY AND NETWORK
Network protocol
Security
Plug in
GENERAL
Power
Operating
temperature
Material
Dimensions
Weight
Certification
83
1 (1.0Vrms, 3kΩ) / 1
1 / 1
1 CVBS 1.0V p-p (75Ω), 4:3 aspect
ratio
FTP, email, alarm out, SD card
IPv4: TCP/IP / UDP / AutoIP /
RTP(UDP/TCP) / RTSP / NTP /
HTTP / HTTPS / SSL / DNS /
DDNS / DHCP / FTP / SMTP /
ICMP / SNMPv1/v2/v3(MIB-2) /
ONVIF
HTTPS (TLS), IP filtering, 802.1x,
Digest Authentication (ID/PW)
CGI API, ONVIF
DC12V: max 10.2W
POE IEEE 802.3at: max 16W
(Adaptor is not Included)
-40°F ~ 122°F (-40°C ~ 50°C)
Aluminum die-casting
12.2" x 3.81" (310 x 97mm)
2.64 lbs (1.2 kg)
FCC, CE, ROHS, IP67-rated
