Digital Watchdog MEGApix IVA DWC-MB48WiAT User Manual page 66

Setup - System Setup
Firmware Update
1
2
3
Version Information - It shows the current Firmware Version in the system.
1
Web Update - Select the Firmware file on your computer by clicking the [Select file] button.
2
Start F/W Update - Click this button to start the update. Progress of uploading will be displayed using
3
Progress Bar. If you assign the wrong file name, an error message will be shown.
Warning:
1. Do not turn off the power to the camera during the firmware update. Interrupting the update may
cause the system to become unstable. Once the update is completed, the system will reboot
automatically.
2. Make sure to check the 'Notice' shown on the screen.
If the firmware update is completed successfully, the camera will reboot and show the login window.
65
