Setup - Camera Setup
Camera Day and Night Settings
1
2
3
4
5
6
7 7
Day and Night
1
• Auto: In this mode, the IR cut filter is removed automatically depending on the light condition around.
• Day: In this mode, the IR cut filter is applied to the image sensor all the time. Thus, the sensitivity will be
reduced in the dark light condition, but better color reproduction performance is obtained.
• Night: In this mode, the IR cut filter on the image sensor is removed all the time. The sensitivity will be
enhanced in the dark light condition, but the image is black and white.
• Schedule: In this mode, Day/Night mode is converted accordance with the scheduled time.
Color Level - This level determines when the camera will change from Night mode (B/W) to Day mode (color)
2
while set to Auto. The lower that this value is set, the lower the lighting threshold requirement will be for the
transition.
B/W Level - This level determines when the camera will change from Day mode (color) to Night mode
3
(B/W) while set to Auto. The lower that this value is set, the lower the lighting threshold requirement will be
for the transition.
Transition Time - If it is set to Auto, to determine the rate at which Day/Night is converted.
4
If it is set to schedule mode, Set the time that Day/Night is converted.
5
IR Mode - turn the built-in IR LEDs on or off manually.
6
Click 'Save' to save all settings.
7
Click 'Cancel' to return to the previous setting.
Click 'Default' to settings to the factory defaults.
