Digital Watchdog MEGApix IVA DWC-MB48WiAT User Manual page 14

Web Viewer Screen -
Basic Screen
2
3
4
5
The web viewer is optimized with Internet Explorer 10 (or above) and Mozilla Firefox.
"If VLC is not installed or the VLC plugin is not supported (Chrome), 'Live Buffering' and 'Channel Select'
(subjects 3 and 4 in the diagram) will display as 'Live Viewer'. If so, select HTML5 (MJPEG) from the Live
Viewer menu to view the video.
Live video display. This is the region for the live video stream from the camera.
1
Setup a popup button. Click it to open the Setup page to setup details of the IP camera like Video, Network,
2
Events, System, etc. See the section 'Setup'.
When the image is distorted due to a bad network connection, the stored image frames will display live
3
images, depending on the set buffer time.
Users will see the delayed images based on the set delay time.
Channel Select button. Select a stream produced from the camera between Stream 1 ~ 3 to display it in the live
4
view screen.
Refer the 'Setup > Video & Audio > Video' to setup the Video Stream.
Below "Menu" is supported per model.
5
PTZ Control - This camera model does not support zoom and focus.
Preset - Not supported.
Speaker Control - Enable/disable the audio stream from the camera and adjust the volume accordingly.
Alarm Input - If an alarm is triggered, the corresponding input number will be changed from dark gray to red.
Relay Out - Using this checkbox, read the relay output status and set or reset it manually.
Motion - Shows the motion event status.
6
Event Alert Icon (
Camera Time - Display the camera time.
7
) appears if 'Motion Detection' is activated.
13
1
6
7
