Digital Watchdog MEGApix IVA DWC-MB48WiAT User Manual page 39

Setup - Network Setup
SNMP Settings
1
2
3
4
5
6
7
8
9
SNMPv1/SNMPv2 - Select the SNMPv1/SNMPv2 option and type the names of Read and Write communities.
1
SNMP trap can be used to check periodically for operational thresholds or failures that are defined in the MIB.
SNMP Trap - Enable or disable the SNMP trap.
2
SNMPv3 contains cryptographic security, a higher security level, which allows you to set the Authentication
password and the Encryption password.
Mode - Select either Read or Read/Write mode.
3
Activation - Select mode to enable or disable.
4
Read/Write name - Define Read name and Write name.
5
Security Level - Select one of no auth, no priv/auth, priv.
6
Authentication Algorithm - Select MD5 or SHA as the authentication method.
7
Authentication Password - The Authentication Password is encryption for authentication and is between 8
8
to 30 digits long.
Click 'Apply' to save all settings.
9
