3.2 Dimensions (mm) and Weight (Kg)
778

3.3 Connections

LEFT Connections from and to outside are set on the left side of the unit front view
RIGHT Connections from and to outside are set on the right side of the unit front view
The factory setting is LEFT.
Fig. 3.a Connections in LEFT orientation
Intake air from outside
A
Exhaust air to outside
B
Supply air to inside
C
Extract air from inside
D
Winter condensation drainage
E
Summer condensation drainage
F
B
144 490 144
279 279
220
A
B
A
D
ø155
ø148
C
D
DEFAULT
C
525 23
548
Weight Kg
36
F E
