OPERATION and MAINTENANCE
INSTRUCTION MANUAL
AEU-25T Electronic Endodontic System
Endo
DTC
®
DIGITAL TORQUE CONTROL
DUAL VOLTAGE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AEU-25T and is the answer not in the manual?

Questions and answers

Summary of Contents for DENTSPLY AEU-25T

  • Page 1 OPERATION and MAINTENANCE INSTRUCTION MANUAL AEU-25T Electronic Endodontic System Endo ® DIGITAL TORQUE CONTROL DUAL VOLTAGE...
  • Page 2: Table Of Contents

    TABLE OF CONTENTS: SPECIFICATIONS: Introduction ......1 Console Size: 3.5” x 5” x 7” (9 cm x 13 cm x 18 cm) Package Contents .
  • Page 3: Introduction

    Your new Endo DTC ® is one of the most advanced units available to the dental profession. This system features advanced digital torque control technology with auto-stop reverse to help prevent file breakage in the canal, five programmable memory buttons with an onboard file library, an integrated calibration system, and the versatility of an autoclavable 30,000 RPM brushless micro motor.
  • Page 4: Setting Up The Unit

    STEP-BY-STEP INSTRUCTIONS SETTING UP THE UNIT: 1. Unpack the console and check Figure 1 that the Voltage Selector is set to the proper voltage. Use 115v for 110-120v 60Hz voltages, and the 230v for 220-250v 50Hz POWER CONSOLE voltages. To change the Voltage CORD Selector, see page 15.
  • Page 5 Figure 3 - Console Front CONSOLE LCD DISPLAY Torque Selector Handpiece Ratio Selector Forward/Reverse Speed Selector Calibration/ System Setup: Maximum Torque • PRESET MEMORY LOCK Selector • RECALL FACTORY SETUP • AUTO STOP REVERSE • REVERSE BEEPER • TORQUE WARNING TONE •...
  • Page 6: Quick Start Operation

    QUICK START OPERATION 3. Insert an endodontic rotary file into the After the unit has been set up, you are ready for handpiece. quick start operation as follows: 4. Use the Calibration function to calibrate the 1. Turn the Power Switch on the rear panel of Endo DTC ®...
  • Page 7 PathFile (All Files) handpiece will operate, rotating through a pre- Preset Button 2 Default File Series: programmed speed DENTSPLY Tulsa Dental Specialties ProTaper Next™ Files range. Before calibrating, File #1: ProTaper Next High All be sure a file or bit is...
  • Page 8: Advanced Operation & Functions

    ADVANCED OPERATION AND FUNCTIONS 1. HANDPIECE RATIO SELECTOR: 3. TORQUE SELECTOR: Sets the Handpiece Ratio Indicator on the Allows the user to adjust exact torque limits Console LCD Display to read accurately for in Gram•Centimeter increments. Push the different handpiece ratios. Torque Selector up/down arrows until the Multiple handpieces with different ratios are desired torque level is indicated on the...
  • Page 9: Calibration And System Setup

    6. CALIBRATION AND RECALL FACTORY SETUP SYSTEM SETUP BUTTON: 1=no, 2=yes, 3=esc Calibration (CAL): Recalling the Factory Setup allows you to reset Press and release the "CAL" button to activate ® your Endo DTC to factory specifications. NOTE: the Integrated Calibration System. The AEU-25 Any customized presets will be lost if you Recall will automatically run the handpiece and Factory Setup.
  • Page 10: Reverse Beeper

    SYSTEM SETUP MENU - CONTINUED: REVERSE BEEPER • To exit the System Setup, press 3. SAVE CHANGES selection will appear. 1=on, 2=off, 3=esc Select 1 to save changes and exit or select When the Reverse Beeper (BPR) feature is active, 2 to reject all changes and exit.
  • Page 11: Intro To Programming Preset Buttons

    INTRODUCTION TO PROGRAMMING PRESET BUTTONS: By default, the Preset Buttons are programmed 2. If a Single File was programmed on the to recall the file series shown in Chart 1 on preset button, the words "Single File page 5. Preset" and the File Name will be dis- played, as shown in the example below.
  • Page 12 PROGRAMMING A PRESET BUTTON WITH AN ENTIRE FILE SERIES: 1. Disable the Preset Memory Lock. 7. The display will show: For instructions, read about the System USE DEFAULT HP? Setup Menu beginning on page 6. 1=next, 2=ok, 3=esc 2. Press and hold the desired Preset Button NOTE: The default handpiece is the for 1 second (until you hear a double handpiece that was shipped with the...
  • Page 14 10. PROGRAMMING A PRESET BUTTON WITH A SINGLE FILE 1. Disable the Preset Memory Lock. Example 2: For instructions, read about the System To go to the F2 and F3 files in the Setup Menu beginning on page 6. Protaper series, press Button #1 twice. 2.
  • Page 15 11. PROGRAMMING A PRESET BUTTON WITH A USER DEFINED PRESET 1. Disable the Preset Memory Lock and 7. The display will show: enable or disable Auto Stop Reverse and ACCESS FILE LIBRARY? torque warning tone. 1=yes, 2=no, 3=esc For instructions, read about the System Setup Menu beginning on page 6.
  • Page 16: Sterilization & Maintenance

    STERILIZATION AND WARNING MAINTENANCE: • Do not attempt to disassemble the motor or motor connector. HANDPIECES - Wipe with an alcohol • Do not oil or lubricate the motor. gauze. Clean and lubricate handpieces • Do not attach a handpiece to the with a cleaner/lubricant after each use and motor while the motor is running.
  • Page 17 CHANGING THE FUSE OR VOLTAGE - CHANGING THE VOLTAGE Follow the corresponding steps. WARNING Turn the power off and unplug the unit before following the steps below. Use a small flathead screwdriver to open the Fuse/Voltage Selector Panel on the back of the unit.
  • Page 18: Troubleshooting

    TROUBLESHOOTING: Problem: Correction: Console does not light when If lights are blinking, press a button or foot switch turned on: to exit Sleep Mode. Check console to power connection. Check voltage setting. Check fuse. If blown, replace with 1.0A/250V slo-blo fuse for 115 volts, & 0.5A/250V slo-blo fuse for 230 volts.
  • Page 19: Symbol Definitions

    WARRANTY: AEU-25T Endodontic System Distributed By: Tulsa Dental Specialties warrants this product DENTSPLY Tulsa Dental Specialties against defects in material or workmanship for DENTSPLY International, Inc. a period of two (2) years, from date of original 608 Rolling Hills Drive invoice.
  • Page 20 DFUDTC Rev 4 12/12 P/N: 420322 • Rev. J • ECO 12954 12/12 Software: P/N 890002 Rev. J (TUL06 Series) © 2012 DENTSPLY International, Inc. Rx Only For Dental Use Only ® is a registered trademark of Aseptico, Inc.
