HDMI/USB-C KVM Extender
Kit HDBT, 4K/60
Operation Manual
(500452)
1
MuxLab © 2021
94-000965-A/SE-000965-A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Pro Digital 500452 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for MuxLab Pro Digital 500452

  • Page 1 HDMI/USB-C KVM Extender Kit HDBT, 4K/60 Operation Manual (500452) MuxLab © 2021 94-000965-A/SE-000965-A...
  • Page 2: Table Of Contents

    Introduction ..................... 4 Features ....................5 Package Contents ..................5 Specifications ................... 6 Product Dimensions ................8 Typical Application ................. 8 Operation Controls and Functions ............9 Transmitter Panel ............... 9 Reciver Panel ................10 Troubleshooting ..................11 MuxLab © 2021 94-000966-A/SE-000966-A...
  • Page 3: Safety Precautions

    All contents in this manual are copyrighted, and cannot be cloned, copied, or translated without the express permission of MuxLab Inc. Product specifications and information in this document are for reference only, and the content may be updated from time to time without prior notice.
  • Page 4: Introduction

    230ft (70m) at resolutions up to 1080p via one (1) Cat 6/6a/7 unshielded twisted pair cable in a point-to-point configuration. The MuxLab HDMI/USB-C KVM Extender Kit HDBT, 4K/60 includes one (1) transmitter and one (1) receiver. The transmitter is a wall plate HDBT 2x1 switcher with HDMI and USB-C input. It features a US one-gang enclosure for Decora-style wall plate openings.
  • Page 5: Features

    ⚫ One (1) Power supply ⚫ Two (2) Wall Mount Brackets ⚫ One (1) User manual (available via download) Notes:Confirm that the product and accessories are all included. If not, please contact the supplier from which you purchased the unit. MuxLab © 2021 94-000966-A/SE-000966-A...
  • Page 6: Specifications

    1x HDMI IN [Type A, 19-pin female] 1x HDBaseT IN [RJ45, 8-pin female] Outputs: 1x HDMI OUT [Type A, 19-pin female] Connectors (Receiver) 1x AUDIO OUT [Phoenix jack] Control: 2x USB [USB A TYPE] 1x FW [Micro USB, Update port] MuxLab © 2021 94-000966-A/SE-000966-A...
  • Page 7 Receiver: 7.87” x 3.85” x 0.90” (200mm x 98mm x 23mm) Wall plate: 0.43 lbs (0.196 kg) Weight Receiver: 1.12 lbs (0.511 kg) Shipping Weight 2.67 lbs (1.21 kg) Warranty 2 years 500452 HDMI/USB-C KVM Extender Kit HDBT, Order Information 4K/60 (UPC: 627699004524) MuxLab © 2021 94-000966-A/SE-000966-A...
  • Page 8: Product Dimensions

    (*) The TX is PoC powered by the RX. However an optional power supply may be used if connected USB devices do not have their own power supply and must be powered via the TX USB port. MuxLab © 2021 94-000966-A/SE-000966-A...
  • Page 9: Operation Controls And Functions

    Connect to the computer’s USB port. USB-B port SOURCE button Used to switch HDMI / USB-C input signal. HDBaseT OUT Connect to the HDBaseT IN port of Receiver with a CAT6/6a/7 cable. 10 Micro-USB Firmware update port. MuxLab © 2021 94-000966-A/SE-000966-A...
  • Page 10: Reciver Panel

    When both HDMI and USB-C ports are connected to active signal, HDMI signal input is preferred; When both HDMI and USB-C ports are not connected to active signal, it will switch to the source signal of the Receiver. MuxLab © 2021 94-000966-A/SE-000966-A...
  • Page 11: Troubleshooting

    USB not working • USB Cable Check USB Cable but video OK If you still cannot diagnose the problem, please call MuxLab Customer Technical Support at 877-689- 5228 (toll-free in North America) or (+1) 514-905-0588 (International). MuxLab © 2021 94-000966-A/SE-000966-A...
  • Page 12 HDMI/USB-C KVM Extender Kit HDBT, 4K/60 Operation Manual MuxLab Inc. 2321 Rue Cohen Montreal, Quebec Canada H4R 2N7 Tel.: +1 (514) 905-0588 Fax: +1 (514) 905-0589 Toll Free (North America): 877 689-5228 URL: www.muxlab.com E-mail: info@muxlab.com MuxLab © 2021 94-000966-A/SE-000966-A...
