Removing the LCD Bezel

1. See "Removing the LCD Module" on page 66.

2. Remove the two upper and two lower bezel screw caps.

3. Remove the four securing screws from the LCD module.

Step

LCD Bezel

Chapter 3

Size

M2.5*5 (NL)

Quantity

4

Screw Type

95
