Aspire 4730Z/4730ZG/4330 Exploded Diagrams

Main Module

Item
Description
1
Middle Cover
2
Upper Cover
3
Mainboard
4
CPU Fan
5
Thermal Module
156
Part No.
Item
60.AT902.001
6
60.AT902.002
7
MB.ATV02.001
8
23.AT902.001
9
60.AT902.007
10
Description
Bluetooth
TBD
Module
Keyboard
KB.INT00.442
Power Cable
TBD
RJ-11 Cable
60.AT902.003
Lower Cover
Part No.
Chapter 6
