Removing the Switch Cover

CAUTION: Using tools to remove the Switch Cover may cause damage to the outer casing. It is
recommended that you only use your fingers to remove the Switch Cover.
1. See "Removing the Battery Pack" on page 44.
2. Locate and remove the two securing screws as shown.
Step
Switch Cover
3. Turn the computer over and open the LCD module to expose the Switch Cover.
4. Lift the Switch Cover as shown, and move from right to left side.
Chapter 3
Size
M2*3(NL)
Quantity
2
Screw Type
59
