Bottom View
Location
14
SPDIF Conn
15
Audio Conn (pink)
16
Audio Conn (blue)
17
USB (single Rev)
19
Fan Conn
20
CRT Conn (blue)
21
RJ45
23
MXM Conn
24
CPU Socket
25
Battery Conn
26
DCIN Cable Conn
152
Description
Location
27
USB PCB to MB
28
DDR2 5.2 mm (Rev.)
29
DDR2 9.2 mm (Rev.)
30
ODD SATA Conn
31
HDD SATA Conn
32
Mini PCI Express (5.2)
34
Card Reader
36
MXM Standoff (M2xH4)
37
Fan Standoff (M2xH6)—UMA only
42
ICL50 MB Fan Standoff—DIS only
Description
Chapter 5
