AMD CrossFireX
This motherboard supports the AMD CrossFireX
install multi-graphics processing units (GPU) graphics cards. Follow the installation
procedures in this section.

Requirements

1 Two identical CrossFireX
of 2-way CrossFireX
2 You would need one CrossfireX
3 Make sure that your graphics card driver supports the AMD CrossFireX
technology. Download the latest driver from the AMD website
(www.amd.com).
4 Make sure that your power supply unit (PSU) can provide at least the mini-
mum power required by your system.
Installing CrossFireX
1. Insert the CrossFireX
the card is properly seated on the slot.
A. For 2-way configuration, install two graphic cards on PCIEX16_1 and PCIEX16_2,
then connect them with the CrossFire
Z170-LIGHTSABER USER MANUAL
TM
Technology Support
TM ready graphic cards are needed for the setup
TM configuration.
TM bridge cable.
TM
graphics cards
TM graphics cards into the PCIEX16_1~3 slots. Make sure that
TM Bridge.
* For reference only
TM
Technology that allows you to
TM
