Table of Motherboard Components
LABEL
1. CPU Socket
2. CPUFAN1~2
3. DIMM1~4
4. 80P_SW
5. POST
6. POWER
7. RESET
8. ATX_POWER
9. SYSFAN1~2
10. USB3F
11. SATA3_1~6
12. SATAE_7/8
13. M2_2280M
14. SPIROM_SW
15. F_PANEL
16. ROM_BACKUP ROM backup button
17. F_USB1~2
18. CASE
19. BZ
20. BIOS_UPDATE BIOS update button
21. BIOS_SET
22. QUICK_OC
23. PWR_FAN
24. F_AUDIO
25. PCIEX16_1~3
26. PCIEX1_1~4
27. ATX_12V
Z170-LIGHTSABER USER MANUAL
COMPONENTS
LGA1151 socket for Intel
4-pin CPU cooling fan connectors
288-pin DDR4 Module slots
80 Port switch button
POST Code, Voltage and Temperature LED
Power on button
Reset button
Standard 24-pin ATX power connector
4-pin system cooling fan connectors
Front panel USB 3.0 header (supports EZ Charger)
Serial ATA 6Gb/s connectors
Serial ATA Express connector
M.2 M.2 Socket 3 with M key, supports type
2242/2260/2280 storage devices (both PCIE &
SATA mode)
SPIROM switch
Front panel switch/LED header
Front panel USB 2.0 headers
CASE open header
Buzzer header
BIOS set button
Quick OC button
4-pin Power cooling fan connector
Front panel audio header
PCI Express x16 Gen3 slots for graphics interface
PCI Express x1 Gen3 slots
8-pin +12V power connector
®
Skylake processor
