- Page 1 Camera Link Setting Manual 991SWIR-TEC-CL ARTCAM-991SWIR-TEC-CL Camera Link Setting Manual rev.1.00 Rev.1.00 © 2004 – 2021 ARTRAY Co., Ltd...
-
Page 2: Table Of Contents
Camera output bit assignment....................13 Settings ....................................14 6.1. Preparation ..........................14 6.2. Connect to Camera ......................... 14 6.3. Example of Serial Communication Software Settings ............. 15 6.4. Example of Viewer Software Settings ..................17 Rev.1.00 © 2004 – 2021 ARTRAY Co., Ltd... -
Page 3: Introduction
Table 2-3: Tested Framegrabbers + Software Manufacturer Product name + software NI PCIe-1433 + NI MAX AVAL APX-3318 + AcapLib2Viewer Xcelera-CL PX4 Full + CamExpert Dalsa EPIX PIXCIEB1 + XCAP ※ Tested CameraLink cable length: 2m Rev.1.00 © 2004 – 2021 ARTRAY Co., Ltd... -
Page 4: Camera Link Format
4. Connector Pin Assignment The connector pin assignment is as follows: Table 4-1: Connector Pin Assignment Pin No. Signal Name Pin No. Signal Name XCK- XCK+ CC0- CC0+ CC1+ CC1- CC2- CC2+ CC3+ CC3- Rev.1.00 © 2004 – 2021 ARTRAY Co., Ltd... -
Page 5: Communication Specifications
(e.g. BackSpace) before line any none- feed code, the response must be NG. half-width character before If you want to cancel the command, type a none- line feed code, the response will be NG. Rev.1.00 © 2004 – 2021 ARTRAY Co., Ltd... -
Page 6: List Of Commands
Mirror Horizontal mirror enable/disable Show camera name － Camera Information Show firmware version － Peltier ON － Peltier Control Peltier OFF － Sets preview mode － Capture mode － Sets trigger mode Rev.1.00 © 2004 – 2021 ARTRAY Co., Ltd... -
Page 7: Commands Details
5: Value of shutter speed 6: Line feed code Response Normal: OK⏎ Abnormal: NG⏎ Note Sets the shutter speed ※To calculate the shutter speed, please refer to the instruction of the camera. Rev.1.00 © 2004 – 2021 ARTRAY Co., Ltd... -
Page 8: Gain
3: -vf = Option: FPGA temperature readout 4: Line feed code Response Normal: temperature ⏎ Abnormal: NG⏎ Note To show the estimated temperature of camera FPGA. The temperature shown here is merely a reference. Rev.1.00 © 2004 – 2021 ARTRAY Co., Ltd... -
Page 9: Mirror
Format 〼 ⏎ Details 1: n = Camera information 2: Delimiter 3: -c = Option: Camera name 4: Line feed code Response Normal: ARTCAM-991SWIR-TEC-CL (example)⏎ Abnormal: NG⏎ Note To show camera name. Rev.1.00 © 2004 – 2021 ARTRAY Co., Ltd... -
Page 10: Peltier
Table 5-14: Peltier OFF Format 〼 ⏎ Details 1: p = Peltier 2: Delimiter 3: -n = Peltier OFF 4: Line feed code Response Normal: OK⏎ Abnormal: NG⏎ Note To disable peltier Rev.1.00 © 2004 – 2021 ARTRAY Co., Ltd... -
Page 11: Capture Mode
Table 5-13: Trigger Mode Format 〼 ⏎ Details 1: r = Capture mode 2: Delimiter 3: -t = Trigger 4: Line feed code Response Normal: OK⏎ Abnormal: NG⏎ Note Configures capture as trigger mode Rev.1.00 © 2004 – 2021 ARTRAY Co., Ltd... -
Page 12: Timing Chart
FVAL の High 期間 222720 FVAL 立ち上がりから最初の LVAL の立ち上がりまで LVAL の High 期間 LVAL の Low 期間 最終 LVAL の立下りから FVAL の立下りまで FVAL の Low 期間 230517 LVAL の立ち上がりから DVAL の立ち上がりまで DVAL の High 期間 Rev.1.00 © 2004 – 2021 ARTRAY Co., Ltd... -
Page 13: Camera Output Bit Assignment
A[11] B[8] B[9] B[10] B[11] B[0] B[1] B[2] B[3] B[4] B[5] B[6] B[7] COL 0 COL 639 ROW 0 A[11:0] B[11:0] A[11:0] B[11:0] … … … ROW 511 A[11:0] B[11:0] A[11:0] B[11:0] Rev.1.00 © 2004 – 2021 ARTRAY Co., Ltd... -
Page 14: Settings
Please connect camera to the Camera Link frame grabber board with Camera Link cable. Before connect AC adapter to the camera, please start up the serial communication software. Command will be sent from the camera once it is connected to the power. Rev.1.00 © 2004 – 2021 ARTRAY Co., Ltd... -
Page 15: Example Of Serial Communication Software Settings
Please click “Setup” on menu bar, then choose “Serial Port” for communication method settings. Please refer to table 5-1 Communication Method for details of the settings. Figure 6-4: To Set up Serial Port on Tera Term Rev.1.00 © 2004 – 2021 ARTRAY Co., Ltd... - Page 16 “OK” on the dialog box. Then you can send command to control camera. Please note that camera will start up only when you send out the command. Figure 6-6: Initialization Rev.1.00 © 2004 – 2021 ARTRAY Co., Ltd...
-
Page 17: Example Of Viewer Software Settings
Figure 6-8: Welcome message Please click “PIXCI®” from XCAP menu, then choose “PIXCI®Open/Close” to open the dialog box. Please click “Open” to start the camera. Figure 6-9: To Open Camera Rev.1.00 © 2004 – 2021 ARTRAY Co., Ltd... - Page 18 Please refer to table 3-1 to confirm the Camera Link format. Figure 6-10: Configure Settings Second, please set the resolution. Please refer to table 3-2 to confirm the resolution of each model. Figure 6-11: Resolution Settings Rev.1.00 © 2004 – 2021 ARTRAY Co., Ltd...
- Page 19 The settings are finished now. The image will be displayed either by clicking “Live” in “Capture” on the sub-window, or simply by clicking “Live Icon” on the left side of the sub-window. Figure 6-13: Live Icon Rev.1.00 © 2004 – 2021 ARTRAY Co., Ltd...
