- Page 1 Nov 12, 2021 Ver1.02 Camera Link Connection InGaAs Camera ARTCAM-991SWIR-TEC-CL INSTRUCTION BOOKLET ARTRAY CO., LTD. - 1 -...
-
Page 2: Table Of Contents
Contents Attention ..............................- 3 - Introduction .............................. - 6 - Main Features ............................- 6 - The Product .............................. - 6 - Connect the Camera ..........................- 7 - 5.1. How to Connect a Camera ......................- 7 - 5.1.1. -
Page 3: Attention
1. Attention ■ About this manual 1．Before using the camera, please read this manual thoroughly. 2．Please keep this manual reachable and always refer to the contents when needed. 3．Please contact us if the manual is lost or damaged. We will provide a replacement. 4．We cannot guarantee the safety of improper uses of the camera. - Page 4 ■ For Safe Use Warning ●In following circumstances, please stop using the product and turn off the power immediately to prevent the risks of fires and electric shocks. If the product is defective, please contact us for repair or exchange. For your safety, please do not disassemble, modify or repair the camera on your own. Please stop using the product and turn off the power immediately when: ・...
- Page 5 For more details, please refer to the sites below: Hardware Warranty: http: //www.artray.us/download/artray_warranty.pdf ■ Dispose To dispose this product, please return the camera to us. If you decide to dispose the camera without returning it us, please follow related regulations and have the camera disposed as an industrial waste.
-
Page 6: Introduction
2. Introduction This manual is to identify the specification of ARTCAM-991SWIR-TEC-CL, NIR camera adopting InGaAs (Indium gallium arsenide) sensor with Camera Link interface. 3. Main Features ●NIR Detection with High Sensitivity The InGaAs sensor can detect radiation invisible to human eyes and CCD/CMOS cameras in the wavelength range between 400 nm to 1700 nm bond. -
Page 7: Connect The Camera
5. Connect the Camera 5.1. How to Connect a Camera 5.1.1. When connecting to a desktop PC 5.1.2. When connecting to a notebook PC - 7 -... -
Page 8: Specifications
6. Specifications 6.1. Camera Specification ARTCAM-991SWIR-TEC-CL MODEL SONY IMX991-AABA-C Sensor Model 640(H) × 512(V) Effective Pixel Array 5[μm] × 5[μm] Pixel Pitch 3.2[mm] × 2.56[mm] Image Size (Diagonal length: 4.1[mm], 1/4”) 400nm~1700nm Spectral Range Global Shutter Shutter type 51dB (for reference only) -
Page 9: Analog / Digital Gain Settings
The graph below shows the relationship between setting value of gain and its magnification[dB]. 6.1.2. Shutter speed calculation ARTCAM-991SWIR-TEC-CL allows for shutter speed control. Shutter speed value can be calculated by the following formula: Shutter speed [us] = value*12.96[us] - 9 -... -
Page 10: Dimensional Outline
6.1.3. Dimensional Outline Drawing of the base without a tripod mount 6.1.4. Sensor Package Information - 10 -... -
Page 11: Sensor Position And The Light Receiving Surface
Sensor Position and the Light Receiving Surface 6.1.5. H = 5[um] * 640 = 3200 [um] V = 5[um] * 512 = 2560 [um] 6.1.6. Field of Vision: Lens versus Sensor（For Reference Only） ※ The ratios of sensor size (diagonal) to lens size in the above illustrations are as follows: 1/2 inch = φ8mm, 2/3 inch = φ11mm, 1 inch = 15.8mm. -
Page 12: Spectral Sensitivity Characteristics
6.2. Spectral Sensitivity Characteristics 6.3. External Trigger Function This camera has an external trigger electronic circuit, which is insulated by a photocoupler, and thus enables synchronized shooting by the input signal received from the external circuit. - 12 -... -
Page 13: Trigger Timing
6.4. Trigger Timing items Required time Effective trigger input pulse >10μsec. From the rise of the external trigger input to the fall of the trigger signal passed to the sensor <1μsec. (Delay due to the photocoupler) From the fall of the trigger signal passed to the Max 0.13μs sensor to the start of exposure Exposure time = The setting value of the... -
Page 14: Recommended System Requirements
Please confirm with us if you are using different grabber. ⚫ Please confirm the recommended requirement of the Camera Link frame grabber. ARTRAY Co., LTD. Obtained ISO 9001: 2015 2018/9/17 1-17-5 Kouenjikita, Suginami-ku, Tokyo 166-0002 Japan TEL: +81-3-3389-5488 FAX: +81-3-3389-5486 Email: sales@artray.us...
