Powering Down the Device

CAUTION: Failing to properly power down the device before removing power may corrupt your device's file
system.
Following are two options that power down the device while maintaining the current parameter settings and
allowing for a clean network detach.
Issue command AT+QPOWD.
or
Hold the NRESET signal (pin 35) low for at least 1 second.
Note: Note: AT+QPOWD will not take more than 40s.
