SPECIFICATIONS
Category
SMS
SMS
Certifications and Compliance
EMC and Radio
Compliance
Safety Compliance
Carrier
Underwriters Laboratories, Inc. Required Global Positioning System
(GPS) Statement
Note the following information required by Underwriters Laboratories: Underwriters Laboratories, Inc.
Underwriters Laboratories Inc.("UL") has not tested the performance or reliability of the Global Positioning System
("GPS") hardware, operating software or other aspects of this product. UL has only tested for fire, shock or
casualties as outlined in UL's Standard(s) for Safety. UL60950-1 Certification does not cover the performance or
reliability of the GPS hardware and GPS operating software. UL MAKES NO REPRESENTATIONS, WARRANTIES OR
CERTIFICATIONS WHATSOEVER REGARDING THE PERFORMANCE OR RELIABILITY OF ANY GPS RELATED FUNCTIONS
OF THIS PRODUCT.

LED Interface

LED — Link Status— All Builds
The LED signal indicates the SocketModem working status. Refer to the mechanical drawing for LED location.
LED Signal
Off
On

Powering Down Your Device

CAUTION: Failing to properly power down the device before removing power may corrupt your device's file
system.
To properly power down your device, use the following sequence :
1. Issue the AT#SHDN command.
10
Description
Point-to-Point messaging
Mobile-Terminated SMS
Mobile-Originated SMS
SMS over IMS
CE Mark, RED (EU)
IEC 60950-1 2nd ED
EU
Link Status LED
No power to the device.
Continuously lit
Slow blink (0.2Hz)
Faster blink (3Hz)
Powered and connected, but not transmitting or receiving.
Powered and searching for a connection.
Transmitting or receiving.
SocketModem
®
Cell MTSMC-L4E1 Device Guide for Europe
