ANTENNAS
Chapter 4 – Antennas
Antenna System Cellular Devices
The cellular/wireless performance depends on the implementation and antenna design. The integration of the
antenna system into the product is a critical part of the design process; therefore, it is essential to consider it early
so the performance is not compromised. Devices were approved with the following antenna(s) and for alternate
antennas meeting the given specifications.
The antenna system is defined as the UFL connection point from the device to the specified cable specifications
and specified antenna specifications.
PTCRB Requirements
There cannot be any alteration to the authorized antenna system. The antenna system must be the same type with
similar in-band and out-of-band radiation patterns and maintain the same specifications.
Antenna
Devices were approved with the following antenna:
Manufacturer:
Description:
Model Number
MultiTech ordering information:
Model
ANLTE4-1HRA
ANLTE4-2HRA
ANLTE4-10HRA
ANLTE4-50HRA
Antenna Specifications
Category
Frequency Range
VSWR
Gain
Impedance
Radiation
18
Wieson
LTE Antenna with SMA-Male Connector
GY115IE002-001
Quantity
1
2
10
50
Description
0.698 - 0.96 GHz
1.710 - 2.170 GHz
2.30 - 2.69 GHz
3:1 maximum
2.06 dBi
50Ω nominal
Omni-directional
®
SocketModem
Cell MTSMC-L4G1 Device Guide
