Specula dispensers

Advertisement

Mat. No. 773421, 80027532 ver A
Revision Date: 2020-12
Choose the mounting method best suited to mounting surface type:
To affix unit to a dry, clean, firm nonporous surface (such as
sheetrock) use double-sided tape:
1. Attach 2 pieces of double-sided tape to White Base, keeping
outer release liner in place. Select location on wall.
CAUTION
Take particular care to properly
locate the unit at FIRST contact of tape to wall.
2. Remove release liners and press unit firmly against wall in
exact position desired.
3. If necessary to relocate: Remove from wall by prying
under rear of White Base. Then remove old tape and apply
new double-sided tape (1/16" thick) such as 3M 4466W or
equivalent.
Models 52400 and 52401 Specula Dispensers
OR
(over)
Mounting Instructions
To affix unit to a rough, porous surface (such as vinyl
wallpaper) use screws:
1. Mark desired location for top of unit on wall. Measure
down 3" to mark top screw location. Measure down 3" to
locate lower screw.
2. Drive the two screws provided into the wall, leaving
about 1/8" behind the screw head. Depending on the
mounting surface, alternate screws may be needed.
3. Mount unit by fitting the round holes in the rear of White
Base over screw heads on the wall. Then push downward
on the unit to secure it to wall.
