7.5. DEVICE CONFIGURATION

The Device configuration menu is the main menu of the device that allows the user to
configure all the inputs and outputs of the device to measure and control the system.
To prevent accidental or unauthorized change to the settings in the Device
configuration menu, the user can set the access protection (see Chapter 7.17. ACCESS
OPTIONS). If this option is set, before entering each submenu, the user will be requested to
enter the password.
More information about selected sub-menus is described in further Chapters.
To exit the main menu, press the
screen. Due to the fact that the configuration process takes place in real time, all changes
must be confirmed before saving them. In the confirmation window, you can Save or Revert
changes (see Fig. 7.36).
There is a possibility to press the
will appear (see Fig. 7.37 ), and the user must choose to save a new configuration or go to
the main screen with an unsaved but active configuration. If the second option is chosen,
the icon: , will be displayed on the information bar, the device will also keep a new
configuration in memory and the user can determine if those changes brought a desired effect
(see Fig. 7.38 ). This operation can be repeated any number of times, as long as the new
configuration is saved or the old one is reverted.
i
In case of power failure, changing to a remote or local display, any unsaved
settings will be lost, and the last saved configuration will be restored.
62
Fig. 7.34. The device configuration menu
button located in the upper right corner of the
button again. In that case the warning message
